Troubleshooting and Diagnosing Oracle
Database 12.2 and Oracle RAC
Sandesh Rao, Senior Director , RAC Development
https://www.linkedin.com/in/raosandesh/
sandeshr

Safe Harbor Statement
The following is intended to outline our general product direction. It is intended for
information purposes only, and may not be incorporated into any contract. It is not a
commitment to deliver any material, code, or functionality, and should not be relied upon
in making purchasing decisions. The development, release, and timing of any features or
functionality described for Oracle’s products remains at the sole discretion of Oracle.
Confidential – Oracle Restricted 2

Common Questions
• How do I contact you ?
– Linkedin – Sandesh Rao
– Email – Sandesh.rao@oracle.com
• Where do I get your presentation ?
– http://otnyathra.in/downloads/
• Which books on RAC do I read for basics or internals ?
– Oracle Database 11g Oracle Real Application Clusters Handbook, 2nd Edition (Oracle Press) 2nd Edition
– Pro Oracle Database 11g RAC on Linux (Expert's Voice in Oracle) 2nd ed. Edition
– Oracle 10g RAC Grid, Services and Clustering 1st Edition
– Pro Oracle Database 10g RAC on Linux: Installation, Administration, and Performance (Expert's Voice in
Oracle) 1st Corrected ed., Corr. 3rd printing Edition
– Oracle Database 12c Release 2 Oracle Real Application Clusters Handbook: Concepts, Administration, Tuning &
Troubleshooting (Oracle Press) 1st Edition
– Documentation – Autonomous Computing Guide , RAC Admin guide
Confidential – Oracle Internal/Restricted/Highly Restricted 3

Agenda
• Architectural Overview
• Troubleshooting Scenarios
• Proactive and Reactive tools
• Q&A

Grid Infrastructure Overview
• Grid Infrastructure is the name for the combination of
– Oracle Cluster Ready Services (CRS)
– Oracle Automatic Storage Management (ASM)
• The Grid Home contains the software for both products
• CRS can also be Standalone for ASM and/or Oracle Restart
• CRS can run by itself or in combination with other vendor clusterware
• Grid Home and RDBMS home must be installed in different locations
– The installer locks the Grid Home path by setting root permissions.

• CRS requires shared Oracle Cluster Registry (OCR) and Voting files
– Must be in ASM or CFS
– OCR backed up every 4 hours automatically GIHOME/cdata
– Kept 4,8,12 hours, 1 day, 1 week
– Restored with ocrconfig
– Voting file backed up into OCR at each change.
– Voting file restored with crsctl

• For network CRS requires
– One/multiple high speed, low latency, redundant private network for inter node
communications
– Think of interconnect as a memory backplane for the cluster
– Should be a separate physical network or managed converged network
– VLANS are supported
– Used for :-
• Clusterware messaging
• RDBMS messaging and block transfer
• ASM messaging
• HANFS for block traffic

• Only one set of Clusterware daemons can run on each node
• The CRS stack is spawned from Oracle HA Services Daemon (ohasd)
• On Unix ohasd runs out of inittab with respawn
• A node can be evicted when deemed unhealthy
– May require reboot but at least CRS stack restart (rebootless restart)
– IPMI integration or diskmon in case of Exadata
• CRS provides Cluster Time Synchronization services
– Always runs but in observer mode if ntpd configured

Grid Infrastructure Processes
Agents change everything
• Multi-threaded Daemons
• Manage multiple resources and types
• Implements entry points for multiple resource types
– Start,stop check,clean,fail
• oraagent, orarootagent, application agent, script agent, cssdagent
• Single process started from init on Unix (ohasd)
• Diagram below shows all core resources

Level 1
Level 2a
Level 2b
Level 3
Level 4a
Level 4b
Level 0

Init Scripts
• /etc/init.d/ohasd ( location O/S dependent )
– RC script with “start” and “stop” actions
– Initiates Oracle Clusterware autostart
– Control file coordinates with CRSCTL
• /etc/init.d/init.ohasd ( location O/S dependent )
– OHASD Framework Script runs from init/upstart
– Control file coordinates with CRSCTL
– Named pipe syncs with OHASD

• Level 1: OHASD Spawns:
– cssdagent - Agent responsible for spawning CSSD
– orarootagent - Agent responsible for managing all root owned ohasd resources
– oraagent - Agent responsible for managing all oracle owned ohasd resources
– cssdmonitor - Monitors CSSD and node health (along with the cssdagent)
• Level 2a: OHASD rootagent spawns:
– CRSD - Primary daemon responsible for managing cluster resources.
– CTSSD - Cluster Time Synchronization Services Daemon
– Diskmon ( Exadata )
– ACFS (ASM Cluster File System) Drivers

• Level 2b: OHASD oraagent spawns:
– MDNSD– Multicast DNS daemon
– GIPCD – Grid IPC Daemon
– GPNPD – Grid Plug and Play Daemon
– EVMD – Event Monitor Daemon
– ASM – ASM instance started here as may be required by CRSD
• Level 3: CRSD spawns:
– orarootagent - Agent responsible for managing all root owned crsd resources.
– oraagent - Agent responsible for managing all nonroot owned crsd resources.
• One is spawned for every user that has CRS resources to manage.

• Level 4: CRSD oraagent spawns:
– ASM Resouce - ASM Instance(s) resource (proxy resource)
– Diskgroup - Used for managing/monitoring ASM diskgroups.
– DB Resource - Used for monitoring and managing the DB and instances
– SCAN Listener - Listener for single client access name, listening on SCAN VIP
– Listener - Node listener listening on the Node VIP
– Services - Used for monitoring and managing services
– ONS - Oracle Notification Service
– eONS - Enhanced Oracle Notification Service ( pre 11.2.0.2 )
– GSD - For 9i backward compatibility
– GNS (optional) - Grid Naming Service - Performs name resolution
Startup Sequence

Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | 15
The standard going forward
(every Oracle 12c Rel. 2 cluster
is a Flex Cluster by default.)
Oracle Flex Cluster

Under the Hood: Any New Install Ends Up in a Flex Cluster
[GRID]> crsctl get cluster name
CRS-6724: Current cluster name is 'SolarCluster'
[GRID]> crsctl get cluster class
CRS-41008: Cluster class is 'Standalone Cluster'
[GRID]> crsctl get cluster type
CRS-6539: The cluster type is 'flex'.

