AsynchronousProgrammingDesignPatterns.pptx

Non-Juniper
Programming Language : C/C++ ( but concepts are language agnostic )
Pre-requisites : Thread Synch ( Mutex and Condition Variables ), Socket programming basics
Website : www.csepracticals.com

Non-Juniper
In this Course, we shall be going to understand Asynchronous Programming, and problem it solves through a Demo Project !
Pre-requites :
Multithreading, Thread Sync, Mutex, Condition Variables
C/C++ Or any main-stream programming language
Table of Contents :
1. Understanding sync and async programming paradigm
2. Understanding sync and async communication
3. Goals of Asynchronous Programming
4. Defining the project to practice Asynchronous Programming Concepts
5. Asynchronous Programming through Dispatch Queue/EventLoop
1. Design
2. Implementation
3. Implement Various Asynchronous Design Patterns
After doing this Course :
 Understand where to apply Async
Programming techniques and why
 Say good-byte to forced Multi-threading
 Say good-bye to forced locking
 Build scalable system soft-wares
 Implement Async Communication

Non-Juniper
Asynchronous Programming Design Patterns  Async Vs Sync Example
 Till now, most of the code you have written so far is sync code
 All codes that you write while practicing CP is sync code
 Sync programming means – performs steps in known definite order
Measure ingredients
Mix flour, eggs,
Sugar
Heat Oven to
the right temp
Bake the cake
Wait for cake to
ready
Prepare the cake
Synchronous
way
Measure ingredients
Mix flour, eggs,
Sugar
Heat Oven to
the right temp
Bake the cake
Send notif that
cake is ready
Prepare the cake
ASynchronous
way
Eat Eat
• Do independent tasks in parallel
• No waiting, do something else
• Asynchronous doesn’t means
multithreading, but closely tied
to it

Non-Juniper
Asynchronous Programming Design Patterns  Async Vs Sync communication
 Conversation through telephone – Synchronous communication
 You hear what other is saying
 You wait until the other side has completed his sentence
 When one speak, other one actively hear
 While you speak or hear, you don’t do anything else
 Conversation through email or chat – Asynchronous Communication
 You don’t wait for other’s response
 You shoot your email/msg without knowing if other one is in ready to recv/read state
 You don’t wait for the reply ( at-least instantly )
 You are notified by notification that reply has recvd
 Asynchronous communication means communication which happens ‘out of sync’
It is almost a bad software design if you need to get blocked for some reason ! However, blocking is justified in few scenarios
like select( ) / fgets( ) etc

Non-Juniper
Asynchronous Programming Design Patterns  Asynchronous Vs Multi-Threading Programming
 They tend to appear same , but they are not
 Multithreading is one form of asynchronous programming
 Asynchronous programming can be done with single thread as well as with multiple threads
 Multi-Threading is about Workers who works in parallel
 Asynchronous is all about set of tasks to be finished, for example an application may have :
 Task 1 : Network 10 pkts in Queue to be processed
 Task 2 : Timer Callback pending to execute
 Task 3 : A Network pkt to send to remote machine
 Task 4 : A CLI input from user to be processed
Asynchronous
Programming
Multithreading
Programming
Single Threaded
Programming
 How would application going to finish pending tasks ?
 In what order ?
 Parallel or sequentially ?
 While executing current task, more task may Queue in

Non-Juniper
T1 T2 T3 T4 T5 T6
Synchronous
Single Threaded
Thread 1
Task 1
Task 2
Task 3
Task 4
Task 5
Thread 1
Thread 2
Thread 3
Thread 4
Thread 5
Synchronous
Multi Threaded
ASynchronous
Single Threaded T1 T2 T1 T4 T2 T6
Thread 1
Thread 1
Thread 2
Thread 3
Thread 4
ASynchronous
Multi Threaded
T1 T2 T1 T4 T2 T6
S1 S2 S3 S1 S2 S5
U1 U2 U1 U4 U2 U6
V6 V2 V1 V6 V2 V6

Non-Juniper
ASynchronous
Single Threaded Sum[0,3] Mul[0,5] Sum[4,6] Mul[6,9] Sum[7,9] -
Thread 1
1 2 3 4 5 6 7 8 9 10
Task 1 - Calculate sum of all numbers
Task 2 – Calculate multiplication of all numbers
Sum[0,9] Mul[0,9]
Thread 1
Synchronous
Single Threaded
Sum[0,9]
Mul[0,9]
Thread 1
Synchronous
Multi Threaded
Thread 2
ASynchronous
Multi Threaded
Sum[0,3] Sum[4,6] Sum[7,9]
Thread 1
Mul[0,5] Mul[6,9]
Thread 2

