1. Browsers
with
Wings:
HTML5
& APIs

6. HTML5 brand

9. HTML5 is:
markup,
JavaScript, CSS,
SVG, jQuery &
your dinner.

10. HTML5 is:
markup, Lie.
Don'CSS,
JavaScript, t be
stoop
id
SVG, jQuery & ,
but...
your dinner.

11. HTML5 is
anything & everything
to mere mortal beings.

12. Today

13. Media

14. <video src=bruce.mp4>

16. <video src=bruce.mp4>
<a href="bruce.mp4">Download</a>
</video>

17. Codec Wars

18. <video>
<source src=bruce.mp4>
<source src=bruce.ogv>
</video>

19. <video>
<source src=bruce.webm>
<source src=bruce.mp4>
<source src=bruce.ogv>
</video>

20. <video controls>
<source src=bruce.mp4>
<source src=bruce.ogv>
</video>

28. <video>
works i n IE6

29. <video>
wo L n .IE6
rks iie

30. http://camendesign.com/code/video_for_everybody
<video width="640" height="360" controls preload="none">
<!-- MP4 must be first for iPad! -->
<source src="__VIDEO__.MP4" type="video/mp4" /><!-- WebKit video -->
<source src="__VIDEO__.OGV" type="video/ogg" /><!-- Firefox / Opera -->
<!-- fallback to Flash: -->
<object width="640" height="384" type="application/x-shockwave-flash"
data="__FLASH__.SWF">
<!-- Firefox uses the `data` attribute above, IE/Safari uses the param below -->
<param name="movie" value="__FLASH__.SWF" />
<param name="flashvars" value="image=__POSTER__.JPG&amp;file=__VIDEO__.MP4" />
<!-- fallback image. note the title field below, put the title of the video there -->
<img src="__VIDEO__.JPG" width="640" height="360" alt="__TITLE__"
title="No video playback capabilities, please download the video below" />
</object>
</video>
<!-- you *must* offer a download link as they may be able to play the file locally.
customise this bit all you want -->
<p> <strong>Download Video:</strong>
Closed Format: <a href="__VIDEO__.MP4">"MP4"</a>
Open Format: <a href="__VIDEO__.OGV">"OGG"</a>
</p>

31. Custom player style

32. function toggle() {
if (video.paused) {
video.play();
this.innerHTML = 'Pause';
} else {
video.pause();
this.innerHTML = 'Play';
}
}
var play = document.getElementById('play');
play.onclick = toggle;

33. function toggle() {
if (video.paused) {
video.play();
this.innerHTML = 'Pause';
} else {
video.pause();
this.innerHTML = 'Play';
}
}
var play = document.getElementById('play');
play.onclick = toggle;

34. function toggle() {
if (video.paused) {
video.play();
this.innerHTML = 'Pause';
} else {
video.pause();
this.innerHTML = 'Play';
}
}
var play = document.getElementById('play');
play.onclick = toggle;

35. function toggle() {
if (video.paused) {
video.play();
this.innerHTML = 'Pause';
} else {
video.pause();
this.innerHTML = 'Play';
}
}
var play = document.getElementById('play');
play.onclick = toggle;

36. // get & set
video.currentTime
// half speed
video.playbackRate = 0.5
// actual loaded video
video.currentSrc
// etc

37. video.ontimeupdate = function () {
updatePlayhead(this.currentTime);
};

38. Fullscreen?

39. Warning! User agents should not provide a public API to cause
videos to be shown full-screen. A script, combined with a carefully
crafted video file, could trick the user into thinking a system-modal
dialog had been shown, and prompt the user for a password. There is
also the danger of "mere" annoyance, with pages launching full-
screen videos when links are clicked or pages navigated. Instead,
user-agent specific interface features may be provided to easily allow
the user to obtain a full-screen playback mode.

