This document provides an overview of the Poly Rove wireless DECT IP phone solution, including its key components, configuration and calling features. It discusses the Poly Rove B2 and B4 base stations, R30 and R40 handsets, and R8 repeaters. It outlines how to provision the base stations, pair handsets and repeaters to extend the wireless range, and use calling features like transfer and conference. The goal is to train users on setting up and using the Poly Rove DECT system.

1. Poly Rove (DECT)– Training
Session
From: Vijay Paul

2. Agenda
• Introduction
• Poly Rove DECT components – B2, B4,
R8, Rove30, Rove40
• Poly Rove Provisioning
• Pairing Base R2 with handsets R30, R40
• Repeaters
• Calling Features
• Q/A

3. Introduction
• Poly wireless DECT IP Phone
Solution
• Poly Rove B2 Base Station
• Poly Rove B4 Base Station
• Poly Rove 30 Handset
• Poly Rove 40 Handset
• Poly Rove R8 Repeater

4. Poly Rove –Base Station and Repeaters
1. Rove B2:
• DECT range Indoor up to 50m and outdoor up to
300m
• Up to 20 Handsets (Single/Dual Cell)
• Up to 10 Simultaneous Calls (Single Cell)
• Up to 20 Simultaneous Calls (Dual Cell)
• Up to 20 SIP Registrations
*Blueface Template is designed for 10 Lines
2. Rove B4:
• DECT range Indoor up to 50 m and outdoor up to 300
m.
• Up to 30 Handsets per Base Station
• Up to 8 Simultaneous Calls per Base Station
• Up to 1000 Handsets per System
• Up to 1000 SIP Registrations per System
• Up to 2000 Simultaneous Calls per System
3. Rove R8 Repeater
• Extend range between base station
and handset by 50 m indoor and
300 m outdoor
• Pairing up to six repeaters for each
Poly Rove B2 base station
• Pairing up to three repeaters for
each Poly Rove B4 base station
• Automatically hand-off calls
between repeaters

5. Poly Rove –Handsets
1. Rove R30:
• Multiple Lines Support for Handsets (20 lines
per HS)
Multilingual user interface
Dedicated 3.5 mm standard headset port
2. Rove R40:
• Multiple Lines Support for Handsets (20 lines
per HS)
• Multilingual user interface
• Dedicated 3.5 mm standard headset port
• Bluetooth® headset compatibility

6. Poly Rove
Provisioning
1. On the Blueface UC portal template
"Poly Rove B2" is created
2. The MAC address of Base Station B2
or B4 to be used for provisioning
3. Once DECT base station is provisioned
successfully the LED will turn solid
green.
4. This will add one line to DECT base
station
5. The line will become active when
Handset is paired successfully to
Base Station

7. Pairing Base R2 with handsets R30, R40
• On the wireless handset R30 or R40, go to Menu > Settings
• Select Connectivity > Easy Registration
• Once registered successfully a message "Registration Success!" Will pop-up on handset
• To add additional handsets to same Base Station.
• On the already registered handset Select Connectivity > Easy Registration
• At the message "? Add another device to the system?" Select Yes
• One the new handset which you which to pair go to > Settings Connectivity > Easy Registration
• Once registered successfully a message "Registration Success!" Will pop-up on both the handsets

8. Repeaters R8
• Power all the repeaters you want to pair.
The status indicator on the repeaters flash green when they are
in pairing mode.
• On the already registered wireless handset, go
to Menu > Settings .
• Select Connectivity > Easy Registration.
• At the message "? Add another device to the system?" Select Yes
The Poly Rove base station searches for a repeater in pairing
mode and assigns it to the first available index. The repeater's
status indicator displays solid green when it's paired with a base
station.

9. Calling Features
• Calling Features
• Support upto 10 lines per base station with independent realms,
transport mode (TCP, UDP & TLS)
• Inbound, outbound, transfer, conference.
• DND
• BLF
• Voicemail

10. Thank You
Q/A
