1. iFour ConsultancyExplore ASP.NET Core 3.0 Features

2. Topics
● Introduction
● Why choose .NET Core?
● Versions of .NET Core
● Benefits and Features
● What's new in .Net Core
● Migrate from .net framework to .net core
● Demo
- Installation
- Configuration
- Project structure explanations
- Application deployment
ASP.NET Core Software companies

3. .NET Core
ASP.NET Core Software companies

4. Introduction
❖ ASP.NET Core is a cross-platform, high-performance, open-source
framework for building modern, cloud-based, Internet-connected
application
ASP.NET Core Software companies

5. ❖ An Editor -VS,VS Code, Sublime, Vim, Atom
➢ Visual Studio 2019
❖ .NET Core SDK (Software Development Kit)
➢ https://dotnet.microsoft.com/download/dotnet-core/3.0
Prerequisites
ASP.NET Core Software companies

6. Why choose .NET Core ?
ASP.NET Core Software companies

7. The MVC Architecture (Why choose .NET Core ?)
ASP.NET Core Software companies

8. Razor Page (Why choose .NET Core ?)
❖ page-based coding model that makes building web UI easier
❖ It is a server side markup language
❖ Support :
➢ Cross platform development
➢ Deployed to window, linux and mac os
➢ Lightweight and very flexible
➢ Full control over rendered HTML
ASP.NET Core Software companies

9. JavaScript Frameworks (Why choose .NET Core ?)
❖ Provide built-in template for two most popular javaScript frameworks
➢ Angular
➢ React
❖ JavaScriptServices
➢ Provide infrastructure that need to develop client-side apps using
JavaScript frameworks
ASP.NET Core Software companies

10. Collaboration & Cross-Platform support (Why choose
.NET Core ?)
❖ “Write once, run anywhere” seems to be the mantra
❖ Developers are free to choose their development OS.
❖ Using visual studio IDE (Integrated Development Environments) , team
of developers working across macOS, Windows or Linux machines and
they can still collaborating on the same project.
ASP.NET Core Software companies

11. Dependency injection support (Why choose .NET
Core ?)
❖ Technique for achieving Inversion of control (IoC)
❖ Most widely used pattern for creating loosely coupled application
❖ Built-in container is represented by IServiceProvider implementation
❖ Two type of Service
➢ Framework Service
○ Which are part of Asp.net core framework such as IApplicationBuilder,
IHostingEnvironment, ILoggerFactory
➢ Application Service
○ Programmer create for your application
ASP.NET Core Software companies

12. Versions of .NET Core
ASP.NET Core Software companies

13. Benefits and Features
ASP.NET Core Software companies

14. ❖ Open Source
❖ Cross Platform (Windows, Linux, MacOS)
❖ Multiple environments and development mode
❖ One Unified Programming Model for MVC and Web API
❖ Command-line tool support
❖ Free of Cost
❖ Modular
❖ Flexible deployment
❖ Support for Cloud-Based Development
❖ Performance
Benefits and Features
ASP.NET Core Software companies

15. ❖ Open Source
➢ .NET core is an open source,which is developed and maintained by
Microsoft and developers all around the world on GitHub
➢ Link- https://github.com/dotnet/core (you can download
contribute code on this URL)
Benefits and Features contd.
ASP.NET Core Software companies

16. ❖ Cross-platform
➢ Application implemented in .NET Core can be run and its code can be
reused regardless of your platform target.
➢ It currently supports three main operating systems (OS)
■ Windows
■ Linux
■ MacOs
Benefits and Features contd.
ASP.NET Core Software companies

17. ❖ Multiple environments and development mode
➢ Configure app behavior based on the runtime environment using environment
variable
➢ Achieve this behaviour using, environment variable
ASPNETCORE_ENVIRONMENT at app startup and store value in
IHostEnvironment.EnvironmentName
➢ Three values are supported by Framework
○ Development
○ Staging
○ Production
Benefits and Features contd.
ASP.NET Core Software companies

