1. #backdaybyxebia
FABIAN GUTIERREZ
XAVIER BUCCHIOTTY
Construire le SI de demain
Akka, the reactive toolkit

2. #backdaybyxebia
Speakers
@FabGutierr @xbucchiotty

3. #backdaybyxebia
Agenda
● Concepts
● Reactive Application
● Actor Basics
● Actor Supervision
● Scale OUT
● Use case

4. #backdaybyxebia
Concepts

5. #backdaybyxebia
Concurrency
"Two or more tasks are making progress even though
they might not be executing simultaneously"
Parallelism
"The execution of multiple things is truly simultaneous"
Rob Pike - 'Concurrency Is Not Parallelism': https://vimeo.com/49718712

6. #backdaybyxebia
Synchronous
"A method call is considered synchronous if the caller
cannot make progress until the method returns a value
or exception"
Asynchronous
"Async call allows the caller to progress after a finite
number of steps and the completion may be signaled
via a callback, Future or message"

7. #backdaybyxebia
Blocking
"When the delay of one thread can indefinitely delay
some of the other threads"
Non blocking
"No thread is able to indefinitely delay others"

8. #backdaybyxebia
Reactive Application

9. #backdaybyxebia
RUsers = REvents + RLoad + RFailure
React to events, pushing rather than pulling
React to load, focus on scalability rather than single-user
performance
React to failure, resilient systems with the ability to recover
quickly at all levels

10. #backdaybyxebia

11. #backdaybyxebia
- Áhkká
All the wisdom and beauty of the world according to the
sami mythology
A mountain in Laponia in the north part of Sweden

12. #backdaybyxebia
Problem
It is very difficult to build:
● Correct highly concurrent
systems
● Truly scalable systems
● Self-healing, fault-
tolerant systems
Goal
Make simpler:
● Concurrency
● Scalability
● Fault-tolerance

13. #backdaybyxebia
Scale UP
is the same thing as
Scale OUT
-- Jonas Bonér

14. #backdaybyxebia
Actor Basics

15. #backdaybyxebia
A computational model that
embodies:
● Processing
● Storage
● Communication
Actor Model
Carl Hewitt

16. #backdaybyxebia
"The Actor model allows the developer to write concurrent
and distributed systems by abstracting the low-level
problems of having to deal with locking and thread
management"
Actor Model

17. #backdaybyxebia
● Lightweight objects
● Thread-safe
● Send and receive
messages
Actors

18. #backdaybyxebia
● Actors have a mailbox, all
messages received go
there
● When a message is
received they decide what
to do based on message
type and content
Actor Behaviour
● In addition to normal
operations, they can create
new actors or send
messages to other actors
● Messages can only be sent to
actors whose address is
known

19. #backdaybyxebia
Behaviour
State
Actor
Event-driven
Thread

20. #backdaybyxebia
Defining Actors
case object Tick
class MyCounterActor extends Actor{
var counter = 0
def receive = {
case Tick =>
counter += 1
println(counter)
}
}
val config = ConfigFactory.
load()
val system =
ActorSystem("system", config)
val counterRef = system.actorOf(
Props[MyCounterActor],
"MyActor")

21. #backdaybyxebia
Sending Messages to Actors
counterRef ! Tick
counterRef tell Tick
counterRef.tell(Tick)
counterRef.tell(Tick,
senderRef)
implicit val timeout =
Timeout(5 seconds)
val future = actor ? message
//or
val future = ask (actorRef,
Tick, 5 seconds)

22. #backdaybyxebia
Become / Unbecome
class HotSwapActor extends Actor with Stash {
import context._
def angry: Receive = {
case "foo" => sender() ! "I am already angry?"
case "bar" => become(happy)
}
def happy: Receive = {
case "bar" => sender() ! "I am already happy :-)"
case "foo" => become(angry)
}
def receive = {
case "foo" => become(angry)
case "bar" => become(happy)
}
}
The Stash trait
enables an actor to
temporarily stash
away messages that
can not or should not
be handled using the
actor's current
behavior

