1. 1-10 Operations
1-10
1.2.3 Worksheet Tab
The Worksheet tab contains a summary of the information contained in
the stream property view for all the streams attached to the air cooler.
The Conditions and Composition pages contain selected information
from the corresponding pages of the Worksheet tab for the stream
property view.
The Properties page displays the property correlations of the inlet and
outlet streams of the unit operations. The following is a list of the
property correlations:
• Vapour / Phase Fraction • Vap. Frac. (molar basis)
• Temperature • Vap. Frac. (mass basis)
• Pressure • Vap. Frac. (volume basis)
• Actual Vol. Flow • Molar Volume
• Mass Enthalpy • Act. Gas Flow
• Mass Entropy • Act. Liq. Flow
• Molecular Weight • Std. Liq. Flow
• Molar Density • Std. Gas Flow
• Mass Density • Watson K
• Std. Ideal Liquid Mass Density • Kinematic Viscosity
• Liquid Mass Density • Cp/Cv
• Molar Heat Capacity • Lower Heating Value
• Mass Heat Capacity • Mass Lower Heating Value
• Thermal Conductivity • Liquid Fraction
• Viscosity • Partial Pressure of CO2
• Surface Tension • Avg. Liq. Density
• Specific Heat • Heat of Vap.
• Z Factor • Mass Heat of Vap.
The PF Specs page contains a summary of the stream property view
Dynamics tab.
The PF Specs page is
relevant to dynamics cases
only.
The Heat of Vapourisation for
a stream in HYSYS is defined
as the heat required to go
from saturated liquid to
saturated vapour.
