3. Main topic
FPGA programming for beginners
Dev kit and tools
Tutorial 1: "LED"
Simulation tool and testbench
Tutorial 2: "Simulation"
IP core
Building on the command-line
FPGA design for Ethernet
overview, MII, RMII, timing chart, MDIO, RFC2544
Tutorial 3: "Delay measurement tool for network device"
Play with the measurement device
Next step
{Layer2, Layer3, IPv6, throughput, frame loss rate} support
4. Extra materials
a. PCI and PCI Express
overview, Bus (wishbone), sample code, debug, DMA and SR-IOV
Tutorial 5: "How to use PCI Express IP"
b. HTML5 for embedded system
Blob/Arraybuffer, websocket, node.js, HTML canvas
c. FPGA hot topics
FPGA development kit, Handmade 10G/40G/100G device, memory,
CAM/TCAM,HLS for FPGA, Embedded CPU
Reference list
5. Schedule
9/4
Main topic
9/5
Extra a:
Main topic PCI Express
33. How to use IPexpress
File -> Add -> Existing File
34. How to use IPexpress
生成された{file name}.ipxを選択して'Add'
35. How to use IPexpress
IPの{file name}_tmpl.vにネット名称が記述されているので,それを基にIPを使
用する.tb_{file name}_tmpl.vなども参考になる
36. Building on the Command Line
GUIを使わずに論理合成する
1. {project name}.tclに作業内容を記述
2. $ diamondc {project name}.tcl > output.log
Xilinx ISEでも大体同じことが可能
prj_project open "/home/sora/proj/led.ldf"
prj_run Synthesis -impl led
prj_run Translate -impl led
prj_run Map -impl led
prj_run PAR -impl led
prj_run PAR -impl led -task PARTrace
prj_run Export -impl led -task Bitgen
prj_project close
tclスクリプトの例
44. MDIO
# 今回のWorkshopでは使用しません
PHYの操作とステータスの取得用
リンクのステータス取得
転送速度の取得と選択
全二重・半二重
オートネゴ
Loopback
10GbEではレジスタ数が拡張
ST
OP PHYADR REGADR TA DATA
(01)
2bit 2bit 5bit 5bit 2bit 16bit
MDIO フレームフォーマット
45. Reduced Media Independent Interface (RMII)
100M (MII)が16ポートだけでも信号線が256本必要
そこでMII/GMIIの信号線を半分したインタフェースRMII/RGMIIが一般的に利
用されている
RMIIは,動作周波数を2倍にする代わりに信号線を半分にしたインタフェー
ス
RGMIIは周波数を変えずにClockの立ち上がりと立ち下りの両エッジでデー
タ転送することで信号線数を半分にする
100 Mbps 1000 Mbps
RMII RGMII
50 MHz 125 MHz
2 bit 4 bit
46. Delay measurement tool for network device
source code: https://github.com/sora/fpga-workshop-2012f/tree/master/tutorial-4
FPGAでネットワークテスタを作る動機
ショートパケット (64byte)ワイヤーレートでテストがしたい
クロックレベルの計測 (1000BASE-Tで8ns単位)
自作ネットワークデバイスのデバッグには必要
FPGA
I/F: Port 0 I/F: Port 1
IP address: IP address:
10.0.20.105/24 10.0.21.105/24
I/F: Port 0 I/F: Port 1
IP address: IP address:
10.0.20.1/24 10.0.21.1/24
DUT: Device Under Test DUT
47. Delay measurement tool for network device
source code: https://github.com/sora/fpga-workshop-2012f/tree/master/tutorial-4
LatticeECP3 versa kitはPHY Chipが乗っているのでそれを利用
PHY chip: Marvell 88E1119R
