How to Design Integrated Control and Information System Architecture Across Largescale Critical Infrastructure

The document outlines the design of integrated control and information systems (IACS) for large-scale critical infrastructures across various domains such as electrical utilities, water, telecommunications, and oil & gas. It discusses infrastructure layers, ownership models, evolution trends, and provides examples of implementation for sectors like petroleum and electricity markets. Key trends include the convergence of IT and operational technology (OT), edge computing advancements, and the integration of digital business platforms.

Embed presentation

Downloaded 19 times
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 1 How to Design Integrated Control and Information System Architecture Across Largescale Critical Infrastructure e-mail: ahmam1@emirates.net.ae LinkedIn: https://ae.linkedin.com/in/Alaa-Mahjoub By: Alaa Mahjoub Data Management Senior Expert
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 2 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 3 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 4 LARGESCALE CRITICAL INFRASTRUCTURE DOMAINS - Electrical Utilities • Power Transmission • Power Generation • Power Distribution - Water • Water production • Water Transmission • Water Distribution - Telecom • Fibber Optics Transport • Microwave - Transportation • Rail (Railway, Rolling Stock, Stations) • Busses • Traffic control - Municipalities • Sewage stations • Sewage pipelines - Oil & Gas • O&G Pipelines • Oil terminals • Refineries
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 5 LEVELS OF LARGESCALE CRITICAL INFRASTRUCTURE - Enterprise - Corporate - National - Regional - International - Electrical Utilities - Water - Telecom - Transportation - Municipalities - Oil & Gas
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 6 OWNERSHIP AND OPERATION MODEL - Government - Private Sector - Hybrid - Government - Private Sector - Hybrid ASSET OWNER SYSTEM OPERATOR Asset owner can operate the asset by itself or fully or partially outsource the operation to somebody else
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 7 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 8 Telecom Network- Power Transmission Grid - Gas Pipelines Network Transportation Network (Railway) EXAMPLES OF NATIONAL LEVEL CRITICAL INFRASTRUCTURE NETWORKS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 9 UAE Emirates National Grid Interconnections 2000 to 2006 2003  GCC Grid Interconnections EXAMPLES OF NATIONAL & REGIONAL LEVEL CRITICAL INFRASTRUCTURE NETWORKS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 10 EXAMPLES OF INTERNATIONAL LEVEL CRITICAL INFRASTRUCTURE NETWORKS EU Energy Network European High Voltage Transmission Grid
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 11 O&G Export Network from Russia Europe EXAMPLES OF INTERNATIONAL LEVEL CRITICAL INFRASTRUCTURE NETWORKS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 12 THE PLANET MEGA INFRASTRUCTURE The Connectivity Atlas: https://atlas.developmentseed.org/
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 13 ELECTRICITY NETWORKS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 14 RAILWAY NETWORKS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 15 GLOBAL SUBWAY MAP  POTENTIAL GLOBAL HYPERLOOP?
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 16 O&G NETWORKS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 17 TELECOM NETWORKS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 18 Navigate the Mega Infrastructure with the Harvard World Map of connectography https://worldmap.harvard.edu/maps/connectography MEGA-INFRASTRUCTURE WORLDWIDE
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 19 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 20 LAYERS OF CRITICAL INFRASTRUCTURE Human Operation Layer IACS Cyber Layer Physical Layer - People & Process (People use information to manage the physical and cyber layers) - Computers, networks, IACS Software and data gathering sensors used to monitor and control the physical layer - Physical Assets (Vertical Industry Dependent )
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 21 EXAMPLE 1: TRANSMISSION SYSTEM OPERATOR CRITICAL INFRASTRUCTURE Electricity Market Evolution Vertically Integrated Style of Ownership & Control Horizontally Integrated Style of Ownership & Control with Integrated SO & TO (TSO) Separate SO and TO (ISO) Support of DSO Model? SO … System Operator TO … Transmission Asset Owner TSO … Transmission System Operator ISO … Independent System Operator
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 22 (The Operations Perspective) IACS Cyber Layer Human Operations Layer Physical Layer Electricity Network TSO Telecom Network Civil Infrastructure Facilities etc Transformers Breakers TX Lines etc Wireless (e.g. WiMax) Multiplexers (e.g. SDH) Cables (e.g. OPGW) etc Control Centers / DR Centers Administration Buildings Substations Telecom equipment Status and Monitoring / etc Breaker Status / Control Signals Access Control / Fire Fighting/ AC/ Ventilation Control / Surveillance Power flow / Energy Readings etc RTUs / Meters / SCMS / PLC PCNs Supervisory Stations Recovery from Failures, etc. Energy Management Security Enforcement Monitoring & Control of Cyber and Physical Layers TSO CRITICAL INFRASTRUCTURE
