The document discusses distributed stream processing frameworks. It provides an overview of frameworks like Storm, Spark Streaming, Samza, Flink, and Kafka Streams. It compares aspects of different frameworks like programming models, delivery guarantees, fault tolerance, and state management. General guidelines are given for choosing a framework based on needs like latency requirements and state needs. Storm and Trident are recommended for low latency tasks while Spark Streaming and Flink are more full-featured but have higher latency. The document provides code examples for word count in different frameworks.

1. MANCHESTER LONDON NEW YORK

2. Petr Zapletal @petr_zapletal
@spark_summit
@cakesolutions
Distributed Real-Time Stream Processing:
Why and How

3. Agenda
● Motivation
● Stream Processing
● Available Frameworks
● Systems Comparison
● Recommendations

4. The Data Deluge
● New Sources and New Use Cases
● 8 Zettabytes (1 ZB = 1 trillion GB) created in 2015
● Stream Processing to the Rescue

5. ● Continuous processing, aggregation and analysis of unbounded data
Distributed Stream Processing

6. Points of Interest
➜ Runtime and Programming Model

7. Points of Interest
➜ Runtime and Programming Model
➜ Primitives

8. Points of Interest
➜ Runtime and Programming Model
➜ Primitives
➜ State Management

9. Points of Interest
➜ Runtime and Programming Model
➜ Primitives
➜ State Management
➜ Message Delivery Guarantees

10. Points of Interest
➜ Runtime and Programming Model
➜ Primitives
➜ State Management
➜ Message Delivery Guarantees
➜ Fault Tolerance & Low Overhead Recovery

11. Points of Interest
➜ Runtime and Programming Model
➜ Primitives
➜ State Management
➜ Message Delivery Guarantees
➜ Fault Tolerance & Low Overhead Recovery
➜ Latency, Throughput & Scalability

12. Points of Interest
➜ Runtime and Programming Model
➜ Primitives
➜ State Management
➜ Message Delivery Guarantees
➜ Fault Tolerance & Low Overhead Recovery
➜ Latency, Throughput & Scalability
➜ Maturity and Adoption Level

13. Points of Interest
➜ Runtime and Programming Model
➜ Primitives
➜ State Management
➜ Message Delivery Guarantees
➜ Fault Tolerance & Low Overhead Recovery
➜ Latency, Throughput & Scalability
➜ Maturity and Adoption Level
➜ Ease of Development and Operability

14. ● Most important trait of stream processing system
● Defines expressiveness, possible operations and its limitations
● Therefore defines systems capabilities and its use cases
Runtime and Programming Model

15. Native Streaming
records
Sink
Operator
Source
Operator
Processing
Operator
records processed one at a time
Processing
Operator

16. records processed in short batches
Processing
Operator
Receiver
records
Processing
Operator
Micro-batches
Sink
Operator
Micro-batching

17. Native Streaming
● Records are processed as they arrive
Pros
⟹ Expressiveness
⟹ Low-latency
⟹ Stateful operations
Cons
⟹ Fault-tolerance is expensive
⟹ Load-balancing

18. Micro-batching
Cons
⟹ Lower latency, depends on
batch interval
⟹ Limited expressivity
⟹ Harder stateful operations
● Splits incoming stream into small batches
Pros
⟹ High-throughput
⟹ Easier fault tolerance
⟹ Simpler load-balancing

19. Programming Model
Compositional
⟹ Provides basic building blocks as
operators or sources
⟹ Custom component definition
⟹ Manual Topology definition &
optimization
⟹ Advanced functionality often
missing
Declarative
⟹ High-level API
⟹ Operators as higher order functions
⟹ Abstract data types
⟹ Advance operations like state
management or windowing supported
out of the box
⟹ Advanced optimizers

20. Apache Streaming Landscape
TRIDENT

21. Storm
Stor
● Pioneer in large scale stream processing

22. ● Higher level micro-batching system build atop Storm
Trident

23. ● Unified batch and stream processing over a batch runtime
Spark Streaming
input data
stream Spark
Streaming
Spark
Engine
batches of
input data
batches of
processed data

24. Samza
● Builds heavily on Kafka’s log based philosophy
Task 1
Task 2
Task 3

25. Kafka Streams
● Simple streaming library on top of Apache Kafka

26. Apex
● Processes massive amounts of real-time events natively in Hadoop
Operator
Operator
OperatorOperator Operator Operator
Output
Stream
Stream
Stream
Stream
Stream
Tuple