42. Canvas
Cooler than a fake Han Solo.

43. First consider SVG:
Standard
Vertical
Graphing

44. First consider SVG:
Standard
Vertical
Lie.
Graphing

45. First consider SVG:
Standard a lie.
Not
Vertical
Lie.
Graphing

46. SVG: Vector based, good for simple
and interactive
Canvas: Pixel based, good for pixel
manipulation & high animation
Check out raphaeljs.com

48. Mix & match
to the
technology's
strength

49. pixel
pushing

50. http://mugtug.com/darkroom

51. var ctx = canvas.getContext('2d');
ctx.getImageData(0,0,w,h)

52. ctx.getImageData(0, 0, w, h);
0 1 2 3
i = 0 r g b a
i = 1 r g b a
i... r g b a

53. pixels.data[i * 4 + 0];
0 1 2 3
i = 0 r g b a
i = 1 r g b a
i... r g b a

54. pixels.data[i * 4 + 1];
0 1 2 3
i = 0 r g b a
i = 1 r g b a
i... r g b a

55. pixels.data[i * 4 + 2];
0 1 2 3
i = 0 r g b a
i = 1 r g b a
i... r g b a

56. pixels.data[i * 4 + 3];
0 1 2 3
i = 0 r g b a
i = 1 r g b a
i... r g b a

57. var px = ctx.getImageData(0, 0, w, h),
l = px.data.length,
i;
for (i = 0; i < l; i += 4) {
}

58. var px = ctx.getImageData(0, 0, w, h),
l = px.data.length,
i;
for (i = 0; i < l; i += 4) {
This says loop
over each pixel
}

59. var px = ctx.getImageData(0, 0, w, h),
l = px.data.length,
i;
for (i = 0; i < l; i += 4) {
px.data[i+0] = 255 - px.data[i+0];
}

60. var px = ctx.getImageData(0, 0, w, h),
l = px.data.length,
i;
for (i = 0; i < l; i += 4) {
px.data[i+0] = 255 - px.data[i+0];
px.data[i+1] = 255 - px.data[i+1];
}

61. var px = ctx.getImageData(0, 0, w, h),
l = px.data.length,
i;
for (i = 0; i < l; i += 4) {
px.data[i+0] = 255 - px.data[i+0];
px.data[i+1] = 255 - px.data[i+1];
px.data[i+2] = 255 - px.data[i+2];
}

62. var px = ctx.getImageData(0, 0, w, h),
l = px.data.length,
i;
for (i = 0; i < l; i += 4) {
px.data[i+0] = 255 - px.data[i+0];
px.data[i+1] = 255 - px.data[i+1];
px.data[i+2] = 255 - px.data[i+2];
// don't need to do the alphachannel
}

63. var px = ctx.getImageData(0, 0, w, h),
l = px.data.length,
i;
for (i = 0; i < l; i += 4) {
px.data[i+0] = 255 - px.data[i+0];
px.data[i+1] = 255 - px.data[i+1];
px.data[i+2] = 255 - px.data[i+2];
// don't need to do the alphachannel
}
ctx.putImageData(px, 0, 0);

66. You can do
that in SVG,
but you can't
do this:

67. http://mrdoob.com

68. canvas.toDataURL()

69. canvas.toDataURL()

png;base64,iVBORw0KGgoAA
AGQCAYAAACAvzbMAAAgAElEQ
f2e692YghpAYQuYQQaP9U8Ur
Q4gSwXNbREIaqVKlpVFPq6G0
VIhMZJDc3OEM/
99v7b3P2efcfc49e5+9z9nDd
+67PWWd
+95liOD8IBAiAAAiAAAjYJxG
GAgCAjgAAIgAAIOCIAAXGEDY
ACIAACjghAQBxhgyMQAAEQAA
IQEEfY4AgEQAAEQAACgjwAAi
IBEAABEICAIA
+AAAiAAAg4IgABcYQNjkAABE
KOCEBAHGGDIxAAARAAAQgI8g

71. Shims
1. Silverlight
Bridge
2. excanvas.js

72. Storage

73. Cookies
suck.
(for most situations)

74. The code for
cookies is
painful: so
we google it.

75. "Session"
cookies
leak across
"sessions".

