3. ww.aditi.com
Azure Document DB?
• NoSQL document database service designed for modern mobile and web applications
• Provides fast read and write
• Easily scale up and down on demand
• JavaScript integration
• Schema less database
• Enables complex ad hoc queries using SQL language
• Multi-Document transaction processing using Stored Procedure, triggers & UDFs
• Natively supports JSON documents
3
6. ww.aditi.com
Resource Description
Database account A database account is associated with a set of databases and a fixed amount of blob storage for attachments (preview feature). You can
create one or more database accounts using your Azure subscription. Every Standard database account is allocated a minimum capacity of
one S1 collection. For more information, visit our pricing page.
Database A database is a logical container of document storage partitioned across collections. It is also a users container.
User The logical namespace for scoping/partitioning permissions.
Permission An authorization token associated with a user for authorized access to a specific resource.
Collection A collection is a container of JSON documents and the associated JavaScript application logic. A collection is a billable entity, where the
cost is determined by the performance level associated with the collection. The performance levels (S1, S2 and S3) provide 10GB of
storage and a fixed amount of throughput. For more information on performance levels, visit our performance page.
Stored Procedure Application logic written in JavaScript which is registered with a collection and transactionally executed within the database engine.
Trigger Application logic written in JavaScript modeling side effects associated with insert, replace or delete operations.
UDF A side effect free, application logic written in JavaScript. UDFs enable you to model a custom query operator and thereby extend the core
DocumentDB query language.
Document User defined (arbitrary) JSON content. By default, no schema needs to be defined nor do secondary indices need to be provided for all the
documents added to a collection.
Attachment An attachment is a special document containing references and associated metadata for external blob/media. The developer can choose
to have the blob managed by DocumentDB or store it with an external blob service provider such as OneDrive, Dropbox, etc.
7. ww.aditi.com
Addressing a resource
Value of the _self Description
/dbs Feed of databases under a database account.
/dbs/{_rid-db} Database with the unique id property with the value {_rid-db}.
/dbs/{_rid-db}/colls/ Feed of collections under a database.
/dbs/{_rid-db}/colls/{_rid-coll} Collection with the unique id property with the value {_rid-coll}.
/dbs/{_rid-db}/users/ Feed of users under a database.
/dbs/{_rid-db}/users/{_rid-user} User with the unique id property with the value {_rid-user}.
/dbs/{_rid-db}/users/{_rid-user}/permissions Feed of permissions under a database.
/dbs/{_rid-db}/users/{_rid-user}/permissions/{_rid-permission} Permission with the unique id property with the value {_rid-permission}.
7
10. ww.aditi.com
Modeling Data in Document DB
• Embedding data
10
When to embed
In general, use embedded data models when:
• There are contains relationships between entities.
• There are one-to-few relationships between entities.
• There is embedded data that changes infrequently.
• There is embedded data won't grow without bound.
11. ww.aditi.com
• Referencing data
11
When to reference
In general, use normalized data models when:
• Representing one-to-many relationships.
• Representing many-to-many relationships.
• Related data changes frequently.
• Referenced data could be unbounded.
12. ww.aditi.com
• Hybrid data (Combination of embed & referencing)
12
Detail Info: https://azure.microsoft.com/en-in/documentation/articles/documentdb-modeling-data/
13. ww.aditi.com
Indexing
13
• Specified at the collection level
• Automatic indexing
– By default, all documents are automatically indexed, but you can choose to turn it off.
– When indexing is turned off, documents can be accessed only through their self-links or by queries using ID.
14. ww.aditi.com 14
• Indexing mode
– Consistent – By default indexes synchronously updated on insert, replace or delete
– Lazy – asynchronous index update (targeted at bulk ingestion)
15. ww.aditi.com 15
• Indexing Types
Hash – supports efficient equality and JOIN queries
Range – supports efficient equality queries, range queries (using >, <, >=, <=, !=), and Order By queries
Hash:
SELECT * FROM collection c WHERE c.prop = "value
SELECT tag FROM collection c JOIN tag IN c.props WHERE tag = 5
Range:
SELECT * FROM collection c WHERE c.prop = "value“
SELECT * FROM collection c WHERE c.prop > 5
SELECT * FROM collection c ORDER BY c.prop
Note: Range indexes are supported only for numeric values.
16. ww.aditi.com
Indexing logical View
16
Example:
JSON property: {"headquarters": "Belgium"}
Corresponds to the path: /"headquarters"/"Belgium".
JSON array: {"exports": [{"city": “Moscow"}, {"city": Athens"}]}
Correspond to the paths: /"exports"/0/"city"/"Moscow" and /"exports"/1/"city"/"Athens".
17. ww.aditi.com
Consistency levels
The choice of consistency level has performance implications for both write and read operations. It applies to all the collections in
the database (future there is a plan of overriding the consistency level per collection basics)
• Strong
– provides absolute guarantees on data consistency, but offers the lowest level of read and write performance.
• Bounded staleness
– provides more predictable behavior for read consistency while offering the lowest latency writes
• Session
– provides predictable read data consistency for a session while offering the lowest latency writes
• Eventual
– provides the weakest read consistency but offers the lowest latency for both reads and writes.
17
18. ww.aditi.com
Securing access
• Account administrator
– Full access to all of the resources (administrative and application) within a given DocumentDB account.
• Read-only administrator
– Read-only access to all of the resources (administrative and application within a given DocumentDB account.
• Database user:
– The DocumentDB user resource associated with a specific set of DocumentDB database resources (e.g. collections, documents,
scripts).
18
Administrative resources
• Account
• Database
• User
• Permission
Application resources
• Collection
• Document
• Attachment
• Stored procedure
• Trigger
• User-defined function
22. ww.aditi.com
UDF’s
22
Creates a UDF to calculate income tax based on rates for various income brackets, and then uses it inside a query to find all people who paid
more than $20,000 in taxes.
26. ww.aditi.com
Limits and quotas
26
ENTITY QUOTA (STANDARD OFFER)
Database Accounts* 5
Number of databases per database account 100
Number of users per database account – across all databases 500,000
Number of permissions per database account – across all databases 2,000,000
Attachment storage per database account (Preview Feature) 2 GB
Maximum Request Units / second per collection 2500
Number of stored procedures, triggers and UDFs per collection* 25 each
Maximum execution time for stored procedure and trigger 5 seconds
Provisioned document storage / collection 10 GB
Maximum collections per database account* 100
Maximum document storage per database (100 collections)* 1 TB
Maximum Length of the Id property 255 characters
Maximum items per page 1000
27. ww.aditi.com 27
ENTITY QUOTA (STANDARD OFFER)
Maximum request size of document and attachment 512KB
Maximum request size of stored procedure, trigger and UDF 512KB
Maximum response size 1MB
String All strings must conform to the UTF-8 encoding. Since UTF-8 is a variable width encoding, string
sizes are determined using the UTF-8 bytes.
Maximum length of property or value No practical limit
Maximum number of UDFs per query* 1
Maximum number of built-in functions per query No practical limit
Maximum number of JOINs per query* 2
Maximum number of AND clauses per query* 5
Maximum number of OR clauses per query* 5
Maximum number of values per IN expression* 100
Maximum number of collection creates per minute* 5
Maximum number of scale operations per minute* 5