27. Flink
Stream Data
Batch Data
Kafka, RabbitMQ, ...
HDFS, JDBC, ...
● Native streaming & High level API

28. Counting Words
Spark Summit 2017
Apache Apache Spark
Storm Apache Trident
Flink Streaming Samza
Scala 2017 Streaming
(Apache, 3)
(Streaming, 2)
(2017, 2)
(Spark, 2)
(Storm, 1)
(Trident, 1)
(Flink, 1)
(Samza, 1)
(Scala, 1)
(Summit, 1)

29. Storm
TopologyBuilder builder = new TopologyBuilder();
builder.setSpout("spout", new RandomSentenceSpout(), 5);
builder.setBolt("split", new Split(), 8).shuffleGrouping("spout");
builder.setBolt("count", new WordCount(), 12).fieldsGrouping("split", new Fields("word"));
...
Map<String, Integer> counts = new HashMap<String, Integer>();
public void execute(Tuple tuple, BasicOutputCollector collector) {
String word = tuple.getString(0);
Integer count = counts.containsKey(word) ? counts.get(word) + 1 : 1;
counts.put(word, count);
collector.emit(new Values(word, count));
}

30. Storm
TopologyBuilder builder = new TopologyBuilder();
builder.setSpout("spout", new RandomSentenceSpout(), 5);
builder.setBolt("split", new Split(), 8).shuffleGrouping("spout");
builder.setBolt("count", new WordCount(), 12).fieldsGrouping("split", new Fields("word"));
...
Map<String, Integer> counts = new HashMap<String, Integer>();
public void execute(Tuple tuple, BasicOutputCollector collector) {
String word = tuple.getString(0);
Integer count = counts.containsKey(word) ? counts.get(word) + 1 : 1;
counts.put(word, count);
collector.emit(new Values(word, count));
}

31. Storm
TopologyBuilder builder = new TopologyBuilder();
builder.setSpout("spout", new RandomSentenceSpout(), 5);
builder.setBolt("split", new Split(), 8).shuffleGrouping("spout");
builder.setBolt("count", new WordCount(), 12).fieldsGrouping("split", new Fields("word"));
...
Map<String, Integer> counts = new HashMap<String, Integer>();
public void execute(Tuple tuple, BasicOutputCollector collector) {
String word = tuple.getString(0);
Integer count = counts.containsKey(word) ? counts.get(word) + 1 : 1;
counts.put(word, count);
collector.emit(new Values(word, count));
}

32. Trident
public static StormTopology buildTopology(LocalDRPC drpc) {
FixedBatchSpout spout = ...
TridentTopology topology = new TridentTopology();
TridentState wordCounts = topology.newStream("spout1", spout)
.each(new Fields("sentence"),new Split(), new Fields("word"))
.groupBy(new Fields("word"))
.persistentAggregate(new MemoryMapState.Factory(),
new Count(), new Fields("count"));
...
}

33. Trident
public static StormTopology buildTopology(LocalDRPC drpc) {
FixedBatchSpout spout = ...
TridentTopology topology = new TridentTopology();
TridentState wordCounts = topology.newStream("spout1", spout)
.each(new Fields("sentence"),new Split(), new Fields("word"))
.groupBy(new Fields("word"))
.persistentAggregate(new MemoryMapState.Factory(),
new Count(), new Fields("count"));
...
}

34. Trident
public static StormTopology buildTopology(LocalDRPC drpc) {
FixedBatchSpout spout = ...
TridentTopology topology = new TridentTopology();
TridentState wordCounts = topology.newStream("spout1", spout)
.each(new Fields("sentence"),new Split(), new Fields("word"))
.groupBy(new Fields("word"))
.persistentAggregate(new MemoryMapState.Factory(),
new Count(), new Fields("count"));
...
}

35. Spark Streaming
val conf = new SparkConf().setAppName("wordcount")
val ssc = new StreamingContext(conf, Seconds(1))
val text = ...
val counts = text.flatMap(line => line.split(" "))
.map(word => (word, 1))
.reduceByKey(_ + _)
counts.print()
ssc.start()
ssc.awaitTermination()

