4. "10+ Deploys Per Day: Dev & Ops Cooperation at Flickr”
(https://www.youtube.com/watch?v=LdOe18KhtT4&ab_channel=O%27Reilly)
개발(develop)과 운영(operation)의 분리로 소통비용이 발생하는 것을 막기 위하여,
개발팀과 운영팀을 긴밀하게 묶고, 통합/자동화/측정/공유하는 문화를 만드는
개발 방법론
0. 앞서서
5. “1. 라우터, 스위치, 케이블 등의 네트워크,
2. 데이터 센터, 서버 컴퓨터 등의 하드웨어,
3. OS, 웹서버, 미들웨어 등의 소프트웨어를 일컫는다”
Red Hat
IT Infrastructure란?
0. 앞서서
8. 인프라스트럭쳐를 다루는 기존의 방식
from 테라폼 도입기 클라우드 인프라스트럭처 코드로 재정의하기 - 김대권
1. Server Scripting
스크립트 자동 실행
2. Configuration Management
서버 상태 관리
3. Resourcement Management
리소스 정의
-> python manage.py collectstatic
python manage.py migrate
sudo service uwsgi restart
sudo service nginx restart
1. IaC란?
10. 배포날…
• 아무리 열심히 기능개발을 해도, 배포
날만 되면 깨지는 서버
• 배포날 퇴근 시간은 없다.
• 열심히 관리해놓아도, 업데이트 한번
했다가 의존성 깨지면 롤백하느라 한
세월
• 업데이트는 절대 하지 않는다
2. 왜 IaC인가
11. 인프라 관리 메뉴얼을 만들라고?
• 열심히 PPT에 그림 갖다붙이며 관리
메뉴얼 만들어놓고 인수인계, 공유했
는데…
• 콘솔 화면을 업데이트했네..?
• 누가 버튼을 잘못눌러서 뭘 바꿔놨는데, 뭘 바꿔
놨는지도 모르겠네..?
2. 왜 IaC인가
12. 2. 왜 IaC인가
• 과거의 On Premiss 환경에서는 IaC가 옵션
• 하드웨어를 이용해 다룰 수 있었음
• 서버를 관리하는 전문 관리자의 수도 많았음
• 그러나, 클라우드 환경에서 IaC는 필수
• 하드웨어가 없어 모든 것을 소프트웨어로 다루어야함
• 소프트웨어를 코드로 배포하는 방법에 익숙해져야만 함
16. 1. Provisioning Tool
리소스 정의 및 구성(아키텍쳐 구성)에 사용되는 툴
• 기존의 템플릿형
• AWS CloudFormation, MS Azure Resource Manager, Google Cloud
Deployment Manager
• YAML, JSON 등을 통해 infra를 템플릿으로 저장하여 구성 가능
• 각자 자기 플랫폼만 지원 내가 다 해먹고싶다!
3. IaC 툴 비교하기
17. 1. Provisioning Tool
리소스 정의 및 구성(아키텍쳐 구성)에 사용되는 툴
• Terraform
• 업계 골목대장
• 멀티 provider 플랫폼 지원(국내에는 네이버도 있음)
• HCL(Hashicorp Configuration Language)라는 전용 DSL(Domain Specific
Language) 지원
• plan, apply 명령어로 immutable한 infra state 정의
3. IaC 툴 비교하기
19. 1. Provisioning Tool
리소스 정의 및 구성(아키텍쳐 구성)에 사용되는 툴
• AWS CDK
• AWS CloudFormation을 기반으로 만든 AWS의 프로비져닝 툴
• YAML, JSON 대신 TS, Python, .Net, JAVA 지원
• AWS 플랫폼 종속적
3. IaC 툴 비교하기
20. 1. Provisioning Tool
리소스 정의 및 구성(아키텍쳐 구성)에 사용되는 툴
• Pulumi
• 멀티 provider 지원
• Terraform에 비해 이용자가 적지만, 점점 주목받고 있는 툴
• Python, Go, JS/TS 등 다양한 언어를 지원해서, 비교적
낮은 러닝커브로 개발자들이 인프라 구성을 시도할 수 있음
• Terraform 처럼 immutable state 지원
3. IaC 툴 비교하기
21. 2. Configuration Management Tool
서버 환경 구성
• 생성(provisioning)된 서버 시스템 위에서 사용됨
• 여러 개의 서버 사이의 환경을 구축하고, 소프트웨어를 설치/업데이트하기위해
사용
• 다수의 서버와 다양한 환경(OS 등)을 지원
3. IaC 툴 비교하기
22. • Ansible
• CM tool의 업계 1위
• Red Hat에서 인수하여 관리중
• python으로 구현됨
• YAML 사용
3. IaC 툴 비교하기
2. Configuration Management Tool
서버 환경 구성
23. • CM tool과 다르게, 한 대의 machine 내부에서 동작함
• Container형과, VM형이 있음 -> DevOps 직군의 단골면접질문!
• 서버 상태를 코드로 남기고, 이를 Image로 템플릿화
• 결국, OS 등의 machine 환경에 구애받지 않고 완전히 동일하게 app 동작 가능
• ubuntu에서는 됐는데, CentOS에서는 안되네.. <- 이런 경우를 차단
3. IaC 툴 비교하기
3. Server Templating Tool
서버의 상태를 이미지로 관리
24. • Docker
• 컨테이너계의 표준(최근에 CRI 문제로 k8s가 docker를 deprecating한다고 하긴 했지만..)
• 스크립트로 구성된 Docker File을 이용해 Machine Image를 생성
• 생성된 이미지를 토대로 컨테이너를 돌림
• Orchestration Tool로 Docker Swarm이 있지만, 업계 표준은 Kubernetes라
k8s와 더 많이 사용됨
3. IaC 툴 비교하기
3. Server Templating Tool
서버의 상태를 이미지로 관리
26. • Packer
• Terraform을 만든 Hashicorp 사의 제품
• Machine Image를 생성하는 역할만 수행
• Docker Script를 배울 필요 없이, JSON만으로 이미지를 구성할 수 있다는
점이 좋음
3. IaC 툴 비교하기
3. Server Templating Tool
서버의 상태를 이미지로 관리
27. • Vagrant
• Virtual Machine 프로비져닝 자동화 툴
• Vagrant file를 작성하여
VM Box의 세부 설정 가능
• Container형의 우세로 최근에는 사용빈도 하락
3. IaC 툴 비교하기
3. Server Templating Tool
서버의 상태를 이미지로 관리