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 23 (The IT Perspective) TSO CRITICAL INFRASTRUCTURE IS/IT Layer Human Layer Physical Layer HRMS / Financial … Electricity Network Telecom Network Civil Infrastructure Facilities Other Enterprise Assets Internet Access KMOffice Automation EmailGISCMMSERP etc Maintenance Tools Non Operational Equipment Vehicles Information & Collaboration Services … Computers IT Networks IT Applications Operations-Staff … Employees Non-Operations Staff Managers
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 24 Human Layer Enterprise Information Architecture Layer Physical Layer Electricity Network Telecommunications NetworkCivil Infrastructure Facilities Other Enterprise Assets IACS Cyber Layer Operations Staff Non-Operational Staff Integration with customers and ecosystem EPM BI/RT OI/ BDA Enterprise-wide Business Process Management MDM/MEM/DW/ECM Enterprise Asset management Telecom for IACS Cyber Layer & IS/IT Layer TSO-wide Integrated Perspective = Operations Perspective + IT Perspective TSO CRITICAL INFRASTRUCTURE Customers, Ecosystems & IoT IS/IT Layer Partners’ IACS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 25 EXAMPLE 2: PETROLEUM INDUSTRY UPSTREAM OPERATOR CRITICAL INFRASTRUCTURE Petroleum Industry Upstream O&G Operator Business Value-chain Model 1- Licensing 2- Exploration 3- Appraisal 4- Development 5- Production 6- Delivery 7- Abandonment
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 26 (The Operations Perspective) IACS Cyber Layer Human Operations Layer Physical Layer Petroleum Industry Assets, Surface & Subsurface Facilities Civil Infrastructure Facilities etc Flow lines & Pumping Units Power System and Telecom System Reservoirs, Wells, Surface & subsurface Facilities etc Control Centers / DR Centers Administration Buildings Fields Constructions Communications infrastructure Status and Monitoring / etc Valves Status / Control Signals Access Control / Fire Fighting/ HVAC / Surveillance Oil Flow / PVT Readings etc RTUs / Meters / PLC / DCS PCNs Supervisory Stations Recovery from Failures / etc Security Enforcement Operations staff: Monitoring & Control of Physical and Cyber Layers Production Management PETROLEUM INDUSTRY UPSTREAM OPERATOR CRITICAL INFRASTRUCTURE
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 27 PETROLEUM INDUSTRY UPSTREAM OPERATOR CRITICAL INFRASTRUCTURE (The IT Perspective) Information Systems Layer Human Layer Physical Layer HRMS / Financial … Petroleum Industry Assets, Surface & Subsurface Facilities Civil Infrastructure Facilities Other Enterprise Assets Internet Access KMOffice Automation EmailGISCMMSERP etc Maintenance Tools Non Operational Equipment Vehicles Information & Collaboration Services … Computers IT Networks IS Applications Operations-Staff … Employees Non-Operations Staff Managers
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 28 Corporate-wide Integrated Perspective = Operations Perspective + IT Perspective Human Layer Enterprise Information Architecture Layer Physical Layer Petroleum Industry Assets, Surface & Subsurface Facilities Telecommunications Network Civil Infrastructure Facilities Other Enterprise Assets IACS Cyber Layer Operations Staff Non-Operational Staff Customers, Ecosystems & IoT PETROLEUM INDUSTRY UPSTREAM OPERATOR CRITICAL INFRASTRUCTURE Telecom for IACS Cyber Layer & IS/IT Layer Integration with customers and ecosystem EPM BI/RT OI/ BDA Enterprise-wide Business Process Management MDM/MEM/DW/ECM Enterprise Asset management Non-operational Information operational Information Enterprise Information (Operational + Non- Operational Other Organizations’ IACS IS/IT Layer
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 29 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 30 PETROLEUM INDUSTRY UPSTREAM OPERATOR CRITICAL INFRASTRUCTURE Enterprise Communications Petroleum Industry Operator Architecture Technology Domain Cyber Critical Infrastructure Business Domain IACS IS/IT
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 31 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 32 EVOLUTION TRENDS 1. Edge Computing 2. Integration with Business Intelligence, Realtime Operational Intelligence and Big Date Analytics 3. Integration with Digital Business Platforms 4. Convergence in Cyber Critical Infrastructure Components and their Supporting Organizational Models (OT, IT , Telecom) 5. Leveraging of Mobility, Cloud Computing and Social Media 6. Digital Twins, AR and ML 7. Open IACS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 33 1- Augmenting IACS Systems with Realtime Operational Intelligence systems with Edge Computing Capabilities Realtime Drilling/Production Operation Center Drilling / Production Platforms Telecommunication between Fields and Operation center The solution is based on Complex Event Processing hub and spoke architecture IACS System IACS System IACS System Edge Computing EVOLUTION TRENDS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 34 EVOLUTION TRENDS 2- Augmenting IACS Systems with BI, Realtime Operational