3. l 前回までの復習
l Blazor 概要
l 今回作成する Web アプリケーションの概要
l Blazor WebAssembly プロジェクト作成
l Web API コントローラー追加、モデル追加
l Entity Framework による Code First データベース作成
l 商品サービス、商品リスト、カテゴリーサービス等必要なサービス、
CRUD 処理等の実装
l 検索サービスの追加と検索コンポーネントの実装
l UI/UX の変更、カートサービス
l 認証・ユーザー登録、その他の機能の実装
アジェンダ
4. 今回の範囲
l セッションでご紹介した EC アプリ .NET 5版ですが、参考にさせて戴きました。
l https://github.com/patrickgod/BlazorEcommercePreviewYT
l 2⽉、3⽉、の復習
l 4⽉は、検索機能、ページネーション、カートサービス、UI/UX 変更等
l 認証・認可まではカバーできず別の機会にフォローできれば…
8. Blazor – .NET 5 まで
Blazor Server Blazor WebAssembly
DOM
Blazor
WebAssembly
.NET
Razor Components
Blazor
.NET
Razor Components
DOM
SignalR
ü DB アクセス含むサーバー機能へのフルアクセス
ü ⾼速なスタートアップ
ü コードがサーバーから離れない
ü 古いブラウザとシンクライアントをサポート
ü 永続的な接続が必要
ü UI の遅延が⾼い
ü完全にクライアント側で実⾏
ü必要なサーバー コンポーネントなし
ü静的サイトとしてホスト
üオフラインで実⾏可能
ü⼤きなダウンロードサイズ
üランタイムパフォーマンスの低下
Blazor Server (.NET 5) Blazor WebAssembly (.NET 5)
15. Get started with Blazor
• Go to https://blazor.net
• Install the .NET SDK
• .NET Conf 2021 https://www.dotnetconf.net/
• .NET Conf 2021 – videos/slides/demos
https://github.com/dotnet-presentations/dotNETConf/tree/master/2021/MainEvent/Technical
Visual Studio Visual Studio for Mac Visual Studio Code
+ C# extension
20. EC Demo アプリの構成 1
Azure
SQL Database
Elastic Cloud
東⽇本リージョン
マスターノード x 1
データノード x 2
ML ノード x 1
https://f79...c67.japaneast
.azure.elastic-
cloud.com:9243/
全⽂検索クエリ
検索・更新 UI
Azure サブスクリプション
Azure
App Service
Elastic APM
Endpoint に送信
Blazor
Server
APM .NET Agent
Blazor
WebAssembly
CRUD
Visual
Studio
2022 for
Mac Azure Data Studio
21. EC Demo アプリの構成 2
Azure
SQL Database
Elastic Cloud
東⽇本リージョン
マスターノード x 1
データノード x 2
ML ノード x 1
https://f79...c67.japaneast
.azure.elastic-
cloud.com:9243/
CRUD
Azure サブスクリプション
Visual
Studio
2022 for
Mac
Azure
App Service
Elastic APM
Endpoint に送信
Azure Data Studio
ASP.NET 6 Web API
Azure
Static Web Apps
Blazor
WebAssembly
検索・更新 UI
APM .NET Agent
Blazor
WebAssembly
全⽂検索クエリ
26. Product Model の追加
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
namespace BlazorECommerceApp.Shared
{
public class Product
{
public int Id { get; set; }
public string Title { get; set; };
public string Description { get; set; };
public string ImageUrl { get; set; };
public decimal Price { get; set; }
}
}
---
@using BlazorECommerceApp.Shared
---
51. Category を実装する
using System;
using System.Collections.Generic;
using System.ComponentModel.DataAnnotations.Schema;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
namespace BlazorECommerceApp.Shared
{
public class Category
{
public int Id { get; set; }
public string Name { get; set; } = string.Empty;
public string Url { get; set; } = string.Empty;
public bool Visible { get; set; } = true;
public bool Deleted { get; set; } = false;
[NotMapped]
public bool Editing { get; set; } = false;
[NotMapped]
public bool IsNew { get; set; } = false;
}
}
52. Category の Seeding と Migration(3回⽬)
•
•
---
modelBuilder.Entity<Category>().HasData(
new Category
{
Id = 1,
Name = "Books",
Url = "books"
},
new Category
{
Id = 2,
Name = "Movies",
Url = "movies"
},
new Category
{
Id = 3,
Name = "Video Games",
Url = "video-games"
}
);
---
• DataContext.cs
122. ショッピングカート - 3
Client → CartItem.cs
---
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
namespace BlazorEcommerce.Shared
{
public class CartItem
{
public int ProductId { get; set; }
public int ProductTypeId { get; set; }