Non-Juniper
Asynchronous Programming Design Patterns  Course Layout
 I have developed this Course on a Fast-Track
 I would try to enforce learning by doing rather than splitting out theeeeoooooorrryyyyyyy
 We will straightaway discuss one problem statement where asynchronous programming is essential
 Then we built asynchronous solution to the problem called – Event Loop Or Dispatch Queue
 We apply the event loop async solution to solve various other problems ( Design Patterns )
 I will use C to demonstrate the concepts, but concepts are language agnostic
 After doing this Course, you would be in a position to design asynchronous systems
 Pre-requisites :
 You must at-least know how to implement producer-consumer problem
 If not, then pls learn thready Synchronization basics before attempting this course
No More Theory,
Let’s Get our Hands
Dirty

Non-Juniper
A Data Structure to do Asynchronous Programming

Non-Juniper
Asynchronous Programming  Introducing Event Loops
 Event loop is an async programming structure which schedule the computation to be formed in future ( Work Deferral )
 Let us understand how event loop works – Design and Implementation
 Event loop is also called as Event dispatcher
 Once we finish the implementation of event loop, I will show you how to put event loop to implement different types
of Asynchronous programming model
 The output of this section is : Event Loop Library

Non-Juniper
F1, arg1 F2, arg2 F3, arg3 F4, arg4 F1, arg5
Appln
Thread(s)
task_create_new_job
(argx, Fnx);
 Event Loop is a separate independent thread acting on its task array
 Event Loop works like a machine, picking up Fn + Arg ( Computation )
from its task array and placing it on execution stack
 It serializes all computations, and discharge them one by one
 It continues to do so until the task array is empty
 It resumes again if some application thread(s) submits new Computation to task array
Task Array
Asynchronous Programming  Event Loop internal Functioning

Non-Juniper
Appln
Thread(s)
task_create_new_job
(arg, foo);
Task Array
foo ( arg ) {
. . .
printf(“this ”);
task_t *bar_task =
task_create_new_job(arg1, bar);
printf(“is my fav ”);
. . .
}
o/P : this is my fav
bar( ) {
printf (“bar”);
}
Asynchronous Programming  Event Loop internal Functioning
1
Foo, arg
2
3
5
bar, arg1
6
7
8
Appln submit new
C to EL
C is Queued in
Task Array as Task
EL is signaled
4 Fst task is removed
From task array
Task is
triggered
Ist Task is
Completed
Task Created
New Task
IInd task is removed
From task array
9
Task is
triggered
10
IInd Task is
Completed
bar
11
EL suspends again
C – Computation
EL – Event Loop Thread

Non-Juniper
Asynchronous Programming  Event Loop Design and Implementation
Event Loop
Thread in Suspended State
Application Submit
Computation to Event Loop
Thread
EL Thread is Signaled (
Resume Execution )
While Task Array is Empty
Dequeue Computation from
Task Array and Triggers it
N
EV_DIS_IDLE
EV_DIS_TASK_FIN_WAIT
Y

Non-Juniper
Asynchronous Programming Design Patterns  Code Access
 You can do this Course on any POSIX compliant Operating system – Linux Or MAC-OS
 I will execute and run all my codes on Linux
 Compiler used – gcc
 Programming language – C/C++ , if you are doing this course in other language, write equivalent code
 You are advised to use github for all your codes management
 30 min tutorial from youtube, that suffice
 My Setup : Visual studio Code IDE, Ubuntu 20.04 LTS, VMWare Work-Station Player
 Code Access : https://github.com/sachinites/AsyncProgramming
 Create your github account and Fork this repository