Intelligence and Big data Analytics 34 DB Consolidation Server(s) DW (Dedicated Repository) Archival Sector Analytics Applications … System 1 System N DB 1 DB N … Metadata Management DI Tools (e.g. ETL) ILM Fields HQ Real-time Production Data Real-time Drilling data DTS data WITSML Server(s) (Drilling) OPC Server(s) (production) Field’sData Acquisition Equipment IACS / DCS/ WITSML Data Source(s)/ PRODML Data Source(s) PRODML Server(s) (DTS) Alerts CEP & BAM WITSML Server(s) PRODML Server(s) OPC Server(s) … Integrated Sector Metadata Repository Integrated Sector DB II- Operational Intelligence III- Big Data Analytics Business Intelligence Platform / tools Data Federation / Virtualization Platform I - Business Intelligence Master Data Transactional, Operational & Analytical Data Meta Data CEP: Complex Event Processing BAM: Business Activity Monitoring ILM: Information Lifecycle Management OPC: OLE for ProcessControl DTS: DistributedTemperature Sensing DCS: Distributed Control Systems Master Data Management Platform DistributedProcessingCluster (e.g.HADOOP) Interactive Sector System M System N+1 System N+2 Database Database Database Database DB Consolidation Real-time Data Replication In-Memory Database Logical Data warehouse Backend Drilling Realtime Operation Centre Backend Production Realtime Operation Centre LDW : Logical DataWarehouse
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 35 EmployeesCustomers Things Ecosystems Platform IoT Platforms Data & Analytics Platform Information Systems Partners Customer Experience Platform EVOLUTION TRENDS 3- Integration with Digital Business Platform (example from transportation industry) IACS Runs the core business applications, back office applications, infrastructure applications, endpoint device applications and operational technology applications IT Run the customers and citizens facing applications such as customer portals, B2C and B2B Connects physical assets (Things) such as Busses, Taxis and Traffic Signals for monitoring, optimization, control and monetization Supports the creation of, and connection to, external ecosystems, marketplaces and communities relevant to the transportation agency business such as government agencies, smart cities, credit card networks, police, ambulance, etc. Contains the Data Management and Analytics tools and applications
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 36 EVOLUTION TRENDS 4- Convergence in Cyber Critical Infrastructure Components and Organization Models (Telecom, OT, IT) - IT/OT Convergence - IT/OT Integration - Organization Model Convergence - Telecommunications Infrastructure Integration and Service Convergence
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 37 Operational technology is the hardware and software that detects or causes a change of state through the direct monitoring and/or control of physical devices, processes and events in the enterprise. The IT and OT convergence brings the two worlds together to deliver new levels of decision support, by putting a business context on various data streams comes from the IT world, while the use of embedded and proprietary systems to capture and distribute machine/operations data comes from the OT world. 1 4.1. IT / OT Convergence 1 On Gartner, Inc. IT Data Streams OT Data Streams New Level of Decision Support
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 38 IT/OT integration is … … the end state sought by organizations (most commonly, asset-intensive organizations such as O&G and Utilities) where instead of a separation of IT and OT as technology areas with different areas of authority and responsibility, there is integrated process and information flow 4.2. IT / OT INTEGRATION Information Technology Operational Technology Integrated Process & Information Flow Business Outcomes
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 39 4.3. ORGANIZATION MODEL CONVERGENCE Example: Organizing for the TSO Cyber Critical Infrastructure Enterprise Communications TSO Architecture Technology Domain Cyber Critical Infrastructure Business Domain IACS IS/IT
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 40 4.3. ORGANIZATION MODEL CONVERGENCE Example: Organizing for the TSO Cyber Critical Infrastructure Organizational FAQs! 1. Who’s right in the fight for control system security? The IT or the IACS? 2. How can the IT securely connect to the IACS? 3. Will the Telecommunications report to the Real-time Operations, the Control Centre Manager, or to the TSO high management? 4. Will the IACS report to the Control Centre or to the IT? 5. Can the IT report to the IACS? 6. Which organization scenario is ideal for the IACS & the IT to better serve the enterprise asset management requirements? 7. Telemetry, is it better to be with the Financial Settlement Department, the Control Centre, the IACS or the Telecommunications? 8. The Substation Control System (SCS) and modern RTUs in the substations, it is better to be with a separate Tele-control team, with the IACS or with the protection department? 9. Is it better to outsource the whole IT & control systems infrastructure? 10. Which organization scenario of all of these is best for safeguarding the TSO critical infrastructure?... !!!
