1. INTRO TO JAVASCRIPT ROBOTICS
Suz Hinton
@noopkat

2. ABOUT ME
 Technical Evangelist at Microsoft
 Open source hardware author
 Member of NodeJS Hardware Working Group

7. AGENDA
 Microcontroller boards
 Inputs and Outputs
 NodeJS on-board
 NodeJS off-board
 NodeJS as an IoT service
 Resources

8. Q: WHAT ARE MOST ROBOTS MADE OF?
A: MICROCONTROLLERS
A: INPUTS AND OUTPUTS

9. Q: WHAT ARE MOST ROBOTS MADE OF?
A: MICROCONTROLLERS
A: INPUTS AND OUTPUTS

10. Arduino Uno
Processor - ATMega328P
Speed: 8MHz
Memory: 32Kb
Language: C++
Price: $24.95 USD
Good for:
Offline, simple projects
Gotchas:
No built in internet, modules are
available

11. Tessel 2
Processor - Mediatek MT7620n
Speed: 580MHz
Memory: 32Gb flash, 64Mb RAM
Language: NodeJS, Rust
Price: $44.95 USD
Extras: built in Wi-Fi, runs Linux
Good for:
Online, processor intensive projects

12. ESP8266
Processor – 32bit Tensilica Xtensa LX106
Speed: 80MHz
Memory: 1MB Flash
Language: Lua, C++
Price: $5 USD
Extras: built in Wi-Fi, TLS capable
Good for:
Online, portable, low power projects
Gotchas:
Hard to work with

13. Q: WHAT ARE MOST ROBOTS MADE OF?
A: MICROCONTROLLERS
A: INPUTS AND OUTPUTS

14. INPUTS
‘read only’
 sensors
 switches
 data

15. INPUT EXAMPLES
 light sensor
 touch sensor
 humidity sensor
 api response

16. OUTPUTS
‘write only’
 state
 data
 movement

17. OUTPUT EXAMPLES
 LED (light)
 speaker
 motor
 data stream

18. YOU COULD MAKE…
{
precipitation: 6,
probability: 100
}

19. TECHNIQUES

20. #1 : NODEJS ON BOARD
with the Tessel2

21. $ npm install –g t2-cli
$ npm install ambient-attx4
var tessel = require('tessel');
var ambientlib = require('ambient-attx4');
var ambient = ambientlib.use(tessel.port['A']);
ambient.getLightLevel();
ambient.getSoundLevel();

22. #2 : NODEJS OFF BOARD
with the Arduino Uno

23. $ npm install –g firmata-party
$ firmata-party uno
$ npm install johnny-five
var five = require(‘johnny-five’);
var board = new five.Board();
board.on(‘ready’, function() {
var led = new five.Led(13);
led.blink(500);
});

24. #3 : NODEJS AS AN IOT SERVICE
with the ESP8266

25. IOT TIARA

26. IoT Tiara
ESP8266‘brain’
3D printed band + crystals
RGB LEDs for lighting
Controlled by chat box on twitch.tv
Connects to MQTT broker (Azure IoT Hub)
NodeJS server sends commands via broker
youtu.be/mxmfkz-kXX0

28. Azure
IoT Hub tiara
Azure
Web App
Twitch chat
IRC channel

29. Azure
IoT Hub tiara
Azure
Web App
color
picke
r.html

30. #1 : NODEJS ON BOARD
#2 : NODEJS OFF BOARD
#3 : NODEJS AS AN IOT SERVICE

31. RESOURCES
 tessel.io
 arduino.cc
 adafruit.com
 nodebots.io
 johnny-five.io
microsoft.com/en-us/internet-of-things
 github.com/noopkat/iot-tiara