Non-Juniper
Asynchronous Programming  Event Loop Design and Implementation  Data Structures
Event Loop
Thread in Suspended State
Application Submit
Computation to Event Loop
Thread
EL Thread is Signaled (
Resume Execution )
While Task Array is Empty
Dequeue Computation from
Task Array and Triggers it
N
EV_DIS_IDLE
EV_DIS_TASK_FIN_WAIT
Computation = Fn + Arg
typedef void (*event_cbk)(void *);
struct task_{
event_cbk ev_cbk;
void *arg;
struct task_ *next;
struct task_ *prev;
} ;
struct event_loop_{
struct task_ *task_array_head;
pthread_mutex_t ev_loop_mutex;
EV_LOOP_STATE ev_loop_state;
pthread_cond_t ev_loop_cv;
pthread_t *thread;
task_t *current_task;
};
typedef enum {
EV_DIS_IDLE,
EV_DIS_TASK_FIN_WAIT,
} EV_DISPATCHER_STATE;
Y
event_loop.h

Non-Juniper
Asynchronous Programming  Event Loop Design and Implementation  APIs
void
event_loop_init(event_loop_t *el);
• Initialize the member of event loop
void
event_loop_run(event_loop_t *el);
• Run the event loop thread

Non-Juniper
 Write the following below helping APIs in file event_loop.c
static task_t *
event_loop_get_next_task_to_run (event_loop_t *el);
static void
event_loop_add_task_in_task_array (
event_loop_t *el,
task_t *new_task);
static bool
task_is_present_in_task_array (task_t *task);

Non-Juniper
static void *
event_loop_thread(void *arg) {
while(1) {
printf (“%s() runningn”, __FUNCTION__);
sleep(2);
}
return NULL;
}
event loop task
array
Application
Thread
Event Loop
Thread
 Therefore, EnQueue/Dequeue operation on EL task array are C.S , and must be protected by EL mutex
Algorithm :
1. Lock the EL mutex
2. Fetch the task from task array
3. If task not found, suspend
4. If task found, fire the task
5. Unlock the EL Mutex
Repeat above 4 steps for forever

Non-Juniper
task_t *
task_create_new_job (event_loop_t *el, event_cbk cbk, void *arg);
• Create a new task_t object, and initialise it
• Lock the EL Mutex
• Add a task to the EL’s task array
• If EL is in IDLE state, signal it
• If EL is already BUSY, We are done
• Unlock EL Mutex
void event_dispatcher_schedule_task (event_loop_t *el , task_t *task);
event loop task
array
Application
Thread
Event Loop
Thread
Task Submission to Event Loop Task Array

Non-Juniper
Asynchronous Programming  Event Loop  Demos
 demo_app_mul_sum.c
 demo_app_single_threaded_concurrency.c

Non-Juniper
Asynchronous Programming  Event Loop  Lock Free
 Application which uses Event Loops are lock free ( as long as Application logic is executed through Tasks only )
 First, we need to understand why we need locks in multi-threaded environment, at the most fundamental level

Non-Juniper
Why we need locking in Multi-Threaded Environment
 To put in one sentence, we need locking because threads do context switching at arbitrary points in a program
 We want that other threads ever sees the data structures in in-consistent state
 Hence, lock the DS !

Non-Juniper
Asynchronous Programming  Event Loop  Lock Free
 Application which uses Event Loops are lock free ( as long as Application logic is executed through Tasks only )
 And the reason is Obvious, if only event loop thread were to execute application code through tasks, then there is only
one and only one thread in the system – event loop thread
 So , no Locks because the system is uni-threaded.
 But in this uni-threaded system also, Tasks switches from T1 to T2 ( upload/download example ). So, does it mean, we would need
locks/synchronization since something similar to context switching is there – task switching ?
Ans :
 Because Tasks switching happens in controlled fashion, unlike threads which Context Switches in uncontrolled
manner ( at any arbitrary point ), we still don’t need any locks.
 When tasks terminate, it is programmer responsibility to not to leave application data structures in in-consistent state.
 Why would any programmer return from a task while he is in middle of deleting a node from a DLL ?
 The New task fired by event loop would always find application data structures in consistent state.

Non-Juniper
Asynchronous Programming  Event Loop  There is no Parallelism
 Concurrency , Parallelism ? Do you understand the difference ? ( Refer Appendix B )
 On multi-core systems, Independent threads can execute in parallel on multiple Cores
 Event loop is a single threaded system, there is only one thread – Event loop thread
 Tasks executes one after the other ( serially ), and not in parallel by event loop thread ( sum( ) / mul( ) example )
 If tasks schedule itself again and again, it appear tasks are executing concurrently ( again, upload/download example )
 Event Loop provides concurrency but no parallelism even on multi-processor systems

Non-Juniper
Asynchronous Programming  Event Loop  What applications must use Event Loops
 Applications which should be designed single threaded
 No parallelism
 Lots of overlapping work
 Too much contention if designed multithreaded
 Have listener threads listening for I/O events
 Need to defer work ( later )
 Running on a single Core environment ( Embedded devices )
 Communication across different independent components of the single software process

Non-Juniper
A Data Structure to do Asynchronous Programming
Thank you !