36. Spark Streaming
val conf = new SparkConf().setAppName("wordcount")
val ssc = new StreamingContext(conf, Seconds(1))
val text = ...
val counts = text.flatMap(line => line.split(" "))
.map(word => (word, 1))
.reduceByKey(_ + _)
counts.print()
ssc.start()
ssc.awaitTermination()

37. val conf = new SparkConf().setAppName("wordcount")
val ssc = new StreamingContext(conf, Seconds(1))
val text = ...
val counts = text.flatMap(line => line.split(" "))
.map(word => (word, 1))
.reduceByKey(_ + _)
counts.print()
ssc.start()
ssc.awaitTermination()
Spark Streaming

38. val conf = new SparkConf().setAppName("wordcount")
val ssc = new StreamingContext(conf, Seconds(1))
val text = ...
val counts = text.flatMap(line => line.split(" "))
.map(word => (word, 1))
.reduceByKey(_ + _)
counts.print()
ssc.start()
ssc.awaitTermination()
Spark Streaming

39. Samza
class WordCountTask extends StreamTask {
override def process(envelope: IncomingMessageEnvelope,
collector: MessageCollector, coordinator: TaskCoordinator) {
val text = envelope.getMessage.asInstanceOf[String]
val counts = text.split(" ")
.foldLeft(Map.empty[String, Int]) {
(count, word) => count + (word -> (count.getOrElse(word, 0) + 1))
}
collector.send(new OutgoingMessageEnvelope(new SystemStream("kafka", "wordcount"),
counts))
}

40. Samza
class WordCountTask extends StreamTask {
override def process(envelope: IncomingMessageEnvelope,
collector: MessageCollector, coordinator: TaskCoordinator) {
val text = envelope.getMessage.asInstanceOf[String]
val counts = text.split(" ")
.foldLeft(Map.empty[String, Int]) {
(count, word) => count + (word -> (count.getOrElse(word, 0) + 1))
}
collector.send(new OutgoingMessageEnvelope(new SystemStream("kafka", "wordcount"),
counts))
}

41. class WordCountTask extends StreamTask {
override def process(envelope: IncomingMessageEnvelope,
collector: MessageCollector, coordinator: TaskCoordinator) {
val text = envelope.getMessage.asInstanceOf[String]
val counts = text.split(" ")
.foldLeft(Map.empty[String, Int]) {
(count, word) => count + (word -> (count.getOrElse(word, 0) + 1))
}
collector.send(new OutgoingMessageEnvelope(new SystemStream("kafka", "wordcount"),
counts))
}
Samza

42. Kafka Streams
final Serde<String> stringSerde = Serdes.String();
final Serde<Long> longSerde = Serdes.Long();
KStream<String, String> textLines = builder.stream(stringSerde, stringSerde,
"streams-file-input");
KStream<String, Long> wordCounts = textLines
.flatMapValues(value -> Arrays.asList(value.toLowerCase().split("W+")))
.groupBy((key, value) -> value)
.count("Counts")
.toStream();
wordCounts.to(stringSerde, longSerde, "streams-wordcount-output");

43. Kafka Streams
final Serde<String> stringSerde = Serdes.String();
final Serde<Long> longSerde = Serdes.Long();
KStream<String, String> textLines = builder.stream(stringSerde, stringSerde,
"streams-file-input");
KStream<String, Long> wordCounts = textLines
.flatMapValues(value -> Arrays.asList(value.toLowerCase().split("W+")))
.groupBy((key, value) -> value)
.count("Counts")
.toStream();
wordCounts.to(stringSerde, longSerde, "streams-wordcount-output");

44. Apex
val input = dag.addOperator("input", new LineReader)
val parser = dag.addOperator("parser", new Parser)
val out = dag.addOperator("console", new ConsoleOutputOperator)
dag.addStream[String]("lines", input.out, parser.in)
dag.addStream[String]("words", parser.out, counter.data)
class Parser extends BaseOperator {
@transient
val out = new DefaultOutputPort[String]()
@transient
val in = new DefaultInputPort[String]()
override def process(t: String): Unit = {
for(w <- t.split(" ")) out.emit(w)
}
}

