Best Practices In Implementing Container Image Promotion Pipelines
- 1. Best Practices In Implementing Container Image Promotion Pipelines
- 3. Software I like Software I know really well @jbaruch #ATO http://jfrog.com/shownotes
- 6. shownotes Øhttp://jfrog.com/shownotes ØSlides ØVideo ØLinks ØComments, Ratings ØRaffle @jbaruch #ATO http://jfrog.com/shownotes
- 9. Copyright @ 2020 JFrog - All rights reserved. The Promotion Pyramid Development builds Dev Integration tests Integr. tests Staging Pre-Prod Prod Amount of builds Build/Deploytime Amount of binaries @jbaruch #ATO http://jfrog.com/shownotes
- 10. Pipeline: quality gates and visibility CI SERVER Integration System Testing If quality requirments are hit If quality requirments are hit If quality requirments are hit Staging - Quality gates - Production 1 2 3 4 * @jbaruch #ATO http://jfrog.com/shownotes
- 11. $docker build @jbaruch #ATO http://jfrog.com/shownotes
- 13. Let’s docker build in every env! @jbaruch #ATO http://jfrog.com/shownotes
- 15. That’s why. FROM ubuntu RUN apt-get install -y software-properties-common python RUN apt-get install -y nodejs RUN mkdir /var/www ADD app.js /var/www/app.js CMD ["/usr/bin/node", "/var/www/app.js"] Latest version Latest version Latest version Latest version @jbaruch #ATO http://jfrog.com/shownotes
- 16. That’s why. FROM ubuntu:19.04 RUN apt-get install -y software-properties-common python RUN apt-get install -y nodejs RUN mkdir /var/www ADD app.js /var/www/app.js CMD ["/usr/bin/node", "/var/www/app.js"] Better now? @jbaruch #ATO http://jfrog.com/shownotes
- 17. That’s why. FROM ubuntu:4033353383af19ec179c01dda7f355a246c6adcafaf93c8f98 RUN apt-get install -y software-properties-common python RUN apt-get install -y nodejs RUN mkdir /var/www ADD app.js /var/www/app.js CMD ["/usr/bin/node", "/var/www/app.js"] And now? @jbaruch #ATO http://jfrog.com/shownotes
- 18. That’s why. FROM ubuntu:4033353383af19ec179c01dda7f355a246c6adcafaf93c8f98 RUN apt-get install -y software-properties-common python RUN apt-get install -y nodejs RUN mkdir /var/www ADD app.js /var/www/app.js CMD ["/usr/bin/node", "/var/www/app.js"] What about those? @jbaruch #ATO http://jfrog.com/shownotes
- 19. That’s why. FROM ubuntu:4033353383af19ec179c01dda7f355a246c6adcafaf93c8f98 RUN mvn clean install CMD ”java –jar Main.class" What about this? @jbaruch #ATO http://jfrog.com/shownotes
- 20. That’s why. FROM ubuntu:4033353383af19ec179c01dda7f355a246c6adcafaf93c8f98 RUN download_random_sh*t_from_the_internet.sh CMD ["/usr/bin/node", "/var/www/app.js"] And how about this? @jbaruch #ATO http://jfrog.com/shownotes
- 21. That’s why you don’t trust Docker @jbaruch #ATO http://jfrog.com/shownotes
- 24. What’s up with the gates?! - QA shouldn’t test dev images - non-tested images shouldn't be staged - non-staged, non-tested or dev images shouldn’t end up in production!!! @jbaruch #ATO http://jfrog.com/shownotes
- 25. Let’s build Rock-solid pipeline!
- 26. How do I separate dev from prod?! @jbaruch #ATO http://jfrog.com/shownotes
- 27. Option 1: metadata tags @jbaruch #ATO http://jfrog.com/shownotes
- 29. Option 2: Docker Repositories
- 31. Separate registries per environment CI SERVER Integration System Testing If quality requirments are hit If quality requirments are hit If quality requirments are hit Staging - Quality gates - Production 1 2 3 4 * @jbaruch #ATO http://jfrog.com/shownotes
- 33. Trumped-up limitations @jbaruch #ATO http://jfrog.com/shownotes
- 34. The Anatomy of Docker Tag @jbaruch #ATO http://jfrog.com/shownotes
- 35. Wait a second, how can I have more than one registry per host now?! @jbaruch #ATO http://jfrog.com/shownotes
- 36. How can we support this? https://host:8081/registry/docker-dev/busybox https://host:8081/registry/docker-staging/busybox https://host:8081/registry/docker-qa/busybox https://host:8081/registry/docker-prod/busybox @jbaruch #ATO http://jfrog.com/shownotes
- 37. “ONE REGISTRY PER HOST OUGHT TO BE ENOUGH FOR ANYBODY.”
- 39. Virtual hosts/ports to the rescue Registry host Tag name docker tag host:port/busybox @jbaruch #ATO http://jfrog.com/shownotes
- 40. Virtual hosts/ports to the rescue https://host:port/v2/busybox Registry host Tag name docker tag host:port/busybox @jbaruch #ATO http://jfrog.com/shownotes
- 41. Virtual hosts/ports to the rescue https://host:port/v2/busybox Registry host Tag name docker tag host:port/busybox https://host:8081/registry/docker-dev/busybox Registry name Tag nameContext name
- 42. server { listen 5001; server_name 192.168.99.100; if ($http_x_forwarded_proto = '') { set $http_x_forwarded_proto $scheme; } rewrite ^/(v1|v2)/(.*) /artifactory/api/docker/docker-dev/$1/$2; … } } @jbaruch #ATO http://jfrog.com/shownotes
- 44. Let’s abuse things! @jbaruch #ATO http://jfrog.com/shownotes
- 45. Let’s abuse things! @jbaruch #ATO http://jfrog.com/shownotes
- 46. But then you realize… Wait a second, now I need to pull, retag and push for every step?! @jbaruch #ATO http://jfrog.com/shownotes
- 48. dev cluster prod cluster staging cluster test cluster @jbaruch #ATO http://jfrog.com/shownotes
- 49. Win-win-win - Single point of access to multiple registries when needed - Completely isolated environments - Immediate and free promotions
- 50. But what about the rest of the dependencies?
- 55. Own your dependencies - Your base image - Your infra - Your application files @jbaruch #ATO http://jfrog.com/shownotes
- 56. Isn’t it a shame? FROM ubuntu RUN apt-get install -y software-properties-common python RUN apt-get install -y nodejs RUN mkdir /var/www ADD app.js /var/www/app.js CMD ["/usr/bin/node", "/var/www/app.js"] Latest version – BAD! @jbaruch #ATO http://jfrog.com/shownotes
- 57. Static Tagging vs Dynamic tagging ØAssigned once, remains unchanged ØReproducible builds ØLatest good state image ØEasy to use ØBut what version is it?! @jbaruch #ATO http://jfrog.com/shownotes
- 58. Copyright @ 2020 JFrog - All rights reserved. Double Tagging FTW @jbaruch #ATO http://jfrog.com/shownotes
- 60. conclusions - Build only once - Separate environments - Promote what you’ve built - Own your dependencies @jbaruch #ATO http://jfrog.com/shownotes