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 41 4.3. ORGANIZATION MODEL CONVERGENCE Example: The TSO Cyber Critical Infrastructure is the TSO Digital Nervous System TSO Digital Nervous System TSO control and information architecture ‘digital nervous system’ Enterprise Information Architecture Layer Telecommunications Network IACS Cyber LayerIS/IT Layer
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 42 Analogy Enterprise Information Systems Cyber Control Systems Telecommunications Network External world Corporate IT Systems Data Input & reporting Field Equipment: Meters, SCS, PLC, RTU, DCS, etc Actuators (Relays / Tap Changers) Process Sensors (CT/VT) Spinal cord & peripheral Nerves Human Senses Muscles 4.3. ORGANIZATION MODEL CONVERGENCE Example: The TSO Cyber Critical Infrastructure is the TSO Digital Nervous System Autonomic & Somatic Nervous System Brain
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 43 4.3. ORGANIZATION MODEL CONVERGENCE TSO Cyber Critical Infrastructure – Business Capability Model Enterprise Information Management Computer System Infrastructure Information & Collaboration Services & Apps. Operational Technology (SCSDA- Metering – SCS- RTU, PLC, DCS) Telecom Network Management Network operation Enterprise Architecture Digital Business Capabilities Business Architecture Information Architecture Apps. Architecture Tech. Architecture Sourcing Management Resource Management Cost & Revenue Management Stakeholder Engagement Technical Support - Business Capability model is used to integrate strategy with Execution - It is also used with the Operating Model as a thinking tool to support the development of new organizational structures The Change
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 44 4.3. ORGANIZATION MODEL CONVERGENCE TSO Cyber Critical Infrastructure – Business Capability Model Enterprise Information Management Computer System Infrastructure Information & Collaboration Services & Apps. Operational Technology (SCSDA- Metering – SCS- RTU, PLC, DCS) Telecom Network Management Network operation Enterprise Architecture Digital Business Capabilities Business Architecture Information Architecture Apps. Architecture Tech. Architecture Sourcing Management Resource Management Cost & Revenue Management Stakeholder Engagement Technical Support - Business Capability model is used to integrate strategy with Execution - It is also used with the Operating Model as a thinking tool to support the development of new organizational structures The Change Digital Business Create new Business Models Analyse Customers & Partners Manage Ecosystem Players Manage Contextual Information Design & Implement Digital Services Formulate Digital Business Strategy
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 45 Communication Network (Infrastructure) Media / Waves Fiber optic cables Cupper twisted pair Wireless broadband SatelliteMicrowave Wireless Mobile Telecom Communication Services Equipment Network management Fiber Switch/Mux LAN switches Router Firewall IDS Equipment Network management Fiber Switch/Mux LAN switchesRouter Firewall IDS Site X Site Y Voice VoiceFax FaxVideo Video Real Time Monitoring & Control Real Time Monitoring & ControlData Data 4.4. CONVERGENCE IN ENTERPRISE NETWORKING & COMMUNICATIONS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 46 4.4 COMMUNICATION NETWORKS CONVERGENCE Communication Networks Convergence is defined where common standards allow several types of networks to connect to each other. Consequentially, communication services can travel over any combination of network Voice Communication Network Data Communication Network IACS Communication Network Example
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 47 4.4 COMMUNICATION SERVICES Convergence Communication Services Convergence is defined where a single communication network is used to provide several communication services that traditionally required several networks Single Communication Network Several Communication Services Site X Site Y Voice VoiceFax FaxVideo Video RT Monitoring & Control RT Monitoring & Control Data Data
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 48 4.4 UNIFIED COMMUNICATIONS Unified communications (UC) describes … … the Convergence and integration of non real-time communication methods and technologies such as messaging (voicemail, e-mail, SMS and fax) with real-time communication methods and technologies such as instant messaging, presence information, IP telephony, video conferencing, web conferencing, call control and speech recognition and with other business applications.