45. Apex
val input = dag.addOperator("input", new LineReader)
val parser = dag.addOperator("parser", new Parser)
val out = dag.addOperator("console", new ConsoleOutputOperator)
dag.addStream[String]("lines", input.out, parser.in)
dag.addStream[String]("words", parser.out, counter.data)
class Parser extends BaseOperator {
@transient
val out = new DefaultOutputPort[String]()
@transient
val in = new DefaultInputPort[String]()
override def process(t: String): Unit = {
for(w <- t.split(" ")) out.emit(w)
}
}

46. val input = dag.addOperator("input", new LineReader)
val parser = dag.addOperator("parser", new Parser)
val out = dag.addOperator("console", new ConsoleOutputOperator)
dag.addStream[String]("lines", input.out, parser.in)
dag.addStream[String]("words", parser.out, counter.data)
class Parser extends BaseOperator {
@transient
val out = new DefaultOutputPort[String]()
@transient
val in = new DefaultInputPort[String]()
override def process(t: String): Unit = {
for(w <- t.split(" ")) out.emit(w)
}
}
Apex

47. Flink
val env = ExecutionEnvironment.getExecutionEnvironment
val text = env.fromElements(...)
val counts = text.flatMap ( _.split(" ") )
.map ( (_, 1) )
.groupBy(0)
.sum(1)
counts.print()
env.execute("wordcount")

48. Flink
val env = ExecutionEnvironment.getExecutionEnvironment
val text = env.fromElements(...)
val counts = text.flatMap ( _.split(" ") )
.map ( (_, 1) )
.groupBy(0)
.sum(1)
counts.print()
env.execute("wordcount")

49. Summary
Native Micro-batching Native Native
Compositional Declarative Compositional Declarative
At-least-once Exactly-once At-least-once Exactly-once
Record ACKs
RDD based
Checkpointing
Log-based Checkpointing
Not build-in
Dedicated
Operators
Stateful
Operators
Stateful
Operators
Very Low Medium Low Low
Low Medium High High
High High Medium Medium
Micro-batching
Exactly-once*
Dedicated
DStream
Medium
High
Streaming
Model
API
Guarantees
Fault
Tolerance
State
Management
Latency
Throughput
Maturity
TRIDENT
Hybrid
Compositional*
Exactly-once
Checkpointing
Stateful
Operators
Very Low
High
Medium
Native
Declarative*
At-least-once
Low
Log-based
Stateful
Operators
Low
High

50. General Guidelines
As always, It depends

51. General Guidelines
➜ Evaluate particular application needs

52. General Guidelines
➜ Evaluate particular application needs
➜ Programming model

53. General Guidelines
➜ Evaluate particular application needs
➜ Programming model
➜ Available delivery guarantees

54. General Guidelines
➜ Evaluate particular application needs
➜ Programming model
➜ Available delivery guarantees
➜ Almost all non-trivial jobs have state

55. General Guidelines
➜ Evaluate particular application needs
➜ Programming model
➜ Available delivery guarantees
➜ Almost all non-trivial jobs have state
➜ Fast recovery is critical

56. Recommendations [Storm & Trident]
● Fits for small and fast tasks
● Very low (tens of milliseconds) latency
● State & Fault tolerance degrades performance significantly
● Potential update to Heron
○ Keeps the API, according to Twitter better in every single way
○ Open-sourced recently

57. Recommendations [Spark Streaming]
● Spark Ecosystem
● Data Exploration
● Latency is not critical
● Micro-batching limitations

58. Recommendations [Samza]
● Kafka is a cornerstone of your architecture
● Application requires large states
● Don’t need exactly once

59. Recommendations [Kafka Streams]
● Similar functionality like Samza with nicer APIs
● Operated by Kafka itself
● Great learning curve
● At-least once delivery
● May not support more advanced functionality

60. Recommendations [Apex]
● Prefer compositional approach
● Hadoop
● Great performance
● Dynamic DAG changes

61. Recommendations [Flink]
● Conceptually great, fits very most use cases
● Take advantage of batch processing capabilities
● Need a functionality which is hard to implement in micro-batch
● Enough courage to use emerging project

62. Dataflow and Apache Beam
Dataflow
Model & SDKs
Apache Flink
Apache Spark
Direct Pipeline
Google Cloud
Dataflow
Stream Processing
Batch Processing
Multiple Modes One Pipeline Many Runtimes
Local
or
cloud
Local
Cloud

