Using Python, the author has developed a program that learns about protocol formats, with the main goal in being useful for Deep Packet Inspection. Deep Packet Inspection is a process mainly used in network security to ensure integrity of network data sent across the network. Deep Packet Inspection is used to pre-empt and prevent malicious data from being transmitted over a network in order to ensure the security of the organization. http://tw.pycon.org/2015apac/en/lightning_en

1. NETWORK SECURITY AND ANALYSIS
WITH PYTHON
Lee Yang Peng
Dunman High School
Singapore

9. DEEP Packet Inspection
Searching if anything in the packet is suspicious

14. ANALYTICS
Motivation: Helping Deep Packet Inspection
An initial experimental study
Then I conducted experiments on them to determine their effectiveness

16. HEURISTICS FOR ANALYTICS
Detecting Constant Fields and Enumeration fields to learn about protocol format
Constant: Bytes that do not change data in all packets in a single protocol.
 For example: {‘x00’} appears all the time. Or {‘x00’, ‘x01’, ‘x02’} in sequence
Enums: Bytes at fixed positions that changes only slightly or has a limited number of
values.
 For example: At position 5, only contains values within {‘x00’, ‘x01’, ‘x02’}

18. Constant fields in protocol headers:
Maybe…
Paddings
Protocol Version
Reserved Fields

22. Where pi is the probability of each value
occurring

24. 13 May 2015

26. Ethernet TCP UDP
IPv4 IPv6 ICMP
IGMP(v3) ARP SMB
NBNS LLMNR DNS
SCTP OSPF

27. Contagio:
http://contagiodump.blogspot.sg/

29. • Collected data unable to simulate randomness of a
real network
• False positives will be observed
• For consistency, will mark these as incorrect during
my evaluation

34. • Manual analysis of the protocol header was compared against ground
truth from protocol documentation
• Mark every byte in protocol header as {Constant, Not Constant}, and
{Enum, Not Enum}
• Accuracy = (True Positives + True Negatives) / Total Header Length
• Entered these data into a table

35. Protocol Accuracy (Constants) Accuracy (Enums)
TCP 100% 95%
IPv4 90% 95%
Ethernet 100% 100%
IPv6 97.5% 92.5%
DNS / NetBIOS-NS / LLMNR 41.7% 91.6%
ARP 50.0% 62.5%
ICMP 100% 100%
UDP 100% 100%
OSPF 30% 80%
IGMP Version 3 50% 62.5%
SCTP 100% 100%
SMB 62.5% 84.4%
Average Accuracy 76.8% 88.6%

36. LIMITATIONS
• Is only useful for analyzing a single protocol
• Heuristics to detect higher level fields such as dependencies and
sequence numbers are not yet implemented