Non-Juniper
Asynchronous Programming Design Pattern 1

Non-Juniper
Asynchronous Programming Design Patterns  Serializing Multi-threaded Flows
 We have a multi-threaded program
 We want to reduce multi-threaded program to a logical single threaded program
 But, If we wanted a single threaded program, why did you write a multithreaded programming in the first place ?
 And, now what is the need to reduce a multi-threaded program to single threaded ?
 And Why am I even Studying this, simply refactor your application code such that you don’t launch multiple threads,
problem solved !
 And Is it even possible ?
T1 T2 T3 T
Multi-threaded program Single-threaded program

Non-Juniper
Overlapping & Non-Overlapping Work
If Thread T1 is doing work W1 and Thread T2 doing work W2 , then W1 and W2 is said to be overlapping
if W1 and W2 operates on same Data
Eg : W1 - sorting the array A in Ascending order
W2 - sorting the array A in Descending order
Since Array is a common data on which Thread T1 and T2 are operating, therefore, W1 and W2 are
overlapping work
• If Threads access the same Data structures of a process , say, some global variable then work done by two
threads are overlapping work
Application
Overlapping work
Tend to be Single Threaded
Non-Overlapping work
Tend to be Multi Threaded

Non-Juniper
Overlapping & Non-Overlapping Application Example
Single Threaded Application Design Example
 Networking protocols
 Modification of one DS trigger Modification of other DS
 Modification often Trigger computation
 OSI Layer Implementation
 Processing is done sequentially ( from top to bottom
Or bottom to top )

Non-Juniper
Asynchronous Programming Design Patterns  Is Multi-Threaded Always Superior ?
Application
A
Single Threaded Multi Threaded
 Is Multi-Threaded Always Superior to Single Threaded ?
 Does Multi-Threaded appln always perform better as compared to Single Threaded ?
More the degree of isolated Data Structures and independent responsibilities, more the application tend to be multi-threaded
> So that threads can be assigned independent duties
> Threads operate on isolated data, not interfering with one another ( wait n signaling )
• Cars (threads) tend to move slow
• Road (shared resource ) is congested
• Cars move only when other
nearby cars create room
• You will cover 5km in 1 hr
• Ahh ! Resource exclusive for you !
• No Competitor to access same resource
• Move faster
• You will cover 5km in 10 min

Non-Juniper
Multithreaded and Single Threaded Applications
 Abhi wants to design a new application; he is confused whether he should design an application as Single threaded or
multithreaded
 Choosing the wrong thread model shall be devastating
Application
 Too big in size
 Wrong thread sync, deadlocks
 Overlapping Data Structures
 Too much locking & unlocking
 Not clear demarcation of logic/processing
 No Scope of parallelism
 Sequential tasks
Single
threaded 
 Moderate size
• Proper thread sync , manageable
 Isolated Data Structures
• Independent threads can perform CRUDs
 clear demarcation of logic/processing
• Every thread tied to its specific responsibility
 Parallel tasks
Multi
threaded 

Non-Juniper
Asynchronous Programming Design Patterns  Listener Threads
 We need to understand how threads can be used by the application to listen for external events
 Refer to Appendix C. Complete this section before jumping to next video.

Non-Juniper
 It is a common scenario that an application needs to constantly listen to external events
 Those external events can arrive anytime, and application needs to process those events
 Application May Use Thread(s) to listen on those external events
 Process STP has an overlapping property, meaning, it is a single threaded application by its design
Process STP
foo( )
bar( )
pkt_process( )
ipc_process( )
cli_handler( )
kernel_events( )
timer_event( )
Network
Pkt listener
thread
User input
listener
thread
User
Kernel events
listener
thread
Kernel
Process
communication
thread
Process P1
Using listener threads , process can
listen to all events at the same time,
When event arrive, process them !
Problems here : 
• Process STP tends to move towards multi-threaded
design, against its base design and arch
• Forced locking
• Contention
timer
thread
Asynchronous Programming Design Patterns  Listener Threads