Domain Services Cluster
Cluster Domain
IO Service
ASM
Service
Database
Member Cluster
Uses ASM
Service
Database
Member Cluster
Uses IO & ASM
Service of DSC
Trace File
Analyzer
(TFA)
Service
Mgmt
Repository
(GIMR)
Service
Application
Member Cluster
GI only
Database
Member Cluster
Uses local ASM
Shared ASM
Additional
Optional
Services
Rapid Home
Provisioning
(RHP)
Service
Private
Network
SAN
NAS
1 2 3 4

Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | Oracle Confidential – Internal/Restricted/Highly Restricted 18
Database-oriented Storage Management for more flexibility and availability
ASM Flex Diskgroups 1
Pre-12.2 diskgroup Organization
Diskgroup
DB3 : File 1
DB2 : File 2 DB1 : File 3
DB3 : File 3
DB2 : File 1
DB1 : File 1
DB1 : File 2
DB2 : File 3DB3 : File 2
DB2 : File 4
12.2 Flex Diskgroup Organization
Flex Diskgroup
DB1
File 1
File 2
File 3
DB2
File 1
File 2
File 3
File 4
DB3
File 1
File 2
File 3
File Group
Shared resource
management
Database-oriented
resource management

Flex Diskgroup
DB1
File 1
File 2
File 3
DB2
File 1
File 2
File 3
File 4
DB3
File 1
File 2
File 3
Oracle Confidential – Internal/Restricted/Highly Restricted 19
Database-oriented Storage Management for more flexibility and availability
ASM Flex Diskgroups 2
Quota
DB3
File 1
File 2
File 3
12.2 Flex Diskgroup Organization
• Flex Diskgroups enable
– Quota Management - limit the space
databases can allocate in a diskgroup and
thereby improve the customers’ ability to
consolidate databases into fewer DGs
– Redundancy Change – utilize lower
redundancy for less critical databases
– Shadow Copies (“split mirrors”) to easily
and dynamically create database clones
for test/dev or production databases

• Node Weighting is a new feature that considers
the workload hosted in the cluster during fencing
• The idea is to let the majority of work survive,
if everything else is equal
– Example: In a 2-node cluster, the node hosting the
majority of services (at fencing time) is meant to survive
Node Weighting in Oracle RAC 12c Release 2
Idea: Everything equal, let the majority of work survive
✔
1 2

CSS_CRITICAL
can be set on various levels /
components to mark them as
“critical” so that the cluster will try to
preserve them in case of a failure.
21
CSS_CRITICAL will be honored
if no other technical reason prohibits
survival of the node which has at
least one critical component at the
time of failure.
A fallback scheme is applied if
CSS_CRITICAL settings do not lead to
an actionable outcome.
CSS_CRITICAL – Fencing with Manual Override
crsctl set server
css_critical {YES|NO}
+ server restart
srvctl modify database -help
|grep critical
…
-css_critical {YES | NO}
Define whether the database
or service is CSS critical
✔
Node eviction
despite WL; WL
will failover.
“Conflict”.

Autonomous Health Framework
(powered by machine learning)
works more efficiently for you on the
DSC, as continuous analysis is taken
off the production cluster.
22
The DSC is the ideal hosting
environment for Rapid Home
Provisioning (RHP) enabling software
fleet management.
Oracle ASM 12c Rel. 2 based storage
consolidation is best performed on
the DSC, as it enables numerous
additional features and use cases.
Proven Features – Even More Beneficial on the DSC

Node Eviction Basics

SAN
Network
SAN
Network
Public LanPublic Lan
CSSD
Basic RAC Cluster with Oracle Clusterware
CSSDCSSD
Voting
Disk
Private Lan /
Interconnect

What does CSSD do?
CSSD monitors and evicts nodes
• Monitors nodes using 2 communication channels:
– Private Interconnect ó Network Heartbeat
– Voting Disk based communication ó Disk Heartbeat
• Evicts (forcibly removes nodes from a cluster)
nodes dependent on heartbeat feedback (failures)
CSSDCSSD
“Ping”
“Ping”

Network Heartbeat
Interconnect basics
• Each node in the cluster is “pinged” every second
• Nodes must respond in css_misscount time (defaults to 30 secs.)
– Reducing the css_misscount time is generally not supported
• Network heartbeat failures will lead to node evictions
– CSSD-log: [date / time] [CSSD][1111902528]clssnmPollingThread: node
mynodename (5) at 75% heartbeat fatal, removal in 6.770 seconds
CSSDCSSD “Ping”

Disk Heartbeat
Voting Disk basics – Part 1
CSSDCSSD
“Ping”
• Each node in the cluster “pings” (r/w) the Voting Disk(s) every second
• Nodes must receive a response in (long / short) diskTimeout time
– I/O errors indicate clear accessibility problems à timeout is irrelevant
• Disk heartbeat failures will lead to node evictions
– CSSD-log: … [CSSD] [1115699552] >TRACE: clssnmReadDskHeartbeat:
node(2) is down. rcfg(1) wrtcnt(1) LATS(63436584) Disk lastSeqNo(1)

Voting Disk Structure
• Voting Disks contain dynamic and static data:
– Dynamic data: disk heartbeat logging
– Static data: information about the nodes in the cluster
• With 11.2.0.1 Voting Disks got an “identity”:
– E.g. Voting Disk serial number: [GRID]> crsctl query css votedisk
1. 2 1212f9d6e85c4ff7bf80cc9e3f533cc1 (/dev/sdd5) [DATA]
• Voting Disks must therefore not be copied using “dd” or “cp” anymore
Node information Disk Heartbeat Logging

“Simple Majority Rule”
CSSDCSSD
• Oracle supports redundant Voting Disks for disk failure protection
• “Simple Majority Rule” applies:
– Each node must “see” the simple majority of configured Voting Disks
at all times in order not to be evicted (to remain in the cluster)
Ø trunc(n/2+1) with n=number of voting disks configured and n>=1

Insertion 1: “Simple Majority Rule”…
… In extended Oracle clusters
CSSDCSSD
• Same principles apply
• Voting Disks are just
geographically dispersed
• http://www.oracle.com/goto/rac
– Using standard NFS to support
a third voting file for extended
cluster configurations (PDF)

• Oracle ASM auto creates 1/3/5 Voting Files
– Based on Ext/Normal/High redundancy
and on Failure Groups in the Disk Group
– Per default there is one failure group per disk
– ASM will enforce the required number of disks
– New failure group type: Quorum Failgroup
[GRID]> crsctl query css votedisk
1. 2 1212f9d6e85c4ff7bf80cc9e3f533cc1 (/dev/sdd5) [DATA]
2. 2 aafab95f9ef84f03bf6e26adc2a3b0e8 (/dev/sde5) [DATA]
3. 2 28dd4128f4a74f73bf8653dabd88c737 (/dev/sdd6) [DATA]
Located 3 voting disk(s).
Insertion 2: Voting Disk in Oracle ASM
The way of storing Voting Disks doesn’t change its use

