2. Introduction
LabVIEW is System-design platform and development environment for a visual
programming language from National Instruments.
It is programming language using graphical notation connected by nodes.
It is used for data acquisition, embedded control design, testing automation and
instrumentation control.
It provide ease for data acquisition, measurement data visualization, data
processing and analysis, parallel programming, ease of interaction between
instrumentations, data communication and ease of interaction between
communication links.
3. Anti aliasing filter
Aliasing is distortion of spectrum of signal due to less sampling rate which defines
the frequency content of signal. A high frequency signal is perceived as low
frequency signal in frequency spectrum.