Non-Juniper
Process STP
foo( )
bar( )
pkt_process( )
ipc_process( )
cli_handler( )
kernel_events( )
timer_events( )
Network
Pkt listener
thread
User input
listener
thread
User
Kernel events
listener
thread
Kernel
Process
communication
thread
Process P1
All listener threads + Timer thread Queue up
their computation to Event loop’s task array
Event loop then runs, and fires all Queued
Computations serially
End Result : Application logic executes only in
Context of EL thread
Result :
• Listener threads exist, but concurrency do not
• Process STP runs in the context of one thread only – Event
Loop thread ( Single threaded Design maintained )
• No locking, no Contention 
Task Array
timer
thread
Asynchronous Programming Design Patterns  Listener Threads Serializing Computation using Event Loop

Non-Juniper
Asynchronous Programming Design Patterns  Getting Started with Sample Project
Assignment : https://github.com/sachinites/asyncprogramming/
dir : AsyncProject
Soln dir : AsyncProjectSoln
stp.c
pkt_process( )
Network
Pkt listener
thread
Pkt listener
thread
User input
listener
thread ( main
thread ) User
rt_table
Routing Table Files :
rt.c
rt.h
 Routing table represents the data structures possessed by STP process
 Routing Table can be concurrently updated by :
 User in the context of main thread
 By Network in the context of Pkt listener thread
 STP is suppose to be single threaded, but it violates the assumption
 STP is thread unsafe, error prone
uses
Dest/Mask Gateway OIF
122.1.1.1/32 10.1.1.1 Eth0
130.1.2.3/32 10.1.2.1 eth1
Sample routing table
*CUD – Create Update Delete

Non-Juniper
Asynchronous Programming Design Patterns  Event Loop Integration
stp.c
pkt_process( )
cli_handler( )
Network
Pkt listener
thread
Pkt listener
thread
User input
listener
thread ( main
thread ) User
rt_table
Task Array
 Event loop must be the only execution unit which executes STP’s instructions
 Listener/UI threads submit their computation to Event Loop instead of executing appln logic directly
 Consequently, event Loop triggers all computations on behalf of listener threads
 Thus, STP is reduced to logically single threaded process
 Listener threads have just one purpose – to listen for events in blocking state, and not to provide
concurrency ( reason for thread invention )
 Next : Integrating Timers – Another tool to do Async Programming
stp_update_routing_table( )
Solution Design

Non-Juniper
stp.c
pkt_process( )
cli_handler( )
Network
Pkt listener
thread
Pkt listener
thread
User input
listener
thread ( main
thread ) User
rt_table
Task Array
 Goal : stp_update_routing_table ( ) must be invoked by event Loop thread instead by listener threads, Obviously all STP’s listener
threads must handover their respective computation to event loop thread
 STP process must have Event Loop object and initialize it using stp_init_el( )
 Create new data Structure el_rt_table_update_data_t to wrap up all arguments in one single object
 Write a new API which create a new task and submit the task to Event Loop task array
task_t *el_stp_update_routing_table(rt_table_t *rt_table, int cmd_code, rt_table_entry_t *rt_entry ) ;
 Changes in application code stp.c to reroute the computation from direct to via Event Loop :
Instead of calling stp_update_routing_table, call new API el_stp_update_routing_table
Asynchronous Programming Design Patterns  Event Loop Integration Steps
This is a common pattern
Regarding how an appln
Submits computation/data
to a general library
el_stp_update_routing_table( )
stp_update_routing_table( )

Non-Juniper

Non-Juniper
Asynchronous Programming Design Patterns  Timers
 Timers are one of the important elements of programming which contribute to Async programming
 Timer allows us to do Timer driven programming
 Schedule computation to be performed in future, one shot or periodically
 In this section , Let us first learn Posix timer APIs, and how to launch a new timer
 Then we will analyse the unwanted concurrency problem introduced by Timers in STP project
 We shall integrate Timers With Event Loop Library so that our STP process stays logically single threaded program
 Appendix D to learn Posix timers
 From next Video, I assume you already know how to create/delete Posix timers
 If you already have any other timer library which you have been using on Linux platform, feel free to use it and skip Appendix D

Non-Juniper
Asynchronous Programming Design Patterns  Timers  STP Project
 Homework :
• Routing table entries which are learned by Network should have expiration time of 30 sec
• Entries which are created by User should not have any expiration time
• First Timers to work with ‘Timers’ –
• Opportunity to learn working with timers
• Conceptually same concept irrespective of timer library