76. Non-session
cookies require
"special"
date format

77. Deleting
cookies,
doesn't delete,
but sets it
in the past.

78. Fuck cookies.

79. Sexy Web Storage FTW

80. Key/value pair

81. One API
setItem(key, value)

82. One API
setItem(key, value)
string* getItem(key)

83. One API
setItem(key, value)
string* getItem(key)
removeItem(key)

84. One API
setItem(key, value)
string* getItem(key)
removeItem(key)
string key(index)

85. One API
setItem(key, value)
string* getItem(key)
removeItem(key)
string key(index)
clear()

86. One API
setItem(key, value)
string* getItem(key)
removeItem(key)
string key(index)
clear()
.length

87. Two instances
localStorage
sessionStorage

88. localStorage
• Persists
• Applied to document origin, i.e.
scheme/host/port tuple
• No expiry

89. sessionStorage
• Lasts whilst on the document origin
• Doesn't leak
• Exactly the same API as localStorage

90. var ss = sessionStorage;
ss.setItem('version', 12);
ss.getItem('version');

91. rnin g!
Wa
Values are strings

92. rnin g!
Wa
Values are strings
Work around: JSON
(and http://www.json.org/json2.js)

93. var ss = sessionStorage,
user = { screen_name : ‘rem’,
rating : 11 };
ss.setItem(‘user’, JSON.stringify(user));
var obj = JSON.parse(ss.getItem(‘user’));
alert(obj.screen_name);

97. window.name shim
http://gist.github.com/350433

98. Alternatives

99. Web SQL Database

100. IndexedDB

101. Geolocation

103. navigator.geolocation

104. getCurrentPosition
watchPosition
clearPosition

105. var geo = navigator.geolocation;
geo.getCurrentPosition(function(data){
map(data.coords.latitude,
data.coords.longitude);
});

106. var geo = navigator.geolocation;
geo.getCurrentPosition(function(data){
map(data.coords.latitude,
data.coords.longitude);
});

107. var geo = navigator.geolocation;
geo.getCurrentPosition(function(data){
map(data.coords.latitude,
data.coords.longitude);
});

108. var geo = navigator.geolocation;
geo.getCurrentPosition(function(data){
map(data.coords.latitude,
data.coords.longitude);
});

109. var geo = navigator.geolocation;
geo.getCurrentPosition(function(data){
map(data.coords.latitude,
data.coords.longitude);
});

111. Check your accuracy

112. http://j.mp/geoshim
if (!navigator.geolocation) {
navigator.geolocation = (function (window) {
function getCurrentPosition(callback) {
// source: http://www.maxmind.com/app/javascript_city
var geourl = 'http://j.maxmind.com/app/geoip.js_' + Math.random(),
iframe = document.createElement('iframe'),
doc, win;
iframe.style.display = 'none';
window.document.body.appendChild(iframe);
doc = iframe.contentDocument || iframe.contentWindow.document;
win = iframe.contentWindow;
// once the script has loaded, it triggers an onload event
iframe.onload = function () {
// assign all the captured values across to our geo object
var geo = {
coords: {
latitude: win.geoip_latitude(),
longitude: win.geoip_longitude()
// other values are supported, i.e. accuracy, speed, heading, etc
},
timestamp: (new Date()).getTime()

113. Sockets

114. Move
over
comet.

115. Low latency.
Direct connection.
Simple API.

116. var url = 'ws://apps.leftlogic.com:8000/',
conn = new WebSocket(url);
conn.onmessage = function (event) {
console.log(JSON.parse(event.data));
};
conn.send('hello world');

117. var url = 'ws://apps.leftlogic.com:8000/',
conn = new WebSocket(url);
conn.onmessage = function (event) {
console.log(JSON.parse(event.data));
};
conn.send('hello world');

