The document analyzes the blast resistance of structures through modeling and analysis. It studies a 12-story reinforced concrete building model subjected to different blast loads. Four different structural models are analyzed: conventional frame, increased member sizes, addition of corner shear walls, and addition of corner steel bracing. The models are analyzed under blast loads of 100kg and 300kg at standoff distances of 20m and 30m. Results show time periods and frequencies varying between the models, with the conventional frame having the highest time periods. Addition of shear walls reduces time periods the most. The study concludes variations could be analyzed for unsymmetrical structures.