今回はDUTの正確な遅延の計測のためMAC相当の機能はIP coreを使わず
に自作
GMII DATA LED TX
PHY chip RJ45
LED RX
MDIO LEDs
FPGA GMII DATA LED TX
PHY chip RJ45
LEDs LED RX
MDIO
FPGAでの実装部とPHYチップの関係
79. Tutorial 4.2: FPGAでPCI Expressを使う
source code: https://github.com/sora/fpga-workshop-2012f/tree/master/tutorial-5
Wishboneバス経由でPCI Express上のI/Oメモリ空間へ回路をマッピング(read only)
コードは複雑に見えますがほとんどが定型のコードです
reg[15:0] wb_dat;
reg wb_ack;
always @(posedge clk_125 or negedge core_rst_n) begin
if (!core_rst_n) begin
wb_dat <= 16'h0;
end else begin
if (pcie_cyc & pcie_stb) begin
wb_dat <= pcie_adr[15:0];
end
end
end
always @(posedge clk_125 or negedge core_rst_n) begin
if (!core_rst_n) begin
wb_ack <= 0;
end else begin
wb_ack <= pcie_cyc & pcie_stb & (~wb_ack);
end
end
assign pcie_dat_i = wb_dat;
assign pcie_ack = wb_ack;
assign led_out = 14'h0;
80. PCI/PCI Express: DMA and SR-IOV
Direct Memory Access (DMA)
ペリフェラルが直接メモリバスを操作して,メインメモリにアクセスする仕組み
レイテンシが低いがスループットが高い
Kintex-7 dev kitにDMA EngineのIPが付属
Single Root I/O Virtualization (SR-IOV)とマルチファッション
PCI-SIGによるPCIデバイスのIO仮想化サポートのための規格
Xilinx 7シリーズから本格対応開始
Vertex-7 XTはPCIe Gen3のHard IPで一部機能をサポート
Kintex-7はSoft IPで対応予定?(詳細不明)
93. CAM/TCAM
module tcam ( ...
input clk
, input rst wire[depth-1:0] bits;
, input iena genvar i;
, input [width-1:0] idata generate
, input [width-1:0] iprefix for (i=0; i<width; i=i+1) begin: gen
, input [width-1:0] isearch_data //assign bits[i] = !(data[i] ^ search[i]); // <- BCAM
, output match assign bits[i] = !(data[i] ^ isearch_data[i]) | !prefix[i];
); end
endgenerate
reg[width-1:0] data;
reg[width-1:0] prefix; always @(posedge clk) begin
if (rst)
always @(posedge clk) begin match <= 1'b0
if (rst) begin else
data <= {width{1'b0}}; match <= (& bits) & iena;
prefix <= {width{1'b0}}; end
end else begin
if (iena) begin
data <= idata;
prefix <= iprefix;
end
end
end
...
94. High-Level Synthesis (HLS) for FPGA
FPGA向けのHLS環境が少しずつ登場
Xilinx Vivado HLS (C/C++/SystemC)
http://www.xilinx.com/support/documentation/sw_manuals/xilinx2012_2/ug902-vivado-
high-level-synthesis.pdf
Impulse C (ANSI C)
Arista 7124FX Application Switchのdev kitに年間ライセンスが付属
その他 (主にASIC向けだが,FPGAにも対応)
Bluespec, LabVIEW FPGAモジュール, etc.
今後の動向
Altera OpenCL (OpenCL)
http://www.altera.co.jp/b/opencl.html
Oracle JDK 9 (Java) #本当?
http://www.oracle.com/technetwork/jp/ondemand/java/jdw-2-2-1390077-ja.pdf
95. Embedded CPU
FPGA Soft CPU
Xilinx MicroBlaze, PicoBlaze
Altera Nios, Nios II
Lattice LatticeMico32
OpenRISC
LEON (SPARC V8)
組み込み向けCPU
ARM
Intel Atom E6シリーズ
はぜやまさんがAtom+FPGA dev kitを持ってくるらしい
CPU+FPGA
Xilinx Zynq (Cortex-A9 dual core 1MHz)