18. Benefits and Features contd.
ASP.NET Core Software companies

19. ❖ One Unified Programming Model for MVC and Web API
➢ Both the MVC controller class and the Web API Controller class inherit from
the same Controller base class and returns IActionResult.
Benefits and Features contd.
IActionResult
ViewResult JsonResult
ASP.NET Core Software companies

20. ❖ Command-line tool support
➢ .NET Core provides the command line, which support all major platforms like
Windows, Mac and Linux.
➢ .NET Core fully supports command line tool which is useful in complete cycle
of development (create new project, add package, build, run etc.)
➢ It is also referred to as a foundational tool because it’s a primary layer on
which other tools like IDE (Integrated Development Environments) build the
application and run it.
Benefits and Features contd.
ASP.NET Core Software companies

21. ❖ Free of Cost
➢ .NET Core is available as free of cost with MIT (Massachusetts Institute of
Technology) license. (so you can use it for private and commercial purpose).
➢ The MIT License grants the software end user rights such as copying,
modifying, …
Benefits and Features contd.
ASP.NET Core Software companies

22. ❖ Modular
➢ .NET Core provide modularity with middleware components
➢ Both the request and response pipelines are composed using the
middleware components
➢ Rich set of built-in middleware components are provided.
➢ Custom Middleware Components can also be created
Benefits and Features contd.
ASP.NET Core Software companies

23. Benefits and Features contd.
ASP.NET Core Software companies

24. ❖ Flexible deployment
● There can be two types of deployment for .NET Core applications
➢ Framework-dependent deployment (IIS, Apache, Docker)
➢ Self-contained deployment (Exe)
Benefits and Features contd.
ASP.NET Core Software companies

25. ❖ Support for Cloud-Based Development
➢ For better security and overall performance, it is better to develop
your enterprise application as cloud-based.
➢ .NET Core functionality is excellent for this.
➢ The framework has been designed to take full advantage of
accessing the Cloud and your applications will be all the better for
it.
Benefits and Features contd.
ASP.NET Core Software companies

26. ❖ Performance
➢ The most important feature of ASP.NET Core is probably its higher performance
when compared to other platforms.
➢ When you compile your code, it automatically optimize it in order to increase the
performance.
➢ The best part about this particular benefit is that you do not have to change your
code. With the re-compilation it optimizes the code directly.
Benefits and Features
ASP.NET Core Software companies

27. What’s new in .Net Core
ASP.NET Core Software companies

28. ❖ WPF and Windows Forms
➢ Create project from the command line tools
○ dotnet new wpf
○ dotnet new winforms
○ dotnet run
➢ Open, build and Run project in visual studio 2019
➢ Uses Microsoft.NET.Sdk.WindowsDesktop
➢ UseWPF and UseWindowsForms properties allow project to specify if it is winform
or WPF
What’s new in .Net Core
ASP.NET Core Software companies

29. ASP.NET Core Software companies

30. ❖ C# 8
● C# 8 Includes,
➢ Pattern matching enhancements:
○ Switch expression
○ Property patterns
○ Tuple patterns
➢ Using declarations
➢ Static local functions
What’s new in .Net Core
ASP.NET Core Software companies

31. ❖ Switch expressions
➢ Variable comes before the switch keyword
➢ The case and : elements are replaced with =>
➢ The default case is replaced with a _
➢ The bodies are expressions, not statements
What’s new in .Net Core
ASP.NET Core Software companies

32. ❖ Property Patterns
➢ Enables you to match on properties of the object
What’s new in .Net Core
ASP.NET Core Software companies

33. ❖ Tuple patterns
➢ allow you to switch based on multiple values expressed as a tuple
What’s new in .Net Core
ASP.NET Core Software companies