Non-Juniper
Asynchronous Programming Design Patterns  Timers  Implement Timer Expiration
rt.h changes :
#define RT_ENTRY_EXP_TIMER 30
Define new members in below structures :
struct rt_table_entry_ {
…
Timer_t *exp_timer;
int exp_timer_msec;
} ;
int /*0 on success, -1 on failure*/
rt_insert_new_entry(rt_table_t *rt,
char *dest, char mask,
char *gw, char *oif,
int exp_timer_in_millisec); << new arg, if 0 do not start the timer, else start the timer

Non-Juniper
Process STP
foo( )
bar( )
pkt_process( )
ipc_process( )
cli_handler( )
kernel_events( )
timer_event( )
Network
Pkt listener
thread
User input
listener
thread
User
Kernel events
listener
thread
Kernel
Process
communication
thread
Process P1
Timers Have Introduced
• Unwanted Concurrency
• Rt table entry is deleted by its timer thread
• User might be updating rt table through CLI
• While at the same time , pkt listener thread might be
Updating routing table
timer
thread
Asynchronous Programming Design Patterns  Timers  STP Project  Unwanted Concurrency
Solution :
• Handover Timer Events to Event Loop thread !
• Let Event Loop Thread delete the RT Table Entry
• Again – All external threads work is serialized by
Event Loop thread
• External Threads – Main thread , Pkt Listener
thread, Timer threads for each RT entry

Non-Juniper
Asynchronous Programming  Event Loops  Summary
 Event loop is an async programming structure which schedule the computation to be formed in future ( Work Deferral )
 Event loop Dequeues the Computation out of Queue and Triggers them ( place it on execution stack )
 Event loop is a powerful programming structure which helps avoid forced multithreading/locking
 Event loop helps in realizing concurrency in a single threaded programs ( Next Section )
 Event loop works like a in-charge Or prime authority of the application code, no other thread is allowed to execute
Application code but the event loop only
 Other threads of the application ( Timers, Socket Threads , UI Threads ) need to place the request for computation to
Event loop
 It is Event loop thread which then triggers the computation request submitted by several other threads
 Event loop is also called as Event dispatcher

Non-Juniper

Non-Juniper
Asynchronous Programming Design Patterns  Preemption
 We have already discussed an example of Preempting the ongoing current task and scheduling it again In a event loop
 Preemption is required so that same job do not occupy the entire CPU for a very long time.
 Multiple EL jobs/Taks should get fair chance to get enough CPUs so that “Progression” is observed
 Same is used by OS’s scheduler when it schedules processes using context-switching
 So, now we will going to observer two levels of Scheduling :
 Level1 : OS scheduling the processes, including our stp.c
 Level2 : stp.c scheduling EL tasks ( EL tasks are invisible to underlying OS )
 Lets do it formally now

Non-Juniper
Asynchronous Programming Design Patterns  Preemption  Context Save
 For the task to get preempted and rescheduled again, the task must resume from the same state where it had
left
 Application must save the task state before preempting it, and restore it when task is scheduled again
 This is similar to Context Switching done by OS in the context of thread switching
 Analogy : Book Reading ….
 Here task state means – Remembering how much work has been completed by the task
 Let us reinvent the “printing routing table” function – but lets implement it using preemption
 In every Preemption & Reschedule, lets print 10 entries incrementally from Routing table

Non-Juniper
Asynchronous Programming Design Patterns  Assignment
 Before we proceed further, let do one assignment
 Introduce a new option in STP main menu :
 6. Serialize and send Rt Entry
 7. Exit
 New Option 6 must do the following :
 Ask from user the Route Credentials : Destination & Mask = 32
 Ask Destination Port Number 50000
 Create a new task :
 Task must search RT entry in RT table, if found send it across network using UDP to 127.0.0.1:50000
 To encode RT entry in a msg to be sent, use the same msg layout as used in udp_client.c with code ROUTE_CREATE
 Run an instance of stp.exe in another terminal window, and start a pkt listener thread listening on port number 50000
 Now, Run another instance of stp.exe and choose option 2 to create a new rt entry followed by option 6
 Link to the soln is shared with the video.