23. #backdaybyxebia
Actor Paths and Addresses

24. #backdaybyxebia
Actor Selection
val actorRef =
system.actorFor( "/MyActor/A")
val parent =
system.actorFor( "..")
val sibling =
system.actorFor( "../B")
val refPath: ActorPath =
actorRef.path
val selection =
system.actorSelection( "/MyActor/*")
selection ! "hello there"

25. #backdaybyxebia
Actor Supervision

26. #backdaybyxebia
Supervision = Parenting

27. #backdaybyxebia
The guardians

28. #backdaybyxebia
The Guardians = Top level Supervisors
/user, the
guardian actor
Parent of all user-created
actors
/system, the system
guardian
Allows an ordered shut-down
sequence
/, the root guardian
Supervises all top level and special actors
/user /system
/ You don’t interact with
this other root actors
as a user
Root Actor

29. #backdaybyxebia
● When?
the actor is in corrupt
internal state
Restarting
● How is it done?
By creating a new
instance of the actor
and keeping the
previous mailbox

30. #backdaybyxebia
Lifecycle monitoring or DeathWatch
● An actor can monitor any other actor in order to
react to his termination
● It means that supervision reacts to failure
● Each actor is the supervisor of its children, and as
such each actor defines fault handling strategy

31. #backdaybyxebia
Fault Tolerance(...or let it crash)
When an actor fails…
the supervisor will
know what to do!!

32. #backdaybyxebia
Default Supervision (in parent actors)
final val defaultStrategy: SupervisorStrategy = {
def defaultDecider: Decider = {
case _: ActorInitializationException => Stop
case _: ActorKilledException => Stop
case _: Exception => Restart
}
OneForOneStrategy()(defaultDecider)
}
You don’t have to
specify your own
supervisor strategy in
each and every actor.
However, the default
strategy looks like
this:

33. #backdaybyxebia
Defining a supervisor strategy
class MyActorSupervisor extends Actor {
override val supervisorStrategy =
OneForOneStrategy (
maxNrOfRetries = 10,
withinTimeRange = 1 minute) {
case _: ArithmeticException => Resume
case _: NullPointerException => Restart
case _: IllegalArgumentException => Stop
case _: Exception => Escalate
}
}

34. #backdaybyxebia
No idea what to do?
Ask your supervisor!!
override val supervisorStrategy =
OneForOneStrategy (
maxNrOfRetries = 10,
withinTimeRange = 1 minute) {
case _: ArithmeticException => Resume
case t => super.supervisorStrategy.decider
.applyOrElse(t,(_: Any) => Escalate)
}
One-For-One All-For-One
OneForOneStrategy AllForOneStrategy
Default strategy Recommended when there are tight
dependencies among children
Applies directives only to the failed child Applies directives to the failed child and
siblings

35. #backdaybyxebia
Manage Failure From Within
class FaultTolerantService extends Actor {
override def preRestart(
reason: Throwable, message: Option[Any]) = {
// clean up before restart
}
override def postRestart(reason: Throwable) = {
// init after restart
}
...
}
Lifecycle hooks:
● preStart
● postStop
● preRestart
● postRestart

36. #backdaybyxebia
Scale UP

37. #backdaybyxebia
Routing
Redirects messages
● RoundRobin
● Random
● SmallestMailbox
● Broadcast
● custom
val routerRef = system.actorOf
(Props[Counter].withRouter(
RoundRobinRouting(
nrOfInstances = 5)
))
akka.actor.deployment {
/parent/router1 {
router = round-robin-
pool
nr-of-instances = 5
}
}

38. #backdaybyxebia
Scale OUT

39. #backdaybyxebia

40. #backdaybyxebia
Remote communication
If no deployment configuration exist then the
actor is deployed as local...it implies:
● Write as local
● Deploy as distributed in the cloud
● No code change

41. #backdaybyxebia
Akka Remote
Communication between systems is symmetric
if a system A can connect to a system B then system
B must also be able to connect to system A
independently
The role of the communicating systems are
symmetric in regards to connection patterns
There is no system that only accepts connections,
and there is no system that only initiates connections

42. #backdaybyxebia
akka {
actor {
provider = "akka.remote.RemoteActorRefProvider"
}
remote {
enabled-transports = [ "akka.remote.netty.tcp"]
netty.tcp {
hostname = "127.0.0.1"
port = 2552
}
}
}
val selection =
context.actorSelection(
"akka.tcp://actorSystemName@10.0.0.1:2552/user/MyActor")
selection ! "Pretty awesome feature"

