Map Window 5 is an open-source GIS software that has the capability to digitize maps, create a geodatabase, convert raster to vector, interactive maps, georeferencing of images, etc. The current tutorial demo the way you can create an attribute table with the help of MapWindow 5.

1. How to create
attribute table in
MapWindow 5 ?
Dr. Mrinmoy Majumder
Data Science in Sustainability | EIS Publishers | Hydrology N/L
SUBSCRIBE EDITOR

2. MapWindow 5
1
2
4
5
3
1 > Map Projection
2 > Data Layer Window
3 > Main Window
4 > Toolbox
5 > “Layer Open/Create”
Toolbar
6 > Add Geometry
6
Open-Source GIS Software
Download from https://github.com/MapWindow/MapWindow5/releases

3. How to create attribute table in MapWindow 5 ?
A
A
Insert the
image/map/raster file
Create shapefile
WRITE THE NAME OF THE SHAPEFILE
SELECT THE TYPE OF THE SHAPEFILE
To digitize locations, select point shape file
and use the Add Geometry tool(6).Click on
the location points of the example image to
generate attributes for each locations. For
each click on the location one shape attribute
will be generated. The same process is
repeated to digitize line(rivers, roads etc.) or
area(pond, lake, watershed etc..) features.
Select Polyline and Polygon as Layer Type
respectively for Line and Area features.
Example Image
Table Editor/Attribute Table
A
3
1
4
2
Select Projection(See 1)
B B > Table Editor Window
Follow
1 > 2 > 3 > 4 to create
attribute table for
each vector layers

4. Thank You
For Watching
This is an excerpt from the
tutorial on GIS and Remote
sensing available for Rs.70 at
Instamojo.