Why are nodes evicted?
è To prevent worse things from happening…
• Evicting (fencing) nodes is a preventive measure (a good thing)!
• Nodes are evicted to prevent consequences of a split brain:
– Shared data must not be written by independently operating nodes
– The easiest way to prevent this is to forcibly remove a node from the cluster
CSSDCSSD
1 2

How are nodes evicted?
EXAMPLE: Heartbeat failure
• The network heartbeat between nodes has failed
– It is determined which nodes can still talk to each other
– A “kill request” is sent to the node(s) to be evicted
§ Using all (remaining) communication channels à Voting Disk(s)
• A node is requested to “kill itself”; executer: typically CSSD
CSSDCSSD
1
2

Re-bootless Node
Fencing (restart)

Re-bootless Node Fencing (restart)
Fence the cluster, do not reboot the node
• Until Oracle Clusterware 11.2.0.2, fencing meant “re-boot”
• With Oracle Clusterware 11.2.0.2, re-boots will be seen less, because:
– Re-boots affect applications that might run an a node, but are not protected
– Customer requirement: prevent a reboot, just stop the cluster – implemented...
CSSD
Oracle RAC
DB Inst. 1
Oracle RAC
DB Inst. 2
Standalone
App X
Standalone
App Y
CSSD

How it works
• With Oracle Clusterware 11.2.0.2, re-boots will be seen less:
– Instead of fast re-booting the node, a graceful shutdown of the stack is attempted
• Then IO issuing processes are killed; it is made sure that no IO process remains
– For a RAC DB mainly the log writer and the database writer are of concern
CSSD
Standalone
App X
Standalone
App Y
CSSD
Oracle RAC
DB Inst. 1

EXCEPTIONS
• With Oracle Clusterware 11.2.0.2, re-boots will be seen less, unless…:
– IF the check for a successful kill of the IO processes fails → reboot
– IF CSSD gets killed during the operation → reboot
– IF cssdmonitor is not scheduled → reboot
– IF the stack cannot be shutdown in “short_disk_timeout”-seconds → reboot
CSSD
Standalone
App X
Standalone
App Y
CSSD
Oracle RAC
DB Inst. 1
Oracle RAC
DB Inst. 2

Troubleshooting Scenarios
Cluster Startup Problem Triage (11.2+)
Startup
Sequence
ps –ef|grep init.ohasd
ps –ef|grep ohasd.bin Running?
YES
NO crsctl config crs
ohasd.log Obvious?
NO Engage Oracle Support
Engage Sysadmin Team
Cluster Startup
Diagnostic Flow
TFA Collector
ps –ef|grep cssdagent
ps –ef|grep ocssd.bin
ps –ef|grep orarootagent
ps –ef|grep ctssd.bin
ps –ef|grep crsd.bin
ps –ef|grep cssdmonitor
ps –ef|grep oraagent
ps –ef|grep ora.asm
ps –ef|grep gpnpd.bin
ps –ef|grep mdnsd.bin
ps –ef|grep evmd.bin
Crsctl check crs
Crsctl check cluster
Running?
YES
NO
YES
Engage Sysadmin Team
ohasd.log
agent logs
process logs
Obvious?
YES
NO
Engage
Sysadmin Team
Engage
Oracle Support
Sysadmin Team
TFA Collector
ohasd.log
OLR perms
Compare reference system
Obvious?
YESNO
TFA Collector
Engage
Sysadmin Team
Engage
Oracle Support
Sysadmin Team

• Multicast Domain Name Service Daemon (mDNS(d))
– Used by Grid Plug and Play to locate profiles in the cluster, as well as by GNS to perform
name resolution. The mDNS process is a background process on Linux and UNIX and on
Windows.
– Uses multicast for cache updates on service advertisement arrival/departure.
– Advertises/serves on all found node interfaces.
– Log is GI_HOME/log/<node>/mdnsd/mdnsd.log
Cluster Startup Problem Triage

<?xml version="1.0" encoding="UTF-8"?>
<gpnp:GPnP-Profile Version="1.0" xmlns="http://www.grid-pnp.org/2005/11/gpnp-profile" xmlns:gpnp="http://www.grid-
pnp.org/2005/11/gpnp-profile" xmlns:orcl="http://www.oracle.com/gpnp/2005/11/gpnp-profile"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://www.grid-pnp.org/2005/11/gpnp-profile
gpnp-profile.xsd" ProfileSequence="6" ClusterUId="b1eec1fcdd355f2bbf7910ce9cc4a228" ClusterName="staij-cluster"
PALocation="">
<gpnp:Network-Profile><gpnp:HostNetwork id="gen" HostName="*">
<gpnp:Network id="net1" IP=”192.168.1.0" Adapter="eth0" Use="public"/>
<gpnp:Network id="net2" IP=”192.168.2.0" Adapter="eth1“ Use="cluster_interconnect"/>
</gpnp:HostNetworkcss"></gpnp:Network-Profile>
<orcl:CSS-Profile id=" DiscoveryString="+asm" LeaseDuration="400"/>
<orcl:ASM-Profile id="asm" DiscoveryString="" SPFile="+SYSTEM/staij-cluster/asmparameterfile/registry.253.693925293"/>
<ds:Signature xmlns:ds="http://www.w3.org/2000/09/xmldsig#"><ds:SignedInfo><ds:CanonicalizationMethod
Algorithm="http://www.w3.org/2001/10/xml-exc-c14n#"/><ds:SignatureMethod Algorithm="http://www.w3.org/2001/10/xml-
exc-c14n#"> <InclusiveNamespaces xmlns="http://www.w3.org/2001/10/xml-exc-c14n#" PrefixList="gpnp orcl
xsi"/></ds:Transform></ds:Transforms><ds:DigestMethod
Algorithm="http://www.w3.org/2000/09/xmldsig#sha1"/><ds:DigestValue>x1H9LWjyNyMn6BsOykHhMvxnP8U=</ds:DigestValue
></ds:Reference></ds:SignedInfo><ds:SignatureValue>N+20jG4=</ds:SignatureValue></ds:Signature>
</gpnp:GPnP-Profile>

• cssd agent and monitor
– Same functionality in both agent and monitor
– Functionality of several pre-11.2 daemons consolidated in both
• OPROCD – system hang
• OMON – oracle clusterware monitor
• VMON – vendor clusterware monitor
– Run realtime with locked down memory, like CSSD
– Provides enhanced stability and diagnosability
– Logs are
• GI_HOME/log/<node>/agent/oracssdagent_root/oracssdagent_root.log
• GI_HOME/log/<node>/agent/oracssdmonitor_root/oracssdmonitor_root.log
• 12c – ORACLE_BASE/diag/node/agent/..