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 49 5. LEVERAGING OF MOBILITY, SOCIAL MEDIA AND CLOUD COMPUTING High level Technical architecture SMS/ Social Can be deployed as: - in premises - Public cloud - private cloud - community cloud
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 50 5. LEVERAGING OF MOBILITY, CLOUD COMPUTING AND SOCIAL MEDIA 5.1. Leveraging Enterprise Mobility Database tier (Back-end) - Notification Messages Database Applications tier (business logic) IACS tier - SMS Dispatcher module - Email Dispatcher module - Messages Data Loader module -Administration module Email ServerSMS Server (web-based) Terminal Service server 1 - Message Composer module - MNS Subscription module Terminal Service server 2 - Message Composer module - MNS Subscription module Web server 1 Web server 2 IVR Server IACS ServersMetering Servers Dispatch Systems Servers Web tier (front-end) IVR Server IVR web server TTS Engine ASR Engine Telephony Services IVR Application IVR configuration database IVR configuration data Application Server Custom-made in-house Developed Applications Central Database Servers SCSDA/EMS, Metering & Dispatching Servers Technical architecture of Mobile Users Notification System (MNS)
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 51 6. LEVERAGING OF MOBILITY, CLOUD COMPUTING AND SOCIAL MEDIA 5.1. Leveraging Enterprise Mobility Conceptual Data Model of Mobile Users Notification System (MNS) User Subscription Message Category Message-User Link
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 52 6. Digital Twins AR and ML Digital Twin: Turbine generated power, health and wind sapped are displayed
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 53 7. Open IACS Open Standards such as OPC UA, OPA and CIM help implementing: - better IACS System to SCATA System Interoperability - better integration with the IT and application worlds OPA forum initiative was initiated by ExxonMobil and managed by The Open Group, this initiative aims to build a proof-of-concept prototype, establish standards for, and ultimately build commercial open process automation systems that minimize vendor-specific technologies and increase overall return on system investment http://www.opengroup.org/open-process-automation
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 54 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 55 ARCHITECTURE DEVELOPMENT METHOD Technology Architecture Information Architecture Business Architecture Application Architecture 1. Establish vision 2. Formulate Strategy 3. Assess the As-IS IACS & IS system architecture including: A. Business Architecture B. Data/Information Architecture C. Application Architecture D. Technology Architecture E. Security Architecture 4. Develop the To-Be IACS & IS system architecture including: A. Business Architecture B. Data/Information Architecture C. Application Architecture D. Technology Architecture E. Security Architecture 5. Identify opportunities and gaps 6. Develop Transition Architectures 7. Establish Implementation Governance 8. Change Management SecurityArchitecture
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 56 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 57 Example 1: ENTERPRISE NETWORKING & COMMUNICATIONS FOR PETROLEUM INDUSTRY INTEGRATED OPERATIONS Physical Layer Cyber Layer Human Layer Integrated Operations is commonly used to describe the new operating model which has been optimized for the businesses of oil industry operators and facilitated by new information, communication and real-time process control technology
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 58 ENTERPRISE COMMUNICATIONS VISION Vision: Connected Enterprise… … From the Wells to the Terminals
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 59 Enterprise Business Context General Business Context Digital Business Context Enterprise Business Context Market Trends Current State Communications Architecture Challenges Drivers for Enterprise Network Evolution Enterprise Communications Development Strategy: - Strategic Objectives - Principal Policies FORMULATION OF ENTERPRISE-WIDE COMMUNICATIONS STRATEGY Business Vision Business Objectives Business Strategy Key Business Challenges Integrated Operations Requirements IT Objectives IT Strategy Inf. Systems Program IT Infrastructure Program OT Objectives OT Strategies OT Program Future State Architecture and Implementation Roadmap
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 60 THE “AS IS” ARCHITECTURE Traditional oil operator’s fragmented communication Networks CyberLayer
