Puppeteer can automate that! - Frontmania

possibly
Puppeteer can
automate that!
with the help of minions

Önder Ceylan
@onderceylan
Sharing knowledge on #javascript, #typescript, #angular, #ionic and #pwa
JS Squad Lead @LINKIT
Speaker, Organiser @ITNEXT
Speaker, Organiser @GDG NL

Headless Chrome
chrome —-headless —-remote-debugging-port=9222

–Puppeteer docs
“Most things that you can do
manually in the browser can be
done using Puppeteer! ”

Examples to get you started
• Generate screenshots and PDFs of pages
• Crawl a SPA and generate pre-rendered
content
• Automate form submission, UI testing,
keyboard input, etc
• Capture a timeline trace of your site to
help diagnose performance issues

puppeteer.launch().then(async browser => {
  const page = await browser.newPage();
  await page.goto('https://www.linkit.nl');
  await page.screenshot({path: 'screenshot.png'});
  await browser.close();
});

github.com/transitive-bullshit/awesome-puppeteer

Alex ! "
Xander # $
Ellen % &
Yelda ' (

Emulating color scheme NEW 
in v2

await page.goto('https://googlechromelabs.github.io/dark-mode-toggle/demo/index.html'); 
await page.emulateMediaFeatures([{ name: 'prefers-color-scheme', value: 'light' }]); 
await page.screenshot({ path: 'light.jpg', type: 'jpeg', omitBackground: true }); 
await page.emulateMediaFeatures([{ name: 'prefers-color-scheme', value: 'dark' }]);
await page.screenshot({ path: 'dark.jpg', type: 'jpeg', omitBackground: true });
Emulating color scheme NEW 
in v2

await page.goto('https://frontmania.com');
await page.addScriptTag(
{ url: 'https://cdnjs.cloudflare.com/ajax/libs/axe-core/3.3.2/axe.min.js' }
);
const results = await page.evaluate(() => axe.run(document));
 
expect(results.violations.length).toBe(0);
Accessibility test

const pti = require('puppeteer-to-istanbul');
 
await page.coverage.startJSCoverage();
await page.goto('https://www.linkit.nl/');
const jsCoverage = await page.coverage.stopJSCoverage();
 
pti.write(jsCoverage);
await page.close();
Code coverage test

throttle network
track memory usage
emulate devices
run audits

github.com/ChromeDevTools/devtools-frontend

Protocol Monitor
chrome://flags/#enable-devtools-experiments

chrome —-remote-debugging-port=9222
Chrome DevTools
Protocol

chromedevtools.github.io/devtools-protocol

github.com/ChromeDevTools/awesome-chrome-devtools

Using DevTools
Protocol with PPTR

puppeteer.launch().then(async browser => {
const session = await page.target().createCDPSession();
  session.on('Animation.animationCreated', () => {
    console.log('Animation created!');
  });
  await session.send('Animation.enable');
  await session.send('Animation.setPlaybackRate', {
    playbackRate: 10,
  });
});

Puppeteer Core
npm i puppeteer-core

Puppeteer Core
browser = await puppeteer.connect({
browserWSEndpoint: 'ws://127.0.0.1:9222/.../...'
});
// or
browser = await puppeteer.launch({
executablePath: '/Applications/Google Chrome.app
/Contents/MacOS/Google Chrome'
});

Chrome Launcher
npm i chrome-launcher

// Launches a debugging instance of Chrome
function launchChrome(headless=true) {
  return chromeLauncher.launch({
    // port: 9222,
    chromeFlags: [
      '--window-size=412,732',
      '--disable-gpu',
      headless ? '--headless' : ''
    ]
  });
}
launchChrome().then(chrome => {
  console.log(`Chrome debuggable on port: ${chrome.port}`);
  // chrome.kill();
});
chrome instance

Puppeteer Light
npm i puppeteer-core
npm i chrome-launcher

github.com/onderceylan/pwa-asset-generator

await Promise.all(filters.map(async (filter) => {
await page.setContent(`
<style>/* Page styles here */</style>
<figure class="${filter}">
<img src="${getImageBase64Url('./sample.jpg')}">
<span>@onderceylan</span>
</figure>
`, { waitUntil: 'networkidle2' });
await page.addStyleTag({
url: 'https://cdnjs.cloudflare.com/ajax/libs/cssgram/0.1.10/cssgram.min.css'
});
// Get original image dimensions
const { width, height } = await page.evaluate(() => {
return (({naturalWidth: width, naturalHeight: height}) =>
({width, height}))(document.querySelector('img'));
});
await page.setViewport({ width, height });
await page.screenshot({
path: `pptgram/pptrgram-${filter}.jpeg`,
type: 'jpeg',
quality: 70,
fullPage: true,
});
});
PptrGram

await page.goto(`http://localhost:8002/tensorflow.html`);
const result = await page.evaluate(() => {
const img = document.getElementById('img');
// Load the model
return cocoSsd.load().then(model => model.detect(img))
});
console.log(result);
PptrFlow

await page.goto('https://www.linkit.nl/');
expect(await page.content()).toMatchSnapshot();
DOM Snapshot Testing

await page.tracing.start({ path: 'trace.json' }); 
await page.goto('https://www.google.com'); 
await page.tracing.stop();
Timeline Trace Monitoring

const protocol = await page.target().createCDPSession();
await protocol.send('HeapProfiler.enable');
await protocol.send('HeapProfiler.collectGarbage');
const startMetrics = await page.metrics();
// Do memory regressions here by interacting with the page
await protocol.send('Input.synthesizeScrollGesture', {
x: 100,
y: 100,
yDistance: -400,
repeatCount: 3
});
await protocol.send('HeapProfiler.collectGarbage');
const endMetrics = await page.metrics();
expect(endMetrics.JSHeapUsedSize < startMetrics.JSHeapUsedSize * 1.1)
.toBeTruthy();
Memory leak by Heap

// Get a handle to the Map object prototype
const mapPrototype = await page.evaluateHandle(() => Map.prototype);
// Query all map instances into an array
const mapInstances = await page.queryObjects(mapPrototype);
// Count amount of map objects in heap
const count = await page.evaluate(maps => maps.length, mapInstances);
// Idea here is to test object instances on the page
// where it's expected to be invalidated
expect(count).toBe(0);
Memory leak by Prototype

Monitor change on security state

const protocol = await page.target().createCDPSession(); 
await protocol.send('Security.enable');
protocol.on('Security.securityStateChanged', console.log);
Monitor change on security state

Monitor SSL certificate expiration

page.on('response', (resp) => {
const url = resp.url(); 
if (url === siteUrl) {
const secDetails = resp.securityDetails();
const now = Math.floor((new Date()).getTime() / 1000); 
console.log((Math.floor((secDetails.validTo() - now) / 86400)),
'days to expire');
}
});
await page.goto(siteUrl, { waitUntil: 'networkidle0' });
Monitor SSL certificate expiration

Main Takeaways
• Chrome can be instrumented with a WS connection over
Chrome DevTools Protocol — CDP
• You might not need to download chromium revision every time
—puppeteer-core + chrome-launcher
• Headless chrome can be executed on servers— cloud, and CI
pipelines
• You can automate anything you do on DevTools, by using raw
protocol of CDP on puppeteer—CDPSession

Thank you!
@onderceylan
https://github.com/onderceylan/puppeteer-demos