Node Evictions
Eviction
Scenario
Cluster alert
ocssd.log
NHB?
1050693.1
1534949.1
1546004.1
Engage
networking team
YES
NO
DHB?
1549428.1
1466639.1 YES
NO
Obvious?
NO
YES
Obvious?
NO
YES
Fenced?
Resource starvation
YES
NO
NO
YES
Node Eviction
Diagnostic Flow
Resource
Starvation?
NO
Engage
Oracle
Support
Engage
sysadmin
team
Engage storage
team
1531223.1
1328466.1
System log
YES
Engage
appropriate
team
Resolved?
NO
YES
Free memory?
CPU load?
Node Response?
TFA Collector
TFA Collector

Missing Network Heartbeat (1)
• ocssd.log from node 1
• ===> sending network heartbeats other nodes. Normally, this message is output once every 5 messages (seconds)
• 2016-08-13 17:00:20.023: [ CSSD][4096109472]clssnmSendingThread: sending status msg to all nodes
• 2016-08-13 17:00:20.023: [ CSSD][4096109472]clssnmSendingThread: sent 5 status msgs to all nodes
• ===> The network heartbeat is not received from node 2 (drrac2) for 15 consecutive seconds.
• ===> This means that 15 network heartbeats are missing and is the first warning (50% threshold).
• 2016-08-13 17:00:22.818: [ CSSD][4106599328]clssnmPollingThread: node drrac2 (2) at 50% heartbeat fatal, removal in 14.520
seconds
• 2016-08-13 17:00:22.818: [ CSSD][4106599328]clssnmPollingThread: node drrac2 (2) is impending reconfig, flag 132108,
misstime 15480
• ===> continuing to send the network heartbeats and log messages once every 5 messages
• ===> 75% threshold of missing network heartbeat is reached. This is second warning.
seconds

• ===> continuing to send the network heartbeats and log messages once every 5 messages
• ===> continuing to send the network heartbeats, but the message is logged after 4 messages
• ===> Last warning shows that 90% threshold of the missing network heartbeat is reached.
• ===> The eviction will occur in 2.49 seconds.
• 2016-08-13 17:00:34.841: [ CSSD][4106599328]clssnmPollingThread: node drrac2 (2) at 90% heartbeat fatal, removal in
2.490 seconds, seedhbimpd 1
• ===> Eviction of node 2 (drrac2) started
• 2016-08-13 17:00:37.337: [ CSSD][4106599328]clssnmPollingThread: Removal started for node drrac2 (2), flags 0x2040c,
state 3, wt4c 0
• ===> This shows that the node 2 is actively updating the voting disks
• 2016-08-13 17:00:37.340: [ CSSD][4085619616]clssnmCheckSplit: Node 2, drrac2, is alive, DHB (1281744040, 1396854)
more than disk timeout of 27000 after the last NHB (1281744011, 1367154)

• ===> Evicting node 2 (drrac2)
• 2016-08-13 17:00:37.340: [ CSSD][4085619616](:CSSNM00007:)clssnmrEvict: Evicting node 2, drrac2, from the cluster in
incarnation 169934272, node birth incarnation 169934271, death incarnation 169934272, stateflags 0x24000
• ===> Reconfigured the cluster without node 2
• 2016-08-13 17:01:07.705: [ CSSD][4043389856]clssgmCMReconfig: reconfiguration successful, incarnation 169934272 with 1
nodes, local node number 1, master node number 1

• ocssd.log from node 2:
• ===> Logging the message to indicate 5 network heartbeats are sent to other nodes
• ===> First warning of reaching 50% threshold of missing network heartbeats
seconds
• 2016-08-13 17:00:26.213: [ CSSD][4073040800]clssnmPollingThread: node drrac1 (1) is impending reconfig, flag 394254,
misstime 15460
• ===> Second warning of reaching 75% threshold of missing network heartbeats
seconds

• ===> Logging the message to indicate 4 network heartbeats are sent
• ===> Third warning of reaching 90% threshold of missing network heartbeats
• 2016-08-13 17:00:38.236: [ CSSD][4073040800]clssnmPollingThread: node drrac1 (1) at 90% heartbeat fatal, removal in
2.460 seconds, seedhbimpd 1
• ===> Eviction started for node 1 (drrac1)
• 2016-08-13 17:00:40.702: [ CSSD][4073040800]clssnmPollingThread: Removal started for node drrac1 (1), flags 0x6040e,
state 3, wt4c 0
• ===> Node 1 is actively updating the voting disk, so this is a split brain condition
• 2016-08-13 17:00:40.706: [ CSSD][4052061088]clssnmCheckSplit: Node 1, drrac1, is alive, DHB (1281744036, 1243744)
more than disk timeout of 27000 after the last NHB (1281744007, 1214144)
• 2016-08-13 17:00:40.706: [ CSSD][4052061088]clssnmCheckDskInfo: My cohort: 2
• 2016-08-13 17:00:40.707: [ CSSD][4052061088]clssnmCheckDskInfo: Surviving cohort: 1

• ===> Node 2 is aborting itself to resolve the split brain and ensure the cluster integrity
• 2016-08-13 17:00:40.707: [ CSSD][4052061088](:CSSNM00008:)clssnmCheckDskInfo: Aborting local node to avoid splitbrain.
Cohort of 1 nodes with leader 2, drrac2, is smaller than cohort of 1 nodes led by node 1, drrac1, based on map type 2
• 2016-08-13 17:00:40.707: [ CSSD][4052061088]###################################
• 2016-08-13 17:00:40.707: [ CSSD][4052061088]clssscExit: CSSD aborting from thread clssnmRcfgMgrThread
• 2016-08-13 17:00:40.707: [ CSSD][4052061088]###################################

• Observations
1. Both nodes reported missing heartbeats at the same time
2. Both nodes sent heartbeats to other nodes all the time
3. Node 2 aborted itself to resolve split brain
• Conclusion
1. This is likely a network problem, engage network team
2. Check OSWatcheroutput (netstat and traceroute)
1. Configure private.net file, not configured by default
3. Check CHM
4. Check system log

Voting Disk Access Problem (1)
ocssd.log:
===> The first error indicating that it could not read voting disk -- first message to indicate a
problem accessing the voting disk
2016-08-13 18:31:19.787: [ SKGFD][4131736480]ERROR: -9(Error 27072, OS Error (Linux
Error: 5: Input/output error
Additional information: 4
Additional information: -1)
)
2016-08-13 18:31:19.787: [ CSSD][4131736480](:CSSNM00060:)clssnmvReadBlocks: read
failed at offset 529 of /dev/sdb8
2016-08-13 18:31:19.802: [ CSSD][4131736480]clssnmvDiskAvailabilityChange: voting file
/dev/sdb8 now offline