43. #backdaybyxebia
Akka Clustering
● Fault-tolerant
● Decentralized
● Peer-to-Peer
Cluster membership service
no single point of failure or
single point of bottleneck

44. #backdaybyxebia
Akka Clustering
/producer/router {
router = round-robin
nr-of-instances = 100
cluster {
enabled = on
routees-path = "/user/routee"
allow-local-routees = on
}
}

45. #backdaybyxebia
Failure Detection
● Hashes the node ring
● Picks 5 nodes
● Request/Reply
heartbeat
Network Partition
● Failure detector can mark an
unavailable member unreachable
● If one node is unreachable then
no cluster convergence
● This means that the leader
cannot perform its duties
● A member can become
reachable again

46. #backdaybyxebia
Testing Actors
akka-testkit because JUnit is not enough

47. #backdaybyxebia
Big Questions!
● Testing async calls without
using threads explicitly
● You are not Brian Goetz and you
want to use ThreadLocals
● CountDownLatch is not enough

48. #backdaybyxebia
Enter Specs
class MyEchoSpec(_system: ActorSystem) extends TestKit(_system) with
ImplicitSender with WordSpecLike with Matchers with BeforeAndAfterAll {
def this() = this(ActorSystem("MySpec"))
override def afterAll {
TestKit. shutdownActorSystem (system)
}
"An Echo actor" must {
"send back messages unchanged" in {
val echo = system.actorOf(TestActors.echoActorProps)
echo ! "hello world"
expectMsg("hello world")
}
}
}

49. #backdaybyxebia
Built-In Assertions
expectMsg[T](d: Duration, msg: T): T
expectNoMsg(d: Duration)
expectMsgClass[T](d: Duration, c: Class[T]): T
expectMsgType[T: Manifest](d: Duration)
expectMsgAnyOf[T](d: Duration, obj: T*): T
expectMsgAnyClassOf[T](d: Duration, obj: Class[_ <: T]*): T
expectMsgAllOf[T](d: Duration, obj: T*): Seq[T]
receiveN(n: Int, d: Duration): Seq[AnyRef]

50. #backdaybyxebia
Multi-JVM
"form a cluster" in {
runOn(ClusterNodes: _*) {
SeedDiscovery.joinCluster(system)
enterBarrier( "deployed")
}
}
"support network partition" in {
runOn(node1) {
for {
from <- group_1
to <- group_2
} {
testConductor. blackhole(from, to, Direction.Both).await
}
}
}

51. #backdaybyxebia

52. #backdaybyxebia
Use case

53. #backdaybyxebia

54. #backdaybyxebia
TCP
Server
DB
Actors are similar to objects.

55. #backdaybyxebia
Actors process one message at a time.
is injected in
usesTCP
Server
DB

56. #backdaybyxebia
TCP
Server
DB
session
2
session
1
create create
is injected in
uses
Actors can create other actors and supervise them.

57. #backdaybyxebia
TCP
Server
DB
session
2
session
1
create create
is injected in
uses
Actors process one message at a time.

58. #backdaybyxebia
TCP
Server
DB
router
session
2
session
1
create
is injected in
Actors can be behind routers to scale UP.
conn
1
conn
2
create
uses

59. #backdaybyxebia
TCP
Server
DB
router
session
2
session
1
create
is injected in
conn
1
conn
2
create
uses
Actors can create other actors and supervise them.

60. #backdaybyxebia
TCP
Server
DB
router
session
2
session
1
create
is injected in
conn
1
conn
2
create
uses
Actors can communicate with other actors.
Alerting
is injected in

61. #backdaybyxebia
TCP
Server
DB
router
session
2
session
1
create
is injected in
conn
1
conn
2
create
uses
Actors can be deployed remotely to scale OUT.
Alerting
is injected in

62. #backdaybyxebia
Alerting
TCP
Server
DB
router
session
2
session
1
create
is injected in
conn
1
conn
2
create
uses
Actors can be deployed remotely to scale OUT.
Alerting
are injected in

63. #backdaybyxebia
Questions?
