- Objection.js is a SQL ORM that allows you to define models for tables using ES6 classes and define relationships between them. It uses Knex for building SQL queries and managing database schemas. - The presentation demonstrates how to install Objection.js and Knex, create database migrations to manage schema changes, define models and relationships, perform queries, add validation, and use plugins like Objection-GraphQL and Objection-Password. - The speaker also announces that they are launching their own consultancy called ANEPHENIX and will be available for contracting work beginning in mid-June.

1. Objection.js
a SQL ORM
Paul Jensen

2. HELLO
ITS ME AGAIN!

3. Node.js has plenty of
ORMs

4. Why consider
another?

5. Sometimes a fresh take on
an existing challenge can
offer something better

6. So for your
consideration, I offer
you this…

7. Objection.js
github.com/vincit/objection.js

8. Objection.js
• Let’s you create models for tables with ES6 classes and define
relationships between them
• Make queries with Node’s async/await
• Add validation to your models using JSON schema
• Use eager-loading and transactions with your models
• Work with nested documents in rows
• Perform Graph Inserts and Upserts
• and more…

9. Install

10. Knex
knexjs.org

11. Knex
• Rather than reinvent the wheel, Objection uses Knex, a
powerful SQL query builder.
• Besides building SQL queries, Knex is used to establish
database connections, including pooling connections.
• Also, it is used for managing database schemas via
migrations.

12. Install a DB driver as well

13. Creating and managing
database schemas

14. Creating and managing
database schemas
• Database migrations are a good pattern for managing
changes to database schemas over time.
• Objection.js defers to Knex for doing database migrations.
• Knex depends on connecting to an existing database, so
we’d need to create that first (unless it exists already).

15. Creating a database

16. Creating migrations
• Migrations allow you to apply a change to a database
schema in a step-by-step fashion.
• The “up” action applies a change (creating a table, adding
or modifying a column, appending an index).
• The “down” action applies the reverse action of the change
(e.g. if a migration’s “up” action creates a table, it’s
equivalent “down” action will drop the table).
• It provides a way to evolve a database schema over time,
and be able to track the state of the database schema
alongside the source code in version control (Git).

17. Creating migrations
• Objection uses Knex’s in-built support for generating
migrations and applying them, as well as being able to roll
them back.

18. Creating migrations

19. Creating migrations

20. Creating migrations
• Knex will create a migrations folder (unless it exists already)
• It then creates a file in the migrations folder for the
migration
• The filename from the command line is prepended with a
timestamp so that we can organise migrations in
chronological order.
• That determines the order in which migrations are
executed.

21. The generated migration

23. Apply the migration

24. Apply the migration

26. Reversing the migration

27. Reversing the migration

29. Models

30. Models
• Models are the wrappers around database tables
• They help to encapsulate the business logic within those
tables (relations, validations, indexes, triggers).
• Objection.js allows you to create Models using ES classes

31. Task model

32. Queries

33. A simple SELECT query
can be done with…

34. A more typical SELECT
query
can be done with…

35. INSERT queries
can be done with…

36. UPDATE queries
can be done with…

37. DELETE queries
can be done with…

38. Relationships

39. Relationships
• Objection.js provides a way to define the relationship
between models that is powerful and flexible.
• The relationships allow you to use other features like eager
loading, as well as support Objection.js’ GraphQL plugin.

40. Relationships
tasks
id
name
due_by
is_done
created_at
updated_at
task_joins
id
dependent_id
dependency_id
created_at
updated_at
1
∞
∞

44. You can also specify
relationships through
join tables

47. Example:
Doing the dishes

51. Eager Loading

53. Lifecycle functions
• A way to trigger functions when a record is inserted,
updated, deleted, fetched or validated.
• The lifecycle functions follow a pattern of beforeAction
and afterAction.

54. Lifecycle functions
• beforeValidate, afterValidate
• beforeInsert, afterInsert
• beforeUpdate, afterUpdate
• beforeDelete, afterDelete
• afterGet

55. Lifecycle functions
You can execute functions that
trigger during the lifecycle of
inserting and updating records.
You can determine whether
they happen before or after the
lifecycle event.

56. Lifecycle functions
You can execute functions that
trigger during the lifecycle of
inserting and updating records.
You can determine whether
they happen before or after the
lifecycle event.

57. Validations

58. Validations
• Objection allows you to add validation logic to your models
through using JSONSchema.
• The validation logic will raise errors which can then be
intercepted with try/catch

60. If you add jsonSchema to your
models, you get to use some
very cool plugins later on

61. Graph Inserts

62. Graph Inserts are cool
🕶

64. Quick demo

65. Plugins

66. Plugins
• Objection comes with a few plugins that are worth
checking out
• Two which I can recommend are “objection-graphql” and
“objection-password”

67. Objection-Password
• Objection password adds quick local authentication to an
application, using Bcrypt to apply the salting and hashing.
• Setting it up is very simple - simply specify the number of
hashing rounds for encrypting the password, and make
your User model an extended class of the Password class

71. Objection-GraphQL
• Objection-GraphQL allows you to put a GraphQL API on
top of your Objection.js models with a few lines of code.
• You will need to have your models using JSONSchema in
order to get the benefits of this.

72. Quick little demo

73. Performance?

74. Do benchmark it, see
what the performance
impact is like

75. Wrap up 🌯

76. Objection.js
github.com/vincit/objection.js

77. Knex
knexjs.org

78. Objection-Password
github.com/scoutforpets/objection-password

79. Objection-GraphQL
github.com/vincit/objection-graphql

80. One more thing…

81. After 2½ glorious
years at Starcount

82. I’m going to launch
my own consultancy

83. ANEPHENIX

84. and I’m available for
contracting from mid
June

85. Thank You