====> The error message that shows a problem accessing the voting disk repeats once every 4 seconds
2016-08-13 18:31:23.782: [ CSSD][150477728]clssnmvDiskOpen: Opening /dev/sdb8
2016-08-13 18:31:23.782: [ SKGFD][150477728]Handle 0xf43fc6c8 from lib :UFS:: for disk :/dev/sdb8:
2016-08-13 18:31:23.782: [ CLSF][150477728]Opened hdl:0xf4365708 for dev:/dev/sdb8:
2016-08-13 18:31:23.787: [ SKGFD][150477728]ERROR: -9(Error 27072, OS Error (Linux Error: 5:
Input/output error
)
2016-08-13 18:31:23.787: [ CSSD][150477728](:CSSNM00060:)clssnmvReadBlocks: read failed at offset 17
of /dev/sdb8

====> The last error that shows a problem accessing the voting disk.
====> Note that the last message is 200 seconds after the first message
====> because the long disktimeout is 200 seconds
2016-08-13 18:34:37.423: [ CSSD][150477728]clssnmvDiskOpen: Opening /dev/sdb8
2016-08-13 18:34:37.423: [ CLSF][150477728]Opened hdl:0xf4336530 for dev:/dev/sdb8:
2016-08-13 18:34:37.429: [ SKGFD][150477728]ERROR: -9(Error 27072, OS Error (Linux Error: 5:
Input/output error
)
2016-08-13 18:34:37.429: [ CSSD][150477728](:CSSNM00060:)clssnmvReadBlocks: read failed at offset 17
of /dev/sdb8

====> This message shows that ocssd.bin tried accessing the voting disk for 200 seconds
2016-08-13 18:34:38.205: [ CSSD][4110736288](:CSSNM00058:)clssnmvDiskCheck: No I/O completions for
200880 ms for voting file /dev/sdb8)
====> ocssd.bin aborts itself with an error message that the majority of voting disks are not available. In
this case, there was only one voting disk, but if three voting disks were available, as long as two
voting disks are accessible, ocssd.bin will not abort.
2016-08-13 18:34:38.206: [ CSSD][4110736288](:CSSNM00018:)clssnmvDiskCheck: Aborting, 0 of 1
configured voting disks available, need 1
2016-08-13 18:34:38.206: [ CSSD][4110736288]###################################
2016-08-13 18:34:38.206: [ CSSD][4110736288]clssscExit: CSSD aborting from thread
clssnmvDiskPingMonitorThread
2016-08-13 18:34:38.206: [ CSSD][4110736288]###################################
• Conclusion
The voting disk was not available, engage storage team

• Time synchronisation issue
• Cluster Time Synchronisation Services daemon
– Provides time management in a cluster for Oracle.
• Observer mode when Vendor time synchronisation s/w is found
–Logs time difference to the CRS alert log
• Active mode when no Vendor time sync s/w is found
Node Eviction Triage

• Cluster Ready Services Daemon
– The CRSD daemon is primarily responsible for maintaining the availability of application
resources, such as database instances. CRSD is responsible for starting and stopping these
resources, relocating them when required to another node in the event of failure, and
maintaining the resource profiles in the OCR (Oracle Cluster Registry). In addition, CRSD is
responsible for overseeing the caching of the OCR for faster access, and also backing up the
OCR.
– Log file is GI_HOME/log/<node>/crsd/crsd.log
• Rotation policy 10-50M
• Retention policy 10 logs
• Dynamic in 12.1 and can be changed

• CRSD oraagent
– CRSD’s oraagent manages
• all database, instance, service and diskgroup resources
• node listeners
• SCAN listeners, and ONS
– If the Grid Infrastructure owner is different from the RDBMS home owner then you would
have 2 oraagents each running as one of the installation owners. The database, and service
resources would be managed by the RDBMS home owner and other resources by the Grid
Infrastructure home owner.
– Log file is
• GI_HOME/log/<node>/agent/crsd/oraagent_<user>/oraagent_<user>.log

• CRSD orarootagent
– CRSD’s rootagent manages
• GNS and it’s VIP
• Node VIP
• SCAN VIP
• network resources.
– Log file is
• GI_HOME/log/<node>/agent/crsd/orarootagent_root/oraagent_root.log

• Agent return codes
– Check entry must return one of the following return codes:
• ONLINE
• UNPLANNED_OFFLINE
– Target=online, may be recovered failed over
• PLANNED_OFFLINE
• UNKNOWN
– Cannot determine, if previously online, partial then monitor
• PARTIAL
– Some of a resources services are available. Instance up but not open.
• FAILED
– Requires clean action

§ Important logs and traces
§ 11.2 – Databases only use ADR
• Grid Infrastructure files in $GI_HOME/log/<node_name>/<component_name>
– $GI_HOME/log/myHost/cssd
– $GI_HOME/log/myHost/alertmyHost.log
§ 12c – Grid Infrastructure and Database use ADR
§ Different locations for Grid Infrastructure and Databases
§ Grid Infrastructure
• Alert.log, cssd.log, csrd.log, etc
§ Databases
§ Alert.log, background process traces, foreground process traces
Automatic Diagnostic Repository (ADR)

• What if issues were detected before they
had an impact?
• What if you were notified with a specific
diagnosis and corrective actions?
• What if resource bottlenecks threatening
SLAs were identified early?
• What if bottlenecks could be
automatically relieved just in time?
• What if database hangs and node reboots
could be eliminated?
60
Oracle’s Database and Clusterware Tools
Cluster
Verification
Utility
ORAchkCluster
Health
Monitor
Trace File
Analyzer
Quality of
Service
Management
Hang
Manager
EXAchk
Cluster
Health
Advisor
Memory
Guard
Confidential – Oracle Restricted

Maintains Compliance
with Best Practices and
Alerts Vulnerabilities to
Known Issues
61
Oracle 12c ORAchk & EXAchk

Automatic proactive warning
of problems before they
impact you
62
Get scheduled health reports
sent to you in email
Why Oracle ORAchk & EXAchk
Health checks for most impactful
reoccurring problems
Runs in your environment
with no need to send
anything to Oracle
Findings can be integrated
into other tools of choiceEngineered
Systems
Non
Engineered
Systems
EXAchk
Common Framework
ORAchk