Non-Juniper

Non-Juniper
Asynchronous Programming Design Patterns  Task Prioritization
 Tasks may have priority associated with them which represents how important the task is !
 Important task must be given CPU earlier and more CPU time as compared to other non-important tasks
 Some tasks can tolerate delay in getting CPU time, hence, must be of least priority
 Event Loop thread must choose Task with higher priority over task with Lower priority to schedule them on CPU
 Task with priority Pj must be chosen by EL thread for execution only and only when there are no task scheduled with priority P such that P > Pj
 Event Loop Thread must maintain a EL queue one for each priority level
 EL thread must finish all task scheduled with higher priority first
 Enhance the below API to include priority of the task as new parameter
task_t *
task_create_new_job(event_loop_t *el, event_cbk cbk, void *arg, TASK_PRIORITY_T task_priority);
TASK_PRIORITY Value Task Example
TASK_PRIORITY_HIGH 0 Packet Processing, Show commands,
Pkt sending
TASK_PRIORITY_MEDIUM 1 Config Commands, Algorithmic Computation
TASK_PRIOTITY_LOW
2 Object Deletion, Garbage Collection

Non-Juniper
Asynchronous Programming Design Patterns  Task Prioritization
 Tasks may have priority associated with them which represents how important the task is !
 Important task must be given CPU earlier and more CPU time as compared to other non-important tasks
 Some tasks can tolerate delay in getting CPU time, hence, must be of least priority
 Event Loop thread must choose Task with higher priority over task with Lower priority to schedule them on CPU
 Task with priority Pj must be chosen by EL thread for execution only and only when there are no task scheduled with priority P such that P > Pj
 Event Loop Thread must maintain a EL queue one for each priority level
 EL thread must finish all task scheduled with higher priority first
TASK_PRIORITY Value Task Example
TASK_PRIORITY_HIGH 0 Packet Processing, Show commands,
Pkt sending
TASK_PRIORITY_MEDIUM 1 Config Commands, Algorithmic Computation
TASK_PRIOTITY_LOW
2 Object Deletion, Garbage Collection

Non-Juniper
Asynchronous Programming Design Patterns  Task Prioritization  Code Changes
 Enhance the below API to include priority of the task as new parameter
task_t *
task_create_new_job(event_loop_t *el, event_cbk cbk, void *arg,
TASK_PRIORITY_T task_priority);
 Enhance the below API such that, task with higher priority is returned first
static task_t *
event_loop_get_next_task_to_run(event_loop_t *el);

Non-Juniper
Asynchronous Programming Design Patterns  Task Prioritization  Problems Addressed
1. Making show command highest priority task, User response time is enhanced
2. Making packet processing as highest priority task helps to process incoming network packets in a time bound
manner
3. Making delete-tasks as lowest priority task, Premature Deletion of objects is addressed

Non-Juniper
1. Making show command highest priority task, User response time is enhanced
Let there be Algorithm A, which executes with MEDIUM priority and with preemption. Let A takes total of 5 sec
to finish execution, preempts after every 1 sec
A1 A2 A3 show A4 A5
lag
show_task 
A_task
show_task – Medium, Algorithm A priority - HIGH
A1 A2 A3 A4 A5 show
lag
User trigger
Show command
show_task
EL_Q
EL_Q
User trigger
Show command
show_task
EL_Q
A_task 
show_task
EL_Q

Non-Juniper
2. Making packet processing as highest priority task helps to process incoming network packets in a time bound manner
Client Server
HTTP Req 
Server uses Event Loop scheduling such that :
Algorithm A is HIGH Priority and HTTP Req Pkt processing task is Medium Priority
A1 A2 A3 A4 A5 http_pkt_processing
_task
lag
HTTP_
processing_task
 HTTP Res
Client will experience delayed response from server
Soln : Make HTTP pkt processing task a high priority
And Algorithm A lower priority
HTTP Req pkt
arrives
HTTP_processing_task
A_task 
EL_Q EL_Q

Non-Juniper
3. Making delete-tasks as lowest priority task, Premature Deletion of objects is addressed
Discussed in next section

Non-Juniper

Non-Juniper
Asynchronous Programming Design Patterns  Handling Premature Deletion
 Premature Deletion means, deleting a Data Object from the system when there are Tasks scheduled to be operating on the object
 The problem of premature deletion is inherent to any environment which is concurrent
 Be it, single threaded concurrent environment which is in-charge of event-loop Or
 multi threaded concurrent environment achieved via multi-threading

