Flex_rest_optimization
- 1. Flex with Rest and Optimazation MyLabs Flex with Rest and Optimazation
- 2. Ways between AJAX and Flex using the flashVars properties, querying string parameters, using the navigateToURL() method using the ExternalInterface class
- 4. Using FlashVar Property <html> <head> <title>/flex2/code/wrapper/SimplestFlashVarTestWrapper.html</title> <style> body { margin: 0px; overflow:hidden } </style> </head> <body scroll='no'> <table width='100%' height='100%' cellspacing='0' cellpadding='0'><tr><td valign='top'> <h1>Simplest FlashVarTest Wrapper</h1> <object id='mySwf' classid='clsid:D27CDB6E-AE6D-11cf-96B8-444553540000' codebase='http://fpdownload.macromedia.com/get/flashplayer/current/swflash.cab' height='100%' width='100%'> <param name='src' value='FlashVarTest.swf'/> <param name='flashVars' value='firstName=Nick&lastName=Danger'/> <embed name='mySwf' src='FlashVarTest.swf' pluginspage='http://www.adobe.com/go/getflashplayer' height='100%' width='100%' flashVars='firstName=Nick&lastName=Danger'/> </object> </td></tr></table> </body> </html>
- 6. Using URL fragments <mx:Script> <![CDATA[ import mx.managers.BrowserManager; import mx.managers.IBrowserManager; import mx.utils.URLUtil; private var bm:IBrowserManager; [Bindable] private var fName:String; [Bindable] private var lName:String; private function init(e:Event):void { bm = BrowserManager.getInstance(); bm.init("", "Welcome!"); /* The following code will parse a URL that passes firstName and lastName as query string parameters after the "#" sign; for example: http://www.mydomain.com/MyApp.html#firstName=Nick&lastName=Danger */ var o:Object = URLUtil.stringToObject(bm.fragment, "&"); fName = o.firstName; lName = o.lastName; } ]]> </mx:Script>
- 10. Using the ExternalInterface API Access javascript from flex <![CDATA[ import mx.controls.Alert; private function init():void { var userAgent:String = ExternalInterface.call("navigator.userAgent.toString"); Alert.show(userAgent, "navigator.userAgent:"); } ]]> </mx:Script> <mx:ApplicationControlBar dock="true"> <mx:Button label="Display user agent" click="init();" /> </mx:ApplicationControlBar>
- 11. Using the ExternalInterface API Access flex from javascript public function myFunc(s:String):void { // whatever you want} public function initApp():void { ExternalInterface.addCallback("myFlexFunction",myFunc); } <SCRIPT LANGUAGE="JavaScript"> function callApp() { window.document.title = document.getElementById("newTitle").value; mySwf.myFlexFunction(window.document.title); } </SCRIPT>
- 19. Optimizing Actionscript: Object Creation Solution #2: Ordered Creation During startup, stagger creation of objects <mx:Application> <mx:Panel width="250" height="100" creationPolicy=âqueuedâ /> <mx:Label text="One" /> </mx:Panel> <mx:Panel width="250" height="100" creationPolicy=âqueuedâ /> <mx:Label text="Two" /> </mx:Panel> </mx:Application>
- 20. Measurement/Layout: Definition The process of assigning a position and size to every component <mx:Application> <mx:HBox> <mx:Button label=â1â/> <mx:Button label=â2â/> </mx:HBox> <mx:TextArea width=â100%â height=â100%â text=âTextâ/> </mx:Application>
