This presentation gives introduction to human auditory system and signal processing goes on in brain to deduce spatial information about the sound we hear.

1. Introduction to Spatial Auditory
Processing
Kaushik Patra
(kpatra@gmail.com)
18th
Jul, 2014

2. Objective
● Review Auditory System
● Review of what is sound?
● Understand Auditory Information Processing.
● Conclusion

3. Auditory System
● Auditory system consists of
the following components.
– External ear (Pinna, ear
canal and ear drum).
– Middle ear (3 very light
weight tiny bones named
ossicles).
– Inner ear (Cochlea, hair
cells, special nerve
called spiral ganglion)
Fig.1: Schematic of Auditory Path
Fig.2: Schematic Position of Auditory Cortex

4. Auditory System
● Spiral Ganglion nerves runs
through 8th
cranial nerve
(CN VIII) to bring
information to auditory
cortex of the brain.
– Fig. 2 shows the part of
brain in pink patch
known to be the auditory
processing centre,
auditory cortex.
Fig.1: Schematic of Auditory Path
Fig.2: Schematic Position of Auditory Cortex

5. Auditory System
● Fig. 3 shows relative amount
of cells that present in
various parts of the
auditory system.
● Most portion of the cells are
in the auditory cortex.
● Only small chunk of cells are
part of hair cells (inner or
outer – in red), sensory
neurons (in blue) and
central neurons in various
part of the path (in black
inner circles).
Fig.3: Relative Amount of Cells in
Different Parts of Auditory System

6. Auditory System
● Why do we need such a big
amount of auditory cortex
cells?
– We'll review later in these
slides on the auditory
information processing.
– We need to process for
speech interpretation
and spatial information.
– We need to process not
only the auditory signals
but also combine them
to visual information for
gaining spatial
information.
Fig.3: Relative Amount of Cells in
Different Parts of Auditory System

7. What is sound?
● Sound is a physical phenomenon of compression and
rarefaction of the medium (gas, fluid or solid) through
which energy flows from one place to another.
● It can be represented as wave in terms of air pressure with
respect to time (Fig. 4).
Fig.4: Sound Wave

8. Auditory Information Processing
● Two types of processing
– Passive processing and transformation of
sound energy
– Active processing for information extraction.
● Perception: Extraction of meaning of sound
(speech recognition, understanding of
surroundings and ambiance, etc.)
● Spatial: Direction of source, distance of the
source, etc.

9. Passive Information Processing
● Passive Processing.
– External ear canal has resonance of same frequency as the human speech. Thus
is increases volume of the sound inside the ear canal.
– Middle ear transform the vibration in air into the vibration of fluid inside the cochlea.
The ossicles connects tympanic membrane of external ear to the oval window
membrane of cochlea. The bone hammers the oval window membrane with
same frequency as the incoming sound. The energy level is decreased partially
during this conversation.
– Inner ear transform vibration energy into electrical pulses along the nerve cell
inside cochlea and transmit it to the brain. In concept Fourier transformation is
done on the incoming vibration (i.e. transforming time domain signal into
frequency domain signal).
External
EarSound
wave
Sound
Wave with
increased
volume
Middle
Ear
Internal
EarAir to fluid
Vibration
transmission
BrainElectrical
Pulses
through
transduction

10. Direction Information Processing
● Unlike visual information, audio
information does not produce any
image, thus it is much more
challenging to deduce spatial
information out of sound.
– Spatial information is computed.
● Location of sound source is computed
using interaural time delay (ITD).
– Sound travels more path to far ear.
– As sound source is located far
toward the side, this difference in
distance increases.
– With a ear-to-ear distance of 140cm
the ITD can be computed as
0.41ms.
– ITD is too small to be computed by
action potential (electrical
pulses) of the auditory neuron.

11. Direction Information Processing
● ITD is computed using differential neurons
where neurons from both side ears connect
to the differential neurons.
– Two set of differential neurons, where one
is set is located near left ear and other
set is located near right ear.
– There will be time difference reaching
sound signals onto these differential
neurons.
– Combining information generated out of
these differential neurons can infer the
direction of the sound source.
● Not only ITD, but sound level is also used to
infer sound source direction (Interaural
Level Difference or ILD).
– Sound coming from one side will create
acoustic shadow into the other ear.
– Volume will be less in this acoustic
shadow location.
– Difference of the volume will be more as
the the sound source moves further
from the centre.