Non-Juniper
Asynchronous Programming Design Patterns  Understanding Premature Deletion
Following event happens in STP process exactly in same sequence :
1. A new RT table entry is malloc’d, PTR is pointer to it
2. This RT table entry is inserted into RT table
3. An Expiry timer is triggered for this rt entry
4. A task TS is scheduled on this rt entry which serialize it and send over network to remote machine
5. Expiry timer Fires :
1. Detach rt entry from RT table
2. Free this RT table entry – free(PTR)
6. TS is triggered, it perform its operation on this PTR
7. STP crashes because pointer to rt_table entry PTR is a dangling pointer 
T1 T2 T3
D D D
free(D)
Dangling ptr Dangling ptr
 Premature Deletion means, deleting a Data Object from the system when there are Tasks scheduled to be operating on the object

Non-Juniper
Asynchronous Programming Design Patterns  Handling Premature Deletion  Solution
 Solution :
 Problem to Premature deletion is resolved when :
 Deletion (free) of Data object D is postponed until all Task scheduled to operate on it has also finished their respective operation on it
 Let their be Three Tasks T1 , T2 and T3 , Where T3 task is a delete task.
 Event-loop thread must schedule Task T3 only when Task T1 and T2 have finished their respective operation on D
 This would ensure no other task in the system ever sees D through Dangling Pointer
 Hence, Simple Solution is :
 Always delete objects through Separate Tasks, and not directly
 Delete Task must be of least Priority Pd
 Any Non-Delete Task Must have priority P > Pd
T1 T2 T3
D D D
free(D)

Non-Juniper
Asynchronous Programming Design Patterns  Handling Premature Deletion  Solution in STP
 Changes in STP process :
 Delete Single Rt Table Entry option # 4
• Create a new Taks with Priority LOW
• In Task CBK fn :
• Detach incoming pointers to rt_entry
• Detach rt_entry from container Data Structures
• Release rt_entry resources
• free rt_entry
• Return EL_FINISH
 Introduce a new Option # 7
 Delete rt table : void stp_el_delete_rt_table ( rt_table_t *rt_table)
• Create a new Taks with Priority LOW
• In Task CBK fn :
• Detach incoming pointers to rt_table
• Detach rt_table from container Data Structures ( Imp )
• Release rt_table resources
• Preempt after deletion of 10 entries, Return EL_CONTINUE
• Return EL_FINISH if all entries are deleted

Non-Juniper

Non-Juniper
Asynchronous Programming Design Patterns  Avoid Redundant work
Real Life Examples :
> Your mother ask you to mob the floor 5 times in a day, you mob it 5 times
You end up cleaning the same floor unnecessarily 4 times
> Your mother ask you to mob the floor 5 times in a day, but you obey only the last order and mob the floor on last call
Intelligent !!
Why to do same work multiple times, when the work produces the same result (Or result of doing it again overwrite
the result of previous work) no matter how many times you do it. Its better to do it only on last call

Non-Juniper
foo (){
. . .
. . .
if (C1) algo1();
. . .
. . .
if (C2) algo1();
. . .
. . .
}
Second invocation of algo1()
makes the prev invocation of algo1()
redundant
foo (){
bool call_algo1 = FALSE;
. . .
. . .
if (C1) call_algo1 = TRUE;
. . .
. . .
if (C2) call_algo1 = TRUE;
. . .
. . .
if (call_algo1) algo1();
}
Better
Approach
Call algo1 only once !
But requires tracking using local bool variable
Will not work if foo() is deeply nested fn and
Call to algo1 is decided in deep nested functions
also
Best Approach
foo ( ) {
. . .
if (C1) {
if (!algo_task) {
algo_task = task_create_new_job(el, algo1, arg)
}
}
. . .
if (C2) {
if (!algo_task) {
algo_task = task_create_new_job(el, algo1, arg)
}
}
}
Asynchronous Program
Call algo1 only once !
Requires tracking using global algo_task variable
Will work in nested fn call cases !
Asynchronous Programming Design Patterns  Avoid Redundant work

AsynchronousProgrammingDesignPatterns.pptx

Recommended

Recommended

More Related Content

Similar to AsynchronousProgrammingDesignPatterns.pptx

Similar to AsynchronousProgrammingDesignPatterns.pptx (20)

Recently uploaded

Recently uploaded (20)

AsynchronousProgrammingDesignPatterns.pptx
