2. 2 Market Position Water Solutions® is the viable alternative for rental or permanent water treatment solutions. Water Solutions - making water pure with a clearly uncomplicated™ approach. 2
8. What We Offer Engineered Solutions Designed with end-user experience Fabricated to last decades Streamlined Processes Proven Technologies Process Water Produced Water Waste Water Desalination 6
16. Processes Balancing Cost and Risk Data collection to diagnose the issues Conceptual engineering to prescribe a solution Pilot evaluations to validate a solution Detailed engineering to refine the solution 3-D modeling to reveal obscure details Start-up to insure performance and a smooth transfer Training and O&M to maintain continued performance 9
18. Produced Water Steam Flood / Discharge Water Use Steam Source? Produced Water Flotation – Oil Removal Unit / API Separator Induced Gas Flotation Walnut Shell Filter Water Flood High Silica? Yes Lime Softener Slop Oil No Steam Flood SAGD Steam Flood SAGD Boiler Evaporator Once thru Steam Generator Anthracite Filters Surface Discharge or Reuse RO Filters Ion Exchange
19. Process Water Raw Water Feed Condensate Polishing Suspended Solids Removal Cartridge Filtration Membrane Separation Demineralization Hardness Removal Ion ExchangeSoftening Filtration Deareator Blowdown Treated Water to Process Operations Cooling Tower Makeup Condensate Return Blowdown CW Supply CW Return
20. Waste Water Biological Treatment Post Biological Clarification Waste Water Treatment Influent Primary Oil / Water Separation Secondary Oil / Water Separation Incineration Incineration Sludge Dewatering Permitted Effluent Discharge Tertiary Treatment Reuse Zero Liquid Discharge Solid Waste Disposal
21. Desalination 14 Secondary Filtration is optional Salt Water Supply Primary Filtration Secondary Filtration Low Pressure Membrane High Pressure Membrane Degasification Chemical Treatment Cation/Anion Filters For Use For Use For Use Mixed Bed Filters
29. Why choose Water Solutions? Responsive Broad skill set and knowledge about water treatment processes 40+ years experience in building water treatment solutions International reputation for delivering on-time and on-budget In-house fabrication facilities Fast, flexible and friendly 22
