The document discusses Docker, Docker Machine, Docker Swarm, and how to build a scalable system using these technologies. It describes Docker as a way to package applications and dependencies into containers. Docker Machine allows creating Docker hosts on local computers, cloud providers, or data centers. Docker Swarm provides native clustering for Docker. The document outlines processes for creating a Swarm master and agents and shows how to design an architecture using Docker Gen to generate configs, Nginx as a reverse proxy, and NodeJS applications running in containers.

1. #dfist#dfist
Infinite Scalable Systems with
Docker
Huseyin BABAL
Full-Stack Software Engineer @ GittiGidiyor

2. #dfist#dfist

3. #dfist#dfist
Docker

4. #dfist#dfist
What is Docker
Docker lets you to package application with its dependencies like code,
runtime, system libraries, etc. inside one container

5. #dfist#dfist
VM vs Docker
Infrastructure Infrastructure
Host OS OS
Hypervisor Docker Engine
Guest OS Guest OS Guest OS
bins/libs bins/libs bins/libs
app1 app2 app3
bins/libs bins/libs bins/libs
app1 app2 app3

6. #dfist#dfist
Docker Machine

7. #dfist#dfist
What is Docker Machine?
Docker Machine lets you to create Docker host
and specific client to connect Docker on local
computer, cloud providers, even in your own
data center.

8. #dfist#dfist
Creating Docker Machine
docker-machine create -d virtualbox default

9. #dfist#dfist
Docker Swarm

10. #dfist#dfist
What is Docker Swarm?
Native clustering for Docker

11. #dfist#dfist
Howto Create Swarm?
SID=docker run swarm create
$SID will be used on clustering

12. #dfist#dfist
Master Create
docker-machine create
-d virtualbox
--swarm
--swarm-master
--swarm-discovery token://$SID
swarm-master

13. #dfist#dfist
Agent Create
docker-machine create
-d virtualbox
--swarm
--swarm-discovery token://$SID
swarm-agent-00

14. #dfist#dfist
Swarm Master Process

15. #dfist#dfist
Swarm Agent Process

16. #dfist#dfist
Swarm Relay Network

17. #dfist#dfist
Architectural Design

18. #dfist#dfist
Components
docker-gen Image
Nginx
NodeJS Application

19. #dfist#dfist
Docker Project

20. #dfist#dfist
docker-gen Image
Generates files from docker container metadata
● Centralized Logging
● Log Rotation
● Reverse Proxy Configs
● Service Discovery

21. #dfist#dfist
How to Build?
docker build -t docker-gen ./docker-gen

22. #dfist#dfist
How to Run?
docker run -d --restart=always --name=docker-gen
--env=affinity:image==docker-gen:latest
--env=DOCKER_HOST=tcp://192.168.99.103:3376 docker-gen

23. #dfist#dfist
Nginx

24. #dfist#dfist
How to Run?
docker run -d --restart=always --name=nginx -p 80:80 --
volumes-from=docker-gen nginx

25. #dfist#dfist
http {
upstream api.nodejs.com {
server 192.168.99.100:5001;
server 192.168.99.100:5002;
}
server {
listen 80;
location / {
proxy_pass http://api.nodejs.com;
}
}
}

26. #dfist#dfist
NodeJS Application

27. #dfist#dfist
How to Run?
docker run -d --restart=always -p 3000 --name hello-
express-1 -P --env VHOST=api.nodejs.com
huseyinbabal/express-hello

28. #dfist#dfist
Load
Balancer
swarm-agent-01
swarm-agent-02
swarm-master
Docker
Gen

29. #dfist#dfist
Show Time!
You can clone project here

30. #dfist
Thank you!
Questions?Questions?
@huseyinbabal
+HüseyinBABAL
http://huseyinbabal.net