34. ❖ Using declarations
➢ A using declarations is a variable declaration preceded by the using keyword
➢ Variable being declared should be disposed at the end of the enclosing scope
What’s new in .Net Core
ASP.NET Core Software companies

35. ❖ Static Local Function
➢ It can be static because it doesn't access any variables in the enclosing
scope
What’s new in .Net Core
ASP.NET Core Software companies

36. ❖ Fast built-in JSON support
➢ Added System.Text.Json.Utf8JsonReader ,System.Text.Json.Utf8JsonWriter
and System.Text.Json.JsonDocument
➢ The new built-in JSON support is low allocation, high-performance
➢ .NET Core 3.0, three new main JSON-related types have been added.
● Utf8JsonReader :
○ High-performance, low allocation
○ 2X Faster than using reader from JSON.NET
What’s new in .Net Core
ASP.NET Core Software companies

37. ● Utf8JsonWriter :
○ High-performance, non-cached
○ 30-80% faster than using the writer from Json.NET
● JsonDocument :
○ Provides the ability to parse JSON data and build a read-only
Document Object Model (DOM)
What’s new in .Net Core
ASP.NET Core Software companies

38. ❖ WinForms Chart controls
➢ Added System.Windows.Forms.DataVisualization package now available in
NuGet
➢ Source code available at dotnet/winforms-datavisualization, On GitHub
➢ Also, Enable chart control in project by adding code to .csproj file
What’s new in .Net Core
ASP.NET Core Software companies

39. ❖ Added supports for AES-GCM and AES-CCM ciphers
❖ Added supports System.IO.Ports.SerialPort on Linux
❖ WinForms High DPI
❖ Tiered compilation - Use the Just-In-Time (JIT) compiler to get better
performance.
❖ Docker and cgroup memory limits
➢ Packing and running application with containers
➢ Set memory limit to Alpine-based container
What’s new in .Net Core
ASP.NET Core Software companies

40. Migrate from .NET Framework to .NET Core
ASP.NET Core Software companies

41. ➢ Convert class libraries to .NET Standard
➢ Use Windows Compact Pack for Windows API’s
● Microsoft.Windows.Compatibility
➢ Use Analyzer to see which platforms code run in
● Microsoft.DotNet.Analyzers.Compatibility
Migrate from .NET Framework to .NET Core
ASP.NET Core Software companies

42. ASP.NET Core Software companies

43. ASP.NET Core Software companies

44. ASP.NET Core Software companies

45. ASP.NET Core Software companies

46. ASP.NET Core Software companies

47. ➢ The WPF and Windows Forms projects look similar but use a different SDK and also use
properties to declare which UI framework is being used:
For WPF:
<Project Sdk="Microsoft.NET.Sdk.WindowsDesktop">
<PropertyGroup>
<OutputType>WinExe</OutputType>
<TargetFramework>netcoreapp3.0</TargetFramework>
<UseWPF>true</UseWPF>
</PropertyGroup>
</Project>
Migrate from .NET Framework to .NET Core
ASP.NET Core Software companies

48. For Windows Forms:
<ProjectSdk="Microsoft.NET.Sdk.WindowsDesktop">
<PropertyGroup>
<OutputType>WinExe</OutputType>
<TargetFramework>netcoreapp3.0</TargetFramework>
<UseWindowsForms>true</UseWindowsForms>
</PropertyGroup>
</Project>
Migrate from .NET Framework to .NET Core
ASP.NET Core Software companies

49. ❖ Install .NET Core Window Server Hosting Bundle
➢Before you deploy application, you need to install .NET Core
window Hosting bundle for IIS
❖ Step to Deploy ASP.NET Core to IIS
➢Publish to a File Folder
➢Copy files to preferred IIS Location
➢Create application in IIS
➢Load your app
Demo - Application Deployment
ASP.NET Core Software companies

50. Demo - Application Deployment
ASP.NET Core Software companies

51. Questions?
ASP.NET Core Software companies

52. Thank You
ASP.NET Core Software companies