118. var url = 'ws://apps.leftlogic.com:8000/',
conn = new WebSocket(url);
conn.onmessage = function (event) {
console.log(JSON.parse(event.data));
};
conn.send('hello world');

119. var url = 'ws://apps.leftlogic.com:8000/',
conn = new WebSocket(url);
conn.onmessage = function (event) {
console.log(JSON.parse(event.data));
};
conn.send('hello world');

120. var url = 'ws://apps.leftlogic.com:8000/',
conn = new WebSocket(url);
conn.onmessage = function (event) {
console.log(JSON.parse(event.data));
};
conn.send('hello world');

121. var url = 'ws://apps.leftlogic.com:8000/',
conn = new WebSocket(url);
conn.onmessage = function (event) {
console.log(JSON.parse(event.data));
};
conn.send('hello world');

122. http://rem.im/collab-drawing

123. http://rem.im/collab-drawing

124. http://rem.im/collab-drawing

125. http://github.com/gimite/web-socket-js/

126. Partial

127. Offline

128. Using a Manifest
<!DOCTYPE html>
<html manifest="my.manifest">
<body>
<!-- my page -->
</body>
</html>

129. my.manifest
CACHE MANIFEST
app.html
css/style.css
js/app.js
#version 13

130. The Manifest
1. Serve as text/manifest, by
adding to mime.types:
text/cache-manifest manifest

131. t ip Firefox caching
<IfModule mod_expires.c>
ExpiresActive on
ExpiresByType text/cache-manifest
↪ “access plus 0 seconds”
</IfModule>

132. The Manifest
2. First line must be:
CACHE MANIFEST

133. The Manifest
3. Including page is implicitly
included in the cache.

134. The Manifest
4. Include some versioning to
cache bust your manifest
# version 16

135. The Manifest
5. Two futher namespaces:
NETWORK & FALLBACK
FALLBACK:
/ offline.html

136. CACHE MANIFEST
CACHE:
app.js
app.css
index.html
NETWORK:
/live/*
FALLBACK:
* offline.html

137. CACHE MANIFEST
CACHE:
app.js
Served from cache app.css
index.html
NETWORK:
/live/*
FALLBACK:
* offline.html

138. CACHE MANIFEST
CACHE:
app.js
app.css
index.html
Requests to
http://mysite.com/live/x NETWORK:
/live/*
must go via the web
FALLBACK:
* offline.html

139. CACHE MANIFEST
CACHE:
app.js
app.css
Requests for files not
index.html
found in the cache,
NETWORK:
are directed to /live/*
offline.html (when
FALLBACK:
offline). / offline.html

140. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

141. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

142. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

143. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

144. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

145. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

146. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

147. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

148. Browser: I have a
Browser: request Server: serve all manifest, cache
assets
Browser:
Server: serve
applicationCache Browser: reload
manifest assets
updated
Browser: only
Browser: serve Server: 304 Not
request manifest
locally Modified
file

149. File API

150. files[0].getAsDataURL()

151. files[0].getAsDataURL()

153. Link prefetching
Web Workers
Web Forms
Hash change event, history state management
Contenteditable
Native drag and drop - embedding of data
Microdata
Cross server messaging
embedded attribute data
mime-type registration
DXHTML6

154. Link prefetching
Web Workers
Web Forms
Hash change event, history state management
Contenteditable
Native drag and drop - embedding of data
Microdata
Cross server messaging
embedded attribute data
mime-type registration Lie.
DXHTML6

155. "Should I be
using HTML5
today?"

156. 1. doctype, script & styles only

157. 1. doctype, script & styles only
2. New HTML5 elements

158. 1. doctype, script & styles only
2. New HTML5 elements
3. Existing APIs

159. 1. doctype, script & styles only
2. New HTML5 elements
3. Existing APIs
4. Shims

160. Yes.

161. introducinghtml5.com
Yes.
@rem
remy@leftlogic.com
