COVER CONCEPT BY DAN RODD

OCTOBER 2007 VOL. 15, NO. 10

ABOUT THE COVER
Used primarily in long-
haul OSP applications, features
9
fusion splicing is now
an alternative to field A close examination of
terminations in the data UTP cabling performance
center due to its effectiveness Answers to many of the”why” questions associated
in meeting critical density
with the installation and maintenance of unshielded
and performance demands.
TO LEARN MORE,
twisted-pair systems. JAMES ANDRESS
SEE PAGE 27.

21 Using an OTDR: How to keep it simple
Not just for use in public networks, the optical time-
domain reflectometer no longer has to be an
intimidating tool. CHRISTIAN SCHILLAB

27 The ins and outs of fusion splicing
Still primarily for use in the outside plant, the technology is now
seeing deployment in premises applications. BETSY ZIOBRON

35 Enclosures play a role
in thermal management
Dealing with heat close to its source takes
several forms. PATRICK MCLAUGHLIN

39 Surveillance market seeing
many IP rumblings
Acquisitions, alliances, and increasing attention are more evidence of
the shift to Internet Protocol-based systems. PATRICK MCLAUGHLIN departments
