HOLLARD BACKUP & REFRESH – THEN & NOW
SOLUTION
• EMC XtremIO All-Flash Array
• iCDM (SQL Sync)
“XtremIO has changed the way Hollard IT
manages data movement from disk to
disk or disk to tape by completely
eliminating the data copy process
through iCDM.
Long term retention backups now run in
less than 15% of the original time with
no additional investment in hardware
and software.”
APPLICATIONS
• Mission Core Line of Business systems
SQL databases
• AGILE Dev platform
• TSM data protection and long term
retention infrastructureRESULTS
• 0% impact on storage IO for Dev refresh via iCDM
• 0% impact on application performance during backups execution
• 85% reduction in AVG time to complete long-term retention backups
• Zero development/config necessary to achieve improvements
0%
20%
40%
60%
80%
100%
Backup time reduction [%] CHALLENGE
• Daily backup window impacting service availability due to overruns
• Business unable to extend operating hours due to backup requirement
• Month end backup window exceeds 24 hours on certain applications
• Restores from PROD to DEV resulting in long delay in DEV availability](https://image.slidesharecdn.com/mt49-xtremio-overview-841bb540-c64a-4a00-81f2-eceaafd1099b-914978036-161014225011/75/MT49-Dell-EMC-XtremIO-Product-Overview-and-New-Use-Cases-61-2048.jpg)
Uploaded byDell EMC World
MT49 Dell EMC XtremIO: Product Overview and New Use Cases
The document provides an overview of Dell EMC's XtremIO, an all-flash array designed to enhance the efficiency, agility, and speed of modern data centers. It highlights its capabilities such as automated provisioning, data mobility, and cost reduction, alongside real-world use cases demonstrating substantial performance improvements and operational savings for businesses like Moen. Additionally, it emphasizes the shift to flash storage as a competitive advantage and details the transformative benefits of consolidating workloads using XtremIO technology.
More Related Content
Similar to MT49 Dell EMC XtremIO: Product Overview and New Use Cases
MT49 Dell EMC XtremIO: Product Overview and New Use Cases
- 1. MT49 Dell EMC XtremIO:Product Overview and New Use Cases Dion Harris, Senior Manager – Product Marketing
- 2.
- 3. 3 Pillars of themodern data center PROTECTION AND TRUST Security/Governance – Encryption – Data Protection – Services/Support FLASH SCALE-OUT SOFTWARE DEFINED CLOUD ENABLED Reduce Costs (# Of Drives, Power, Floor Space. Etc.) Consistent And Predictable Performance Lower Entry Costs And Scale As You Grow Manage Massive Capacity With Fewer Resources Automated Provisioning And Business Agility Flexible And Programmable Data Services Policy Driven Service Delivery On/Off Premises Data and/or Application Mobility
- 4. 4 FLASH WILLACCELERATE YOUR TRANSFORMATIONTO THE MODERN DATA CENTER
- 5. 5 Flash – afundamental market shift ... $- $10 $20 $30 $40 $50 $60 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 20 AnnualRevenueinBillion$ HARD DISK DRIVES 2016 Source: © Wikibon Server SAN Research Project 2015
- 6. Dell - InternalUse - Confidential6 Driven by economics 2000 2002 2004 2006 2008 2010 2012 2014 2016 2018 2020 CROSSOVER POINT SOURCE: EMC MARKET RESEARCH 2016 *CAPACITY COST FACTORS IN DATA REDUCTION TECHNOLOGIES ON FLASH CAPACITYCOST* Dell - Internal Use - Confidential
- 7. Dell - InternalUse - Confidential7 FOR PRIMARY STORAGE
- 8. 8 Every day morecustomers choose flash “10% of companies are all flash today (they’re not telling anyone) – 80% have a plan to get there” — Eric Burgener, IDC Infrastructure Agility Lower TCO Competitive Edge
- 9. 9 Business Agility = Architecture matters It’sabout the right architecture It unlocks unique business value = Use Flash Go Faster Get Smarter + Go Faster
- 10. 10 Scale-out IOPS & Bandwidth InlineAll The Time Data Services Purpose-Built All Flash Array XtremIO: the all flash array market leader Data Reduction & iCDM Consolidation
- 11. 11 Unprecedented growth story $200 $400 $600 $800 $1,000 $1,200 $1,400 $1,600 $1,800 $2,000 1stYear 2nd Year 3th Year 4th Year 5th Year Time Since Introduction Fastest Growth 5x Nearest Array Ground Breaking
- 12. 12 65% own XtremIO OVER 3,000 UniqueCustomers #1 share, Marketscape Leader (40%) Leader in the Magic Quardrant Fortune 100 XtremIO: business momentum OVER $3B Cumulative Revenue Recent wins includes • CNA Financial Corporation • Vestas Wind Systems • Boston Red Sox • New recent release : Offer Extensive App Integration and Automated Storage Management
- 13. 13 ENABLING THE MODERN DATA CENTER Transformed byXtremIO – The World’s #1 All-Flash Array INFRASTRUCTURE APPLICATION $ BUSINESS CONSOLIDATE WORKLOADS IMPROVE BUSINESS AGILITY & INNOVATION ELIMINATE APPLICATION COPY “SPRAWL” Remove silos and get the performance and scale to run everything on a single array Enhance copy management via application integration & integrated copy data management Transform your business to be agile with Data- center-driven business innovation
- 14. 14 What does amodern all-flash system require?
- 15. 15 Workload consolidation Performance, efficiency,protection Performance Efficiency Protection
- 16. 16 Scale-out performance, capacity,IOPs for Mixed & Consolidated Workloads Workload consolidation XtremIO platform fundamentals Data Services optimize every aspect of all the workloads in-line Enhancing business continuity, protection and IT Utilization
- 17. Dell - InternalUse - Confidential17 Consistent predictable performance Performance
- 18. 18 Speed is acompetitive advantage 0.5ms LATENCY SUDDEN IMPACT! BEFORE XTREMIO – ALL HDD 7ms “Reporting Job Finished at 1:30 AM Instead Of 6:30am …now I Can Have My Life Back!”
- 19. 19 Workload: OLTP with8KB Block Size (Actual customer data ) Garbage collection kicks-in LatencyLatency Worse than Disk Latency 20-40ms Latency Spikes 2-5ms • Predictable performance with Always-on, Inline Data Services • Consistent low latency at all times with no system level garbage collection • Predictable, scalable IOPs whether the array is new or has been fully overwritten. 35TB Traditional Flash Array10TB ‘X-Brick’ XtremIO consistently outperforms traditional AFA’S Consistent performance matters
- 20. 20 Cluster building block XtremIOX-Brick Active Controller 1 Active Controller 2 Infiniband RDMA 32 CPU CORES 512 GB RAM 25 eMLC SSDs SAS 2.0SAS 2.0 2 x FC 2 x iSCSI 4 HOST PORTS 2 x FC 2 x iSCSI 256GB RAM 256GB RAM
- 21. 21 5TB – Over1PB Usable Capacity NO TUNINGSCALE-OUT RICH DATA SERVICES<1ms LATENCY © Copyright 2015 EMC Corporation. All rights reserved. XtremIO family portrait Starter 5TB From 2 – 16 N-way Active Controllers 1.2M mixed IOPS 2M read IOPS <1ms Latency 150K mixed IOPS 250K read IOPS <1ms Latency
