The document is a notification from the Central Electricity Regulatory Commission regarding amendments to the Central Electricity Regulatory Commission (Indian Electricity Grid Code) Regulations, 2010. Key points:
- It introduces new definitions related to deviation settlement mechanism regulations and pooling stations.
- It modifies various regulations regarding frequency response obligations of generators, scheduling and despatch, and treatment of deviations from schedules.
- Maximum deviations from schedules will now be as specified in the Deviation Settlement Mechanism Regulations.
- Schedules will be deemed revised to actual generation and drawal during grid disturbances based on certification by RLDCs.
