Hit Refresh with Oracle GoldenGate Microservices
- 2. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 2 Hit Refresh with Oracle GoldenGate Microservices Bobby Curtis Director, Product Management Oracle, GoldenGate April 2018
- 3. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Safe Harbor Statement The following is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any material, code, or functionality, and should not be relied upon in making purchasing decisions. The development, release, and timing of any features or functionality described for Oracle’s products remains at the sole discretion of Oracle. Confidential – Oracle Internal/Restricted/Highly Restricted 3
- 4. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Agenda Overview and Objectives Manageability Useability Demo 1 2 3 4 Confidential – Oracle Internal/Restricted/Highly Restricted 4
- 5. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Oracle GoldenGate Real time Performance Extensible & Flexible Proven & Reliable Oracle GoldenGate provides low-impact capture, routing, transformation, and delivery of database transactions across homogeneous and heterogeneous environments in real-time with no distance limitations. Most Databases Data Events Transaction Streams Cloud DBs Big Data Supports Databases, Big Data and NoSQL: * The most popular enterprise integration tool in history
- 6. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Use cases Oracle GoldenGate New DB/ HW/OS/APP Fully Active Distributed DB Application Offloading Big Data, DW & Marts Message Bus & Data Grid Global Data Centers Data Streaming GoldenGate Oracle Confidential – Internal/Restricted/Highly Restricted1/05/2018 Copyright © 2016, Oracle and/or its affiliates. All rights reserved. | Databases Applications Big Data and No SQL Mainframes Mobile Streaming & Messaging Capture Deliver Distribute Receive Secure Oracle SQL Server MySQL IBM DB2 Z IBM DB2 i IBM DB2 LUW HP NonStop Informix Sybase Messaging High Availability Zero Downtime Migration Data Synchronization Big Data Ingestion Query/Report Offloading Stream Analytics Data Bus (Lambda/Kappa)
- 7. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 7 Oracle GoldenGate Classic Architecture Capture (extract): committed transactions are captured (and can be filtered) as they occur by reading the transaction logs. As of V.11.2.1, GoldenGate offers two options for capture for Oracle; Classic & Integrated Capture Trail: stages and queues data for routing. Pump: distributes data for routing to target(s). Route: data is compressed, encrypted for routing to target(s). Delivery: applies data with transaction integrity. New with GoldenGate 12c, Integrated Delivery & Non- Integrated/Integrated Prallel Delivery. Bi-Directional 20 YRS
- 8. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Objectives for 12.3 Confidential – Oracle Internal/Restricted/Highly Restricted 8 UsabilityManageability Performance
- 9. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Objectives for 12.3 Confidential – Oracle Internal/Restricted/Highly Restricted 9 UsabilityManageability Performance
- 10. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Microservice Architecture Scalable, REST based Administration and Distribution Service Security Framework Secure using a Role based framework Flexible Directory Structure Enables easy usablity, patching and deployments Oracle Confidential – Internal/Restricted/Highly Restricted Manageability Cross Architecture Configuration Inter-operablity between Classic and Microservices Architectures
- 11. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Microservices Architecture Confidential – Oracle Internal/Restricted/Highly Restricted 11 New way to administer GoldenGate Capture Trail Files Trail Files DeliveryDistribution Service Network Receiver Service Administration Service Metrics Service >HTML>>SQL >>CLI >>API Customizable Interactive Experience Proxy/Reverse Proxy ServiceManager
- 12. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | 12 • bin - Executables • lib – libraries, utilities, scripts $OGG_HOME (12.3.0.1.0) $OGG_ETC_HOME - Config File, Sec. certs, wallets $OGG_VAR_HOME - Logs, Trail File, … ServiceManager $OGG_ETC_HOME - Config File, Sec. certs, wallets $OGG_VAR_HOME - Logs, Trail File, … Deployment_Home_1 $OGG_ETC_HOME - Config File, Sec. certs, wallets $OGG_VAR_HOME - Logs, Trail File, … Deployment_Home_N Extract/Replicat Trail Files Report Files Log Files Extract/Replicat Trail Files Report Files Log Files $OGG_HOME = /opt/app/oracle/product/12.3.0.1/oggcore_1 $DEPLOYMENT_HOME = /opt/app/oracle/gg_deployments/<deployment_name> Flexible Directory Structure
- 13. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | 13 • bin - Executables • lib – libraries, utilities, scripts $OGG_HOME (12.3.0.1) $OGG_ETC_HOME - Config File, Sec. certs, wallets $OGG_VAR_HOME - Logs, Trail File, … ServiceManager $OGG_ETC_HOME - Config File, Sec. certs, wallets $OGG_VAR_HOME - Logs, Trail File, … Deployment_Home_1 $OGG_ETC_HOME - Config File, Sec. certs, wallets $OGG_VAR_HOME - Logs, Trail File, … Deployment_Home_N Extract/Replicat Trail Files Report Files Log Files Extract/Replicat Trail Files Report Files Log Files • bin - Executables • lib – libraries, utilities, scripts $OGG_HOME (12.3.0.1.2) Flexible Directory Structure - Upgrade/Patching
- 14. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 14 Security Framework • Role Based • 4 Roles • Security • Administrator • Operator • User • Integration with Single Sign-On (SSO) • On Roadmap
- 15. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 15 Cross Architecture/Platform Configuration Trail Files Distribution Service Administration Service Metrics Service ServiceManager Network Manager Trail Files ReplicatExtract Bi-Directional • Distribution Service connects to Manager Port (Classic) • Extract Data Pump connects to Receiver Service Port (Microservices)
- 16. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Objectives for 12.3 Confidential – Oracle Internal/Restricted/Highly Restricted 16 UsabilityManageability Performance
- 17. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | HTML5 Pages Embedded Web Pages for Administration and Configuration AdminClient Thin, Lite Weight REST API client interface REST API Flexible End-Points for Dynamic Interaction Oracle Confidential – Internal/Restricted/Highly Restricted Usablity
- 18. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 18 • Simple to use Web interfaces • Embedded into Executibles • No web server needed • Lower learning curve HTML5 Pages
- 19. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 19 • Command Line access via AdminClient – Windows Workstations/Laptops – Remote Linux Machines • Runs all GGSCI commands AdminClient
- 20. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | 20 curl -u oggadmin:welcome1 -H "Content-Type: application/json" -H "Accept: application/json" -X POST http://localhost:16001/services/v2/credentials/OracleGoldenGate/SGGATE -d @create_cred_alias.json | python -mjson.tool ,… "messages": [ { "$schema": "ogg:message", "code": "OGG-15114", "issued": "2017-08-10T12:40:54Z", "severity": "INFO", "title": "Credential store in /opt/app/oracle/gg_deployments/Atlanta_1/var/lib/credential/ altered.", "type": "http://docs.oracle.com/goldengate/c1230/gg- winux/GMESG/oggus.htm#OGG-15114" }, { "$schema": "ogg:message", "code": "OGG-15116", "issued": "2017-08-10T12:40:54Z", "severity": "INFO", "title": "No information found in credential store.", "type": "http://docs.oracle.com/goldengate/c1230/gg- winux/GMESG/oggus.htm#OGG-15116" } ] } • Customize Replication • Run anywhere • Dynamic Architecture REST API
- 21. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 21
- 22. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 22