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 61 3- IACS Network: SDH + Ethernet 2- Data Network: E1 + Ethernet 1- Voice Network: PABX + Twisted pairs THE “AS IS” NETWORKS: THREE SEPARATE NETWORKS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 62 DRIVERS FOR ENTERPRISE COMMUNICATIONS EVOLUTION Fragmented Networks in HQ and Remote Fields… … physical barrier for effective corporate-wide system integration … redundant infrastructure that defies cost savings … poor communication network assets utilization Fragmented Management Model … …. Cross-functional model, not well coordinated between the IT and IACS Operations teams Different visions for IT, IACS and Voice communication teams … barrier for effective corporate-wide system integration and digital business transformation efforts
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 63 Converged Enterprise Communication Architecture Converged oil operator’s architecture THE “TO BE” ARCHITECTURE CyberLayer
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 64 1) Communication Network Infrastructure Integration (IACS, Voice , Information Systems networks) ENTERPRISE COMMUNICATIONS STRATEGIC OBJECTIVES & ARCHITECTURE REQUIREMENTS Voice Network (Telephony) Data Network (Information Technology) IACS Network (IACS)
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 65 2) Communication Service Convergence (voicemail, e-mail, SMS, fax, instant messaging, presence information, IP telephony, video conferencing, web conferencing, call control and speech recognition, business applications data ENTERPRISE COMMUNICATIONS STRATEGIC OBJECTIVES & ARCHITECTURE REQUIREMENTS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 66 3) Communication Network Management Convergence IACS Voice Data Network Management ENTERPRISE COMMUNICATIONS STRATEGIC OBJECTIVES & ARCHITECTURE REQUIREMENTS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 67 4) Organization Model Convergence of Enterprise Communication Function The special requirements of the individual systems … …security, availability, performance, etc.) should be preserved while integrating the network infrastructures and communication services. Voice Network Team Data Network Team IACS Network Team ENTERPRISE COMMUNICATIONS STRATEGIC OBJECTIVES & ARCHITECTURE REQUIREMENTS
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 68 PRINCIPAL POLICIES Leverage Existing Communication Assets by … … building on the existing communication media, equipment and services and optimize their utilization (if possible) Adopt Standards and Apply Best Practices for … … transition from the As Is to the To Be Enterprise Communication Network Maintain High Degree of Dependability, i.e. …… …availability, security, performance, scalability, manageability, reliability and agility Use Hybrid Saucing model … … In-sourcing versus Outsourcing model is justified on a case-by-case basis
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 69 ILLUSTRATIVE EXAMPLE - O&G INTEGRATED OPERATIONS Example of two sites connected via the converged enterprise network: - The oil operator’s headquarter. - A remote field site - The Headquarter site includes the Integrated Operation Center (IOC), back offices and the enterprise data center. - The remote field site includes field’s control center (CC), administration offices, remote rig sites and remote well sites.
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 70 TRANSITION ARCHITECTURE IMPLEMENTATION ROADMAP Implement Enterprise Communications Function Management Model Integrate Communication Network Infrastructure & NM Technology Platforms Implement Communication Services Convergence (UC)
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 71 AGENDA 1) Largescale Critical Infrastructure Domains, Levels, Ownership and Operation Model 2) Examples of Largescale Critical Infrastructures 3) Layers of Largescale Critical Infrastructure 4) Cyber Critical Infrastructure 5) Evolution Trends Associated with IACS Systems 6) Architecture Development Method of Cyber Critical Infrastructure 7) Example 1: Establishment of Enterprise Networking & Communications for Petroleum Industry Integrated Operations 8) Example 2: Establishment of Control and Information Architecture for a Transmission System Operator in Deregulated Electricity Market
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 72 Example 2: ESTABLISHMENT OF THE CONTROL AND INFORMATION ARCHITECTURE OF A NEW TSO IN A DEREGULATED ELECTRICITY MARKET New Market New Architecture  New Market  New Architecture