Oracle Stack Coverage
• Oracle Engineered Systems
• Oracle Database Appliance
o Oracle Exadata Database Machine
o Oracle SuperCluster / MiniCluster
o Oracle Private Cloud Appliance
o Oracle Big Data Appliance
o Oracle Exalogic Elastic Cloud
o Oracle Exalytics In-Memory Machine
o Oracle Zero Data Loss Recovery Appliance
• Oracle ASR
• Oracle Systems
• Oracle Solaris
• Cross stack checks
• Solaris Cluster
• OVN
63
• Oracle Database
• Standalone Database
• Grid Infrastructure & RAC
• Maximum Availability Architecture (MAA)
Scorecard
• Upgrade Readiness Validation
• Golden Gate
• Oracle Restart
• Oracle Enterprise Manager Cloud Control
• Repository
• Agent
• OMS
• Oracle Middleware
• Application Continuity
• Oracle Identify and Access Management
Suite (Oracle IAM)
• Oracle E-Business Suite
• Oracle Payables
• Oracle Workflow
• Oracle Purchasing
• Oracle Order Management
• Oracle Process Manufacturing
• Oracle Receivables
• Oracle Fixed Assets
• Oracle HCM
• Oracle CRM
• Oracle Project Billing
• Oracle Siebel
• Database best practices
• Oracle PeopleSoft
• Database best practices
• Oracle SAP
• EXAdata best practices

• Profiles provide logical grouping of
checks which are about similar topics
• Run only checks in a specific profile
• Run everything except checks in a specific
profile
Profiles
./exachk –profile <profile>
./exachk –excludeprofile <profile>
Profile Description
asm ASM Checks
avdf Audit Vault Configuration checks
clusterware Oracle clusterware checks
control_VM Checks only for Control VM(ec1-vm, ovmm, db, pc1, pc2).
No cross node checks
corroborate Exadata checks needs further review by user to determine
pass or fail
dba DBA Checks
ebs Oracle E-Business Suite checks
eci_healthchecks Enterprise Cloud Infrastructure Healthchecks
ecs_healthchecks Enterprise Cloud System Healthchecks
goldengate Oracle GoldenGate checks
hardware Hardware specific checks for Oracle Engineered systems
maa Maximum Availability Architecture Checks
ovn Oracle Virtual Networking
platinum Platinum certification checks
preinstall Pre-installation checks
prepatch Checks to execute before patching
security Security checks
solaris_cluster Solaris Cluster Checks
storage Oracle Storage Server Checks
switch Infiniband switch checks
sysadmin Sysadmin checks
user_defined_checks Run user defined checks from user_defined_checks.xml
64

• Profiles provide logical grouping of
checks which are about similar topics
• Run only checks in a specific profile
• Run everything except checks in a specific
profile
Profiles
./orachk –profile <profile>
./orachk –excludeprofile <profile>
Profile Description
asm ASM Checks
bi_middleware Oracle Business Intelligence checks
clusterware Oracle clusterware checks
dba DBA Checks
ebs Oracle E-Business Suite checks
emagent Cloud control agent checks
emoms Cloud Control management server
em Cloud control checks
goldengate Oracle GoldenGate checks
hardware Hardware specific checks for Oracle Engineered systems
oam Oracle Access Manager checks
oim Oracle Identify Manager checks
oud Oracle Unified Directory server checks
ovn Oracle Virtual Networking
peoplesoft Peoplesoft best practices
preinstall Pre-installation checks
prepatch Checks to execute before patching
security Security checks
siebel Siebel Checks
solaris_cluster Solaris Cluster Checks
storage Oracle Storage Server Checks
switch Infiniband switch checks
sysadmin Sysadmin checks
user_defined_checks Run user defined checks from user_defined_checks.xml
65

$ ./orachk -fileattr start
CRS stack is running and CRS_HOME is not set. Do you want to set CRS_HOME to
/u01/app/11.2.0.4/grid?[y/n][y]
Checking ssh user equivalency settings on all nodes in cluster
Node mysrv22 is configured for ssh user equivalency for oradb user
Node mysrv23 is configured for ssh user equivalency for oradb user
List of directories(recursive) for checking file attributes:
/u01/app/oradb/product/11.2.0/dbhome_11203
/u01/app/oradb/product/11.2.0/dbhome_11204
orachk has taken snapshot of file attributes for above directories at:
/orahome/oradb/orachk/orachk_mysrv21_20170504_041214
• Track changes to the attributes of important files with –fileattr
– Looks at all files & directories within Grid Infrastructure and Database homes by default
– The list of monitored directories and their contents can be configured to your specific requirements
– Use –fileattr start to start the first snapshot
66
Keep Track of Changes to the Attributes of Important Files
./orachk –fileattr start

Note:
• Use the same arguments with check that you used with start
• Will proceed to perform standard health checks after attribute checking
• File Attribute Changes will also show in HTML report output
$ ./orachk -fileattr check -includedir "/root/myapp/config" -excludediscovery
CRS stack is running and CRS_HOME is not set. Do you want to set CRS_HOME to
/u01/app/12.2.0/grid?[y/n][y]
Checking for prompts on myserver18 for oragrid user...
Checking ssh user equivalency settings on all nodes in cluster
Node myserver17 is configured for ssh user equivalency for root user
List of directories(recursive) for checking file attributes:
/root/myapp/config
Checking file attribute changes...
.
"/root/myapp/config/myappconfig.xml" is different:
Baseline : 0644 oracle root /root/myapp/config/myappconfig.xml
Current : 0644 root root /root/myapp/config/myappconfig.xml
…etc
…etc
• Compare current attributes against first snapshot using –fileattr check
67
Keep Track of Changes to the Attributes of Important Files
./orachk –fileattr check
• Results of snapshot comparison will also
be shown in the HTML report output

• Many new checks focus on known issues in 12c
Optimizer as well as SQL Plan Management
• These checks target problems such as:
– Wrong results returned
– High memory & CPU usage
– Errors such as ORA-00600 or ORA-07445
– Issues with cursor usage
– Other general SQL plan management problems
All contained in the dba profile:
Improve performance of SQL queries
-profile dba

• DBSAT analyzes
database
configurations and
security policies
• Uncovers security
risks
• Improves the security
posture of Oracle
Databases
Oracle Database Security Assessment Tool (DBSAT) included
All results included within report output under the check:
Validate database security configuration using database security assessment tool

• New checks to help when upgrading the database
to 12.2
• Both pre and post upgrade verification to prevent
problems related to:
• OS configuration
• Grid Infrastructure & Database patch prerequisites
• Database configuration
• Cluster configuration
Upgrade to Database 12.2 with confidence
-u –o pre
-u –o post
Pre upgrade
Post upgrade

Oracle Health Checks Collection Manager
• New Collection Manager
app built on APEX 5
theme
• Tabs replaced with drop
down menus for easier
navigation
• ORAchk & EXAchk
continue to ship with
APEX 4 app too
• No more new
functionality in the APEX
4 app, all new features
will go into the APEX 5
app

Enterprise Manager Integration
•Check results integrated into EM
compliance framework via plugin
•View results in native EM
compliance dashboards
•Related checks grouped into
compliance standards
72
•View targets checked, violations &
average score
•Drill down into compliance standard
to see individual check results
•View break down by target