12. Direction Information Processing
● ITD and ILD provides horizontal information
only.
– This produces cone of confusion.
– Cone of confusion is created by the
positions of sound source which
produces same amount of ITD and
ILD.
– Confusion can be created either at
vertical dimension or front/back.
● We solve cone of confusion by two ways.
– Using head movement.
– Using sound frequency.

13. Direction Information Processing
● Front/back confusion is resolved by moving
head.
– 'A' position in the picture produces same
ITD and ILD.
– We move our head to position 'B' to make
different ITD and ILD and resolve
front/back confusion.
● Similarly, vertical confusion is resolved by
tilting of head.
– Head tilt creates different ITD and ILD,
hence we can resolve confusion.
● These technique requires longer sound so that
we can react to compute direction by head
movement.
● Direction information processing also needs to
process amount of signal that produced
active head movement.

14. Direction Information Processing
● We also process incoming sound wave
information with its spectral cues.
● Sound is not a simple sin wave, it is much
complex than that.
● Any complex wave can be expressed as a sum
of the simple sin waves with different
frequency and amplitude.
– In mathematical term this transformation is
called Fourier transformation.
● The plot of Amplitude vs. Frequency for a
sound wave is called spectrum of the
sound.

15. Direction Information Processing
● We do Fourier transformation inside our ear.
– Location at cochlea.
– Timing of the action potential.
● The Basilar membrane in cochlea has a
resonance gradient along the length.
– Towards outer direction it resonate to
higher frequency and towards the
centre it resonate with lower
frequency.
– Corresponding hair cells along the basilar
membrane will produce more action
potentials according to it's frequency
resonance.
● Scraping of hair cells against tectorial
membrane causes opening of ion channels
in the sensory cells, which creates the
action potentials (electrical pulse).
– This opening is synchronized (phase
locked) with the frequency of the
incoming signal. Hence the action
potential has same frequency as the
incoming sound wave.

16. Direction Information Processing
● Sounds are first filtered by the external ear's pinna.
– The little folds in the ear lobe or pinna causes alteration of energies at different frequencies.
– The filtering is direction dependent.
● Different frequencies of same amplitude for a sound coming from same location ends up
having different amplitude after the filtering done by pinna.
● Filtering is also direction dependent.
– Same sound wave from different direction ends up attenuated differently.
– This constructs spectral cue.
● Using spectral cue, we are also able to deduce sound source direction.

17. Direction Information Processing
● Sound itself is not a very strong cue to identify the direction.
● To confirm our deduction to the location we also depends on
the visual cue.
– For example, even if the speech comes from speaker in movie
theater, we perceive that the actor / actress is talking and sound
is coming from their mouth (by observing there lip movement).
– Ventriloquism uses this visual cue association of sound to make
the puppet appeared to be talking while the puppet master is
talking without moving his/her lips.
– We also move our head to look for a plausible source of sound
comparing the sound with our prior knowledge of origin of
similar sound.

18. Distance Information Processing
● Distance is computed using two factors.
– Loudness
– Echos
● Sound loudness diminishes with distance.
● We uses loudness information to deduce the distance of the
sound source.
– Thus this works better with familiar sound.
– Familiar sound level can be compared easily with our prior
knowledge about the loudness of the sound and distance stored
in our memory.

19. Distance Information Processing
● One 'first principles' distance cue is the
delays of echoes associated with that
sound.
– This does not need any prior
knowledge about the sound.
● Our auditory environment acts as a
'auditory hall of mirror' where sound
bounces off every other surfaces in
the environment we are hearing the
sound.
● Time difference between principle sound
and its echo gives cue to the source
distance.
– If the distance of the source is large
(like the top picture) the
difference is smaller.
– If the distance of the source is small
(like the bottom picture) the
difference is larger.

20. Conclusion
● Spatial information processing for sound is complex
involving multilevel signal transformation.
● It involves both audio and visual processing.
● It also depends on physical phenomenon like echo.
● It involves prior knowledge about sound (loudness).

21. Acknowledgement
● Most of the figures have been taken from:
– Coursera course on 'Neurobiology in Everyday
Life'.
– Coursera course on 'Brain and Space'
– Wikipedia
● Auditory Cortex (
http://en.wikipedia.org/wiki/Auditory_cortex)
