1. R.M K COLLEGE OF ENGINEERING & TECHNOLOGY
DEPARTMENT OF ECE
DIGITAL ELECTRONICS
UNIT 1 SAMPLE MCQ -PART A QUESTIONS

2. 1. The smaller unit of binary data
a) Nibble
b) Bit
c) Byte
d) word
2. A 64 bit word consists of
a) 4 bits
b) 4 bytes
c) 8 bytes
d) 8 bits
Correct Answer : B
Correct Answer : C

3. 3. Nibble is a collection of
a) 8 bits
b) 16 bits
c) 2bits
d) 4 bits
4. How many possible values for digital signals?
a) 4
b) 2
c) 8
d) 1
Correct Answer : D
Correct Answer : B

4. 5. Which number system has a base of 16
a) Decimal
b) Octal
c) Hexadecimal
d) Binary
6. Binary representation of decimal number (18)10 is
a) (10000)2
b) (10010)2
c) (10001)2
d) (10100)2
Correct Answer : C
Correct Answer : B

5. 7.Which of the following statement is not correct?
a) Noise is an analog signal
b) Variation of resistance in Light Dependent Resistor is an analog signal
c) Human voice is a digital signal
d) Room temperature measured during a particular period is an analog signal
Correct Answer : C

6. 8.Moore’s law states that:
a. The cost of semiconductor tools doubles every four years
b. The cost of semiconductor tools doubles every two years
c. The number of transistors on a chip double annually
d. The number of transistors on a chip doubles every four years
Correct Answer : C

7. 9.Boolean expression can be minimized using
a) Algebraic Method
b) De-morgan’s Law
c) Karnaugh Map
d) Both a & c
Correct Answer : D

8. 10.The SOP expression F=AB+CD is equivalent to the POS expression
a) (A+B) (C+D)
b) (A+C)(B+C)(A+D)(B+D)
c) (A+B) (C+D’)
d) (A+B) (C+D) (B+D)
Correct Answer : B

9. 11. Product-of-Sums expressions can be implemented using
a) 2-level OR-AND logic circuits
b) 2-level NOR logic circuits
c) 2-level XOR logic circuits
d) both option a & b is correct
Correct Answer : D

10. 12.Interpret the following logic Circuit as Boolean expression:
Correct Answer : D
OPTIONS:
A. F=AB+CD
B. F=A+B.C+D
C. F=AC+BD
D. F=AB’+C’D

11. Correct Answer : C
14. Give the dual of the Boolean expression (B’ + C) . A. C
OPTIONS:
A. F=AB+AC
B. F=AC+B.C
C. F=B’C+A+C
D. F=B’A+AC’

12. 15. Which are called Universal gates ?
OPTIONS:
A. NAND
B. NOR
C. Both A &B
D. A or B
Correct Answer : C