• Use Enterprise Manager provisioning
feature and select ORAchk/EXAchk
• After selected this will launch the
provisioning wizard, choose the system
type
73
Provision

Drill into applicable standard and view
individual checks & target status
74
View Results by Compliance Standard
Filter by Exachk%”
Click individual checks for
recommendation details

• The JSON provides many tags to
allow dashboard filtering based on
facts such as:
• Engineered System type
• Engineered System version
• Hardware type
• Node name
• OS version
• Rack identifier
• Rack type
• Database version
• And more...
• Kibana can be used to view health
check compliance across your data
center
• Results can also be filtered based
on any combination of exposed
system attributes
75
JSON Output to Integrate with Kibana, Elastic Search etc

JSON Output to Integrate with Kibana, Elastic Search etc
76

Speeds Issue Diagnosis,
Triage and Resolution
77
Oracle 12c Trace File Analyzer
Confidential – Oracle Internal

Why TFA?
Provides one interface for
all diagnostic needs
Collects data across the
cluster and consolidates it
in one place
Collects all relevant
diagnostic data at the time
of the problem
Reduces time required to
obtain diagnostic data,
which saves your business
money
78Confidential – Oracle Internal

• All major Operating Systems are
supported
– Linux (OEL, RedHat, SUSE, Itanium &
zLinux)
– Oracle Solaris (SPARC & x86-64)
– AIX
– HPUX (Itanium & PA-RISC)
– Windows
• All Oracle Database & Grid versions
10.2+ are supported
• You probably already have TFA
installed as it is included with:
• Updated quarterly via 1513912.1
79
Supported Platforms and Versions
Oracle Grid
Infrastructure
Oracle Database
11.2.0.4+
12.2.0.1+12.1.0.2+
12.2.0.1+
OS versions supported are the same as those supported by the Database
Java Runtime Edition 1.8 required

Root / Daemon Install
1. Download from 1513912.1
2. Copy to one required machine and unzip
3. Run
Will :
– Install on all nodes
– Auto discover relevant Oracle Software & Exadata
Storage Servers
– Start monitoring for problems & perform auto
collections
Non root / Non Daemon Install
1. Download from 1513912.1
2. Copy to every required machine and unzip
3. Run
Will:
– Only install on current host
– Not do automatic collections
– Not collect from remote hosts
– Not collect files unreadable by install user
80
Linux / Unix Installation
./installTFA<platform>
Recommended install location: /opt/oracle.tfa
./installTFA<platform>
-extractto <install_dir>
-javahome <jre_home>

TFA
Daemon
Remote
Node
n
TFA
Daemon
tfactl
Initiator Node
( Where command originated)
Cluster
• TFA daemon runs on each cluster
node
• Or single instance when no
Grid Infrastructure is used
• Command line communication is
via tfactl command
• TFA Daemons on all nodes
coordinate:
• Script execution
• Collection of diagnostics
• Trimming of log contents
• Cluster wide collection output is
consolidated on one node
Architecture
Cluster
wide
Collection
Alerts &
Log files
Scripts
TFA
Daemon
Remote
Node
2
Scripts
TFA
Daemon
Remote
Node
1
Alerts &
Log filesScripts
Scripts
The daemon is only used when installed as root

Automatic Diagnostic Collections
82
Automatically
detect event
Collect & package
relevant
diagnostics
Notify
relevant DBA and
or Sys Admin by
email
Upload collection
to Oracle Support
for further help
Significant
problem occurs
1
2
3
4
Oracle Trace File Analyzer
DBA(s) / Sys Admin(s)
Oracle Grid Infrastructure
& Database(s)

• Specify all command options at
the command line
1. Set and change context
2. Run commands from within
the shell
83
1. Select menu navigation
options then choose the
command you want to run
Command Interfaces
Command line Shell Menu
tfactl <command>
tfactl
tfaclt > database MyDB
MyDB tfactl > oratop
tfactl menu

• Option 1
– Applying standard PSUs will
automatically update TFA
– PSUs do not contain Support Tools
Bundle updates
• Option 2
– To update with latest TFA & Support
Tools Bundle
1. Download latest version: 1513912.1
2. Repeat the same installation steps
84
Maintain
Upgrade to the latest version whenever possible to include bug fixes, new features & optimizations

View System & Cluster Summary
85
Quick summary of status of
key components
Choose an option to drill
down further

Summary ASM Drill Down Example
86
Problems found
ASM Cluster wide status
ASM Overview
ASM cluster wide summary
Problems found on myserver69
Also disk space warning on both servers

Summary ASM Drill Down Example
87
View recent problems detected
View component status
View node wise & drill into
myserver69
View ASM status summary
for myserver69
View ASM problems for myserver69

• Analyze all important recent log entries: • Search recent log entries:
88
Investigate Logs & Look for Errors
tfactl analyze –last 1d tfactl analyze -search “ora-00600" -last 8h
Searching for
“ora-00600”

Perform Analysis Using the Included Tools
Not all tools are included in Grid or Database install.
Download from 1513912.1 to get full collection of tools
Tool Description
orachk or
exachk
Provides health checks for the Oracle stack.
Oracle Trace File Analyzer will install either
• Oracle EXAchk for Engineered Systems, see document 1070954.1 for
more details
or
• Oracle ORAchk for all non-Engineered Systems, see document
1268927.2 for more details
oswatcher Collects and archives OS metrics. These are useful for instance or node
evictions & performance Issues. See document 301137.1 for more details
procwatcher Automates & captures database performance diagnostics and session level
hang information. See document 459694.1 for more details
oratop Provides near real-time database monitoring. See document 1500864.1
for more details.
sqlt Captures SQL trace data useful for tuning. See document 215187.1 for
more details.
alertsummary Provides summary of events for one or more database or ASM alert files
from all nodes
ls Lists all files TFA knows about for a given file name pattern across all nodes
pstack Generate process stack for specified processes across all nodes
Tool Description
grep Search alert or trace files with a given database and file name pattern, for
a search string.
summary Provides high level summary of the configuration
vi Opens alert or trace files for viewing a given database and file name
pattern in the vi editor
tail Runs a tail on an alert or trace files for a given database and file name
pattern
param Shows all database and OS parameters that match a specified pattern
dbglevel Sets and unsets multiple CRS trace levels with one command
history Shows the shell history for the tfactl shell
changes Reports changes in the system setup over a given time period. This
includes database parameters, OS parameters and patches applied
calog Reports major events from the Cluster Event log
events Reports warnings and errors seen in the logs
managelogs Shows disk space usage and purges ADR log and trace files
ps Finds processes
triage Summarize oswatcher/exawatcher data
89
Verify which tools you have installed: tfactl toolstatus

