Deploy and scale your PHP Application with AWS ElasticBeanstalk and Docker

1. Deploy and Scale your PHP App using
Docker containers and AWS Beanstalk
Walter Dal Mut
@walterdalmut - github.com/wdalmut

2. I'm co-founder of @CorleyCloud
application development
infrastructure and application migration on cloud
I'm also a co-founder of @UpCloo
U.K. based startup: powering related content across the web
walter.dalmut@gmail.com

3. First of all we have to agree on
what scaling is for this talk

4. scalability is not high availability
Scalability is the ability of a system to handle a growing amount of work in capable manner or the ability to be
enlarged to accomodate that growth (from wikipedia)

5. Adapting Infrastructures

6. From single instances point of view

7. It is also meaning that with fixed hardware
we have to provide the highest computing capacity

8. Money wasters?

9. With Cloud Providers

10. About ElasticBeanstalk
Load Balanced web applications
Single instance web applications
Queue daemons (SQS)

11. Load balanced web applications

12. Autoscalable infrastructures

13. thresholds are used to
create and remove instances

14. with (auto)scalable infrastructures
How to manage application upgrades
How to monitor servers
How to handle servers configurations
How to handle instances logs
...
ElasticBeanstalk help us with this things

15. Application Deploy

16. Mainly Beanstalk takes a ZIP artifact
(the PHP application)
and unpack it into the environment
Uses YML definitions in order to setup the environment

17. The deploy cycle take care of:
1. Packages
2. Users & Groups
3. Files
4. Commands
before the application and web server are set up
5. Services
6. Container_commands
just before the application version is deployed

18. Configure PHP details
files:
"/etc/php.d/my­timezone.ini" :
mode: "000644"
owner: root
group: root
content: |
date.timezone = Europe/Rome
You can also use beanstalk options

19. extract your application logs
commands:
21_application_logs:
command: echo "/var/app/current/app/logs/*.log" > app.conf
cwd: /opt/elasticbeanstalk/tasks/bundlelogs.d
22_application_logs:
command: echo "/var/app/current/app/logs/*.log" > app.conf
cwd: /opt/elasticbeanstalk/tasks/systemtaillogs.d
23_application_logs:
command: echo "/var/app/current/app/logs/*.log" > app.conf
cwd: /opt/elasticbeanstalk/tasks/taillogs.d
24_application_logs:
command: echo "/var/app/current/app/logs/*.log" > app.conf
cwd: /opt/elasticbeanstalk/tasks/publishlogs.d
And check them directly from the web console

20. Beanstalk works with different
application containers
PHP, Node.js, Tomcat, Python, Ruby
and...
Docker & Multicontainer Docker
Multicontainer Docker is connected to ElasticContainer Service

21. Why docker is interesting for
ElasticBeanstalk?
When there is a default PHP container with
different available versions: 5.3, 5.4, 5.5, 5.6

22. Instances are Amazon Linux
Difficult to configure a different distro: ubuntu, debian ...
Even packages: supervisors, agents etc.
Difficult to replicate the env locally (dev).

23. Default PHP container configuration
{{ Apache - MOD_PHP }}

24. The application path change
after the deploy cycle
/var/app/ondeck->/var/app/current
Symfony2 cache warmup problems...

25. With Docker we can create a more
dedicated setup
{{ Nginx - PHP-FPM }}

26. The docker environment is more stable
and testable than the default one
Thanks to the docker isolation nature
File are uncompressed into: /var/app/current

27. Prepare a web server
FROM ubuntu:14.04
RUN apt­get update && apt­get install ­y php5 apache2 libapache2­mod­php5
php5­apcu php5­curl php5­mongo php5­xsl && rm ­rf /var/lib/apt/lists/*
RUN a2enmod rewrite deflate expires headers
EXPOSE 80
CMD ["/usr/sbin/apache2ctl", "­D", "FOREGROUND"]
prepare your Dockerfile

28. You can build the container during the
deploy cycle
Just let the `Dockerfile` in the root folder of your project

29. dockerbuild-twdalmut/webserver.
dockerpush

30. Docker containers are engaged with:
https://registry.hub.docker.com/
+ automated builds! (keep container up to date automatically)
Already provisioned containers

31. You can use it
for your development
dockerpullwdalmut/webserver
dockerrun
-p8080:80
-v`pwd`:/var/www/html
-dwdalmut/webserver
Use Vagrant docker provisioner for your dev environments

32. Same environment in ElasticBeanstalk
Dockerrun.aws.json
{
"AWSEBDockerrunVersion": "1",
"Image": {
"Name": "wdalmut/webserver",
"Update": "true"
},
"Ports": [
{
"ContainerPort": "80"
}
],
"Volumes": [
{
"HostDirectory": "/var/app/current",
"ContainerDirectory": "/var/www/html"
}
],
"Logging": "/var/log/app"
}

33. Beanstalk proxies
with nginx
your first exposed port
80->EXPOSE*****[,******]

34. Ok, we have the infrastructure
And about the application setup?

35. App tuning with environment variables
<?php
$env=getenv("SYMFONY__ENV");

36. download config files from S3
Resources:
AWSEBAutoScalingGroup:
Type: "AWS::AutoScaling::AutoScalingGroup"
Metadata:
AWS::CloudFormation::Authentication:
S3AccessCred:
type: "S3"
roleName: "aws­elasticbeanstalk­ec2­role"
buckets: "myapp­deploy"
files:
"/root/parameters.yml":
mode: "000400"
owner: root
group: root
source: https://s3­eu­west­1.amazonaws.com/myapp­deploy/parameters.yml
container_commands:
01_copy_configuration:
command: cp /root/parameters.yml app/config/parameters.yml
remember that EC2 IAM roles should be configured correctly

37. EC2 Role configuration
{
"Version": "2012­10­17",
"Statement": [
{
"Sid": "Stmt1305192283000",
"Effect": "Allow",
"Action": [
"s3:*"
],
"Resource": [
"arn:aws:s3:::app­deploy/",
"arn:aws:s3:::app­deploy/*"
]
}
]
}
Could be more detailed and restricted than this example

38. You cannot use PHP from the host
(it is in the docker container)...
You have to pass commands via docker containers
dockerrun
--rm-i-t
-v/var/app/current:/var/www/html
wdalmut/webserver
app/consoleca:cl-e=prod

39. Thanks for listening