}
}---
• カートを追加
• デバッグ実⾏して画⾯のカート部分を確認
130. CartItem のサーバー側
Products への送付- 1
• Shared の CartProductResponse.cs
Shared → CartProductResponse.cs
---
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
namespace BlazorEcommerceApp.Shared
{
public class CartProductResponse
{
public int ProductId { get; set; }
public string Title { get; set; } = string.Empty;
public int ProductTypeId { get; set; }
public string ProductType { get; set; } =
string.Empty;
public string ImageUrl { get; set; } =
string.Empty;
public decimal Price { get; set; }
public int Quantity { get; set; }
}
}
---
131. CartItem のサーバー側
Products への送付- 2
• Server → Services → CartService
フォルダ作成
• Server → Services → ICartService
• Server → Services → CartService
を追加
Server → Program.cs
//下記を追加
---
builder.Services.AddScoped<ICartService, CartService>();
---
global using BlazorEcommerce.Server.Services.CartService;
---
132. CartItem のサーバー側
Products への送付- 3
• Server → Services → CartServiceProgram.cs 実装
Server → Services → CartServiceProgram.cs
---
using System.Security.Claims;
namespace BlazorEcommerce.Server.Services.CartService
{
public class CartService : ICartService
{
private readonly DataContext _context;
public CartService(DataContext context, IAuthService authService)
{
_context = context;
}
public async Task<ServiceResponse<List<CartProductResponse>>>
GetCartProducts(List<CartItem> cartItems)
{
var result = new ServiceResponse<List<CartProductResponse>>
{
Data = new List<CartProductResponse>()
};
foreach (var item in cartItems)
{
var product = await _context.Products
.Where(p => p.Id == item.ProductId)
.FirstOrDefaultAsync();
if (product == null)
{
continue;
}
var productVariant = await _context.ProductVariants
.Where(v => v.ProductId == item.ProductId
&& v.ProductTypeId == item.ProductTypeId)
.Include(v => v.ProductType)
.FirstOrDefaultAsync();
if (productVariant == null)
{
continue;
}
var cartProduct = new CartProductResponse
{
ProductId = product.Id,
Title = product.Title,
ImageUrl = product.ImageUrl,
Price = productVariant.Price,
ProductType = productVariant.ProductType.Name,
ProductTypeId = productVariant.ProductTypeId,
Quantity = item.Quantity
};
result.Data.Add(cartProduct);
}
return result;
}
---
133. CartItem のサーバー側
Products への送付- 4
• Server → Controller→
CartController.cs 実装
Server → Controller → CartController.cs
//
using Microsoft.AspNetCore.Http;
using Microsoft.AspNetCore.Mvc;
using System.Security.Claims;
namespace BlazorEcommerceApp.Server.Controllers
{
[Route("api/[controller]")]
[ApiController]
public class CartController : ControllerBase
{
private readonly ICartService _cartService;
public CartController(ICartService cartService)
{
_cartService = cartService;
}
[HttpPost("products")]
public async
Task<ActionResult<ServiceResponse<List<CartProductResponse>>>>
GetCartProducts(List<CartItem> cartItems)
{
var result = await _cartService.GetCartProducts(cartItems);
return Ok(result);
}
---
---
153. まとめ
l 前回までの復習
l Blazor 概要
l 今回作成する Web アプリケーションの概要
l Blazor WebAssembly プロジェクト作成
l Web API コントローラー追加、モデル追加
l Entity Framework による Code First データベース作成
l 商品サービス、商品リスト、カテゴリーサービス等必要なサービス、CRUD 処理等の実装
l 検索サービスの追加と検索コンポーネントの実装、カートサービス、UI/UX の変更
l 認証・ユーザー登録、その他の機能の実装(別の機会に︕)
154. リソース
l セッションでご紹介した EC アプリ .NET 5版ですが、参考にさせて戴きました。
l https://github.com/patrickgod/BlazorEcommercePreviewYT