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 73 Example 2 : ESTABLISHMENT OF THE CONTROL AND INFORMATION ARCHITECTURE OF A NEW TSO IN A DEREGULATED ELECTRICITY MARKET Transformation of the Electricity Sector (The As-Is Market) Generation Transmission Distribution Single Electricity Utility Consumer Tarif + Government Subsidy Supply of Electricity Payments Vertically integrated style of ownership and control
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 74 Example 2 : ESTABLISHMENT OF THE CONTROL AND INFORMATION ARCHITECTURE OF A NEW TSO IN A DEREGULATED ELECTRICITY MARKET Disco 1 Genco 1 Consumer Tarif + Government Subsidy Horizontally integrated style of ownership and control Transformation of the Electricity Sector (The To- Be Market) Genco 2 … Genco n TSO Disco 2 Disco 3 Sector Regulator Supply of Electricity Payments
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 75 The To-Be Business Architecture Requirements -Availability, Security, Manageability, Economic Dispatch System / EMS - Data Quality requirements - Comply with Open System International Standards (e.g. OPC UA) - Distributed system architecture - Agility (Virtualization and Logical DW) - Scalability - RT Operational Intelligence, Business Intelligence & Bigdata Analytics -Performance of Computer & Telecom Systems -In-house Application Development - Enterprise Mobility -EMS & Settlement Systems - Robust comprehensive DR Solution The To-Be Technical Architecture Requirements - Secure & Economic Operation - Sharing IACS/EMS/WMS Information: - Within Enterprise - With All Market Players - Change Management - Competitive Advantage In New Market - Connect to National & International partners Financial Settlement within market players - Business Continuity Example 2 : ESTABLISHMENT OF THE CONTROL AND INFORMATION ARCHITECTURE OF A NEW TSO IN A DEREGULATED ELECTRICITY MARKET
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 76 The To- Be Technical Architecture (Conceptual) CC With Integrated DC & DR Site GENCOs TSO HQ DISCOs International Grids Integrated Data Center (IDC) Control Center National GridF. Settlement AuthorityRegulator Example 2 : ESTABLISHMENT OF THE CONTROL AND INFORMATION ARCHITECTURE OF A NEW TSO IN A DEREGULATED ELECTRICITY MARKET DR Site Typically distributed architecture across the CC and the HQs READY FOR INFORMATION SHARING CCs. of DISCOs, National and International Grids
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 77 The To- Be Technical Architecture Example 2 : ESTABLISHMENT OF THE CONTROL AND INFORMATION ARCHITECTURE OF A NEW TSO IN A DEREGULATED ELECTRICITY MARKET Settlement Meters RTUs PLCs RTUs SCMSs PLCs RTUs SCMSs PLCs EMS DMS DMS R DMS Support ISDN/PSTN CWDM Mux Backend Frontend Storage GE FC & GE Transports Data Centre ICCP Server National & Reginal Partners Control Centres
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 78 Settlement Meters RTUs PLCs RTUs SCMSs PLCs RTUs SCMSs PLCs EMS DMS DMS R DMS Support ISDN/PSTN CWDM Mux Frontend Backend Storage GE FC & GE Transports Data Centre ICCP Server National & Reginal Partners Control Centres AvailabilitySecurity Scalability & Modularity Agility Business Continuity Mobility Example 2 : ESTABLISHMENT OF THE CONTROL AND INFORMATION ARCHITECTURE OF A NEW TSO IN A DEREGULATED ELECTRICITY MARKET Achieving the Design Goals Logical DW, Analytics: BI, RT OI, BDA
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 79 Country 2 Country 1 Country 3 Country 4 Example 2 : ESTABLISHMENT OF THE CONTROL AND INFORMATION ARCHITECTURE OF A NEW TSO IN A DEREGULATED ELECTRICITY MARKET Achieving the Design Goals: Extensibility Local Level International Level National Level Control & Information Network for load dispatch, financial settlements and real-time information sharing
Designing Next Generation IACS System Architecture Across Large Scale Critical Infrastructure Slide 80 THANK You Alaa Mahjoub is a data management senior expert with decades of insightful experience in Transportation, Oil & Gas, Utility and Defense. Participated as a leading contributor to the Enterprise Information Management (EIM), Enterprise Architecture (EA) and Industrial Automation & Control Systems (IACS) Programs in, ADCO, TRANSCO and DoT. Led the transformation of the control and information systems’ architecture during the restructuring of the water & electricity sector in the Emirate of Abu Dhabi. He is a holder of B.Sc. and M.Sc. in Computer Engineering and has numerous research publications in credit in Digital Energy, Transportation and Data Management.