63. Questions
MANCHESTER LONDON NEW YORK

64. MANCHESTER LONDON NEW YORK
@petr_zapletal @cakesolutions
347 708 1518
enquiries@cakesolutions.net
We are hiring
http://www.cakesolutions.net/careers

65. References
● http://storm.apache.org/
● http://spark.apache.org/streaming/
● http://samza.apache.org/
● https://apex.apache.org/
● https://flink.apache.org/
● http://beam.incubator.apache.org/
● http://www.cakesolutions.net/teamblogs/comparison-of-apache-stream-processing-frameworks-part-1
● http://data-artisans.com/blog/
● http://www.confluent.io/blog/introducing-kafka-streams-stream-processing-made-simple
● https://yahooeng.tumblr.com/post/135321837876/benchmarking-streaming-computation-engines-at
● http://www.slideshare.net/GyulaFra/largescale-stream-processing-in-the-hadoop-ecosystem
● https://www.oreilly.com/ideas/the-world-beyond-batch-streaming-101
● http://stackoverflow.com/questions/29111549/where-do-apache-samza-and-apache-storm-differ-in-their-use-cases
● https://www.dropbox.com/s/1s8pnjwgkkvik4v/GearPump%20Edge%20Topologies%20and%20Deployment.pptx?dl=0
● ...

66. List of Figures
● https://databricks.com/blog/2015/07/30/diving-into-apache-spark-streamings-execution-model.html
● http://www.slideshare.net/ptgoetz/storm-hadoop-summit2014
● https://databricks.com/wp-content/uploads/2015/07/image41-1024x602.png
● http://data-artisans.com/wp-content/uploads/2015/08/microbatching.png
● http://samza.apache.org/img/0.9/learn/documentation/container/stateful_job
● http://data-artisans.com/wp-content/uploads/2015/08/streambarrier.png
● https://cwiki.apache.org/confluence/display/FLINK/Stateful+Stream+Processing
● https://raw.githubusercontent.com/tweise/apex-samples/kafka-count-jdbc/exactly-once/docs/images/image00.png
● https://4.bp.blogspot.com/-RlLeDymI_mU/Vp-1cb3AxNI/AAAAAAAACSQ/5TphliHJA4w/s1600/dataflow%2BASF.pn
g

67. Backup Slides
MANCHESTER LONDON NEW YORK

68. Processing Architecture Evolution
Batch Pipeline
Serving DBHDFS
Query

69. Processing Architecture Evolution
Lambda Architecture
Batch Layer Serving
Layer
Stream layer
Query
Allyourdata
Oozie
Query

70. Processing Architecture Evolution
Standalone Stream Processing
Stream
Processing

71. Processing Architecture Evolution
Kappa Architecture
Query
Stream
Processing

72. ETL Operations
● Transformations, joining or filtering of incoming
data
Streaming Applications

73. Windowing
● Trends in bounded interval, like tweets or sales
Streaming Applications

74. Streaming Applications
Machine Learning
● Clustering, Trend fitting,
Classification

75. Streaming Applications
Pattern Recognition
● Fraud detection, Signal
triggering, Anomaly detection

76. Fault tolerance in streaming systems is
inherently harder that in batch
Fault Tolerance

77. Managing State
f: (input, state) => (output, state’)

78. Performance
Hard to design not biased test, lots
of variables

79. Performance
➜ Latency vs. Throughput

80. Performance
➜ Latency vs. Throughput
➜ Costs of Delivery Guarantees, Fault-tolerance & State Management

81. Performance
➜ Latency vs. Throughput
➜ Costs of Delivery Guarantees, Fault-tolerance & State Management
➜ Tuning

82. Performance
➜ Latency vs. Throughput
➜ Costs of Delivery Guarantees, Fault-tolerance & State Management
➜ Tuning
➜ Network operations, Data locality & Serialization

83. Project Maturity
When picking up the framework, you
should always consider its maturity

84. For a long time de-facto industrial
standard
Project Maturity [Storm & Trident]

85. Project Maturity [Spark Streaming]
The most trending Scala repository
these days and one of the engines
behind Scala’s popularity

86. Project Maturity [Samza]
Used by LinkedIn and also by tens of
other companies

87. Project Maturity [Kafka Streams]
???

88. Project Maturity [Apex]
Graduated very recently, adopted by
a couple of corporate clients already

89. Project Maturity [Flink]
Still an emerging project, but we can
see its first production deployments