OS Watcher (Support Tools Bundle)
Collect & Archive OS Metrics
• Executes standard UNIX utilities (e.g. vmstat, iostat, ps,
etc) on regular intervals
• Built in Analyzer functionality to summarize, graph and
report upon collected metrics
• Output is Required for node reboot and performance
issues
• Simple to install, extremely lightweight
• Runs on ALL platforms (Except Windows)
• MOS Note: 301137.1 – OS Watcher Users Guide

Procwatcher (Support Tools Bundle)
Monitor & Examine Database Processes
• Single instance & RAC
• Generates session wait, lock and latch reports as well as call stacks
from any problem process(s)
• Ability to collect stack traces of specific processes using Oracle Tools
and OS Debuggers
• Typically reduces SR resolution for performance related issues
• Runs on ALL major UNIX Platforms
• MOS Note: 459694.1 – Procwatcher Install Guide

oratop (Support Tools Bundle)
Near Real-Time Database Monitoring
• Single instance & RAC
• Monitoring current database activities
• Database performance
• Identifying contentions and bottleneck

Analyze
• Each tool can be run using tfactl in shell mode
• Start tfactl shell with
• Run a tool with the tool name
1. Where necessary set context with database <dbname>
2. Then run tool
3. Clear context with database
93
tfactl
tfactl > database MyDB
MyDB tfactl > database
tfactl > orachk
MyDB tfactl > oratop

• For certain types of problems
Oracle Support will ask you to
run a Service Request Data
Collection (SRDC)
• Previously this would have
involved:
• Reading many different
support documents
• Collecting output from
many different tasks
• Gathering lots of different
diagnostics
• Packaging & uploading
• Now just run:
One Command SRDCs
tfactl diagcollect -srdc <srdc_type>
94

Faster & Easier SR Data Collection
Type of Problem SRDC Types Collection Scope
ORA Errors
• ORA-00600
• ORA-00700
• ORA-04030
• ORA-04031
• ORA-07445
• ORA-27300
• ORA-27301
• ORA-27302
Local only
Other internal database errors • internalerror Local only
Database performance problems • dbperf Cluster wide
Database patching problems
• dbpatchinstall
• dbpatchconflict
Local only
Database install / upgrade problems
• dbinstall
• dbupgrade
Local only
Enterprise Manager tablespace usage metric problems • emtbsmetrics Local only (on EM Agent target)
Enterprise Manager general metrics page or threshold
problems - Run all three SRDCs
• emdebugon
• emdebugoff
Local only (on EM Agent target & OMS)
• emmetricalert Local only (on EM Agent target & Repository DB)
New
New
New
New
New
New
New
New
tfactl diagcollect –srdc <srdc_type>

ORA4031:
1. IPS Package
2. Patch Listing
3. AWR report
4. Memory information
5. RDA
Database Performance
1. ADDM report
2. AWR for good and problem period
3. AWR Compare Period report
4. ASH report for good and problem period
5. OS Watcher
6. IPS Package (if errors during problem
period)
7. ORAchk (performance related checks)
One Command SRDCs – Examples of What’s Collected
tfactl diagcollect –srdc ora4031 tfactl diagcollect –srdc dbperf
96

Manual Data Gathering vs One Command SRDC
Manual Data Gathering
1. Generate ADDM reviewing Document 1680075.1
2. Identify “good” and “problem” periods and gather AWR
reviewing Document 1903158.1
3. Generate AWR compare report (awrddrpt.sql) using “good”
and “problem” periods
4. Generate ASH report for “good” and “problem” periods
reviewing Document 1903145.1
5. Collect OSWatcher data reviewing Document 301137.1
6. Check alert.log if there are any errors during the “problem”
period
7. Find any trace files generated during the “problem” period
8. Collate and upload all the above files/outputs to SR
TFA SRDC
1. Run
2. Upload resulting zip file to SR
tfactl diagcollect –srdc dbperf
97

1. Enter default for event date/time and database name
2. Scans system to identify recent 10 events in the system (ORA600
example shown)
3. Once the relevant event is chosen, proceeds with diagnostic
collection
98
One Command SRDC
tfactl diagcollect –srdc <srdc_type>
4. All required files are
identified
5. Trimmed where
applicable
6. Package in a zip ready
to provide to support
Interactive Mode

One Command SRDC
99
tfactl diagcollect –srdc <srdc_type> -database <db> -for <time>
1. Parameters(date/time, DB name) are provided
in the command
2. Does not prompt for any more information
3. All required files are identified
4. Trimmed where applicable
5. Package in a zip ready to provide to support
Silent Mode

• Run a default diagnostic
collection if there is not
yet an SRDC about your
problem:
• Will trim & collect all
important log files
updated in the past 12
hours:
• Collections stored in the
repository directory
• Change diagcollect
timeframe with
–last <n>h|d
100
Default Collection
tfactl diagcollect

Automatic Database Log Purge
• TFA can automatically purge database logs
– OFF by default
– Except on a Domain Service Cluster (DSC),
which it is ON by default
• Turn auto purging on or off:
• Will remove logs older than 30 days
– configurable with:
• Purging runs every 60 minutes
– configurable with:
101
tfactl set manageLogsAutoPurge=<ON|OFF>
tfactl set manageLogsAutoPurgePolicyAge=<n><d|h>
tfactl set manageLogsAutoPurgeInterval=<minutes>

Manual Database Log Purge
• TFA can manage ADR log and trace files
– Show disk space usage of individual diagnostic destinations
– Purge these file types based on diagnostic location and or age:
• "ALERT“, "INCIDENT“, "TRACE“, "CDUMP“, "HM“, "UTSCDMP“, "LOG“
tfactl managelogs <options>
Runs as the ADR home
owner. So will only be able
to purge files this owner
has permission to delete
Option Description
–show usage Shows disk space usage per diagnostic directory for both GI and database logs
-show variation –older <n><m|h|d> Use to determine per directory disk space growth.
Shows the disk usage variation for the specified period per directory.
-purge –older <n><m|h|d> Remove all ADR files under the GI_BASE directory, which are older than the time specified
–gi Restrict command to only diagnostic files under the GI_BASE
–database [all | dbname] Restrict command to only diagnostic files under the database directory. Defaults to all,
alternatively specify a database name
-dryrun Use with –purge to estimate how many files will be affected and how much disk space will be
freed by a potential purge command.
May take a while for a
large number of files
102

tfactl managelogs –show usage tfactl managelogs –show variation –older <n><m|h|d>
Use -gi to only
show grid
infrastructure
Use –database to only
show database

tfactl managelogs –purge –older n<m|h|d> -dryrun tfactl managelogs –purge –older n<m|h|d>
Use –dryrun
for a “what if”

Disk Usage Snapshots
• TFA will track disk usage and record snapshots to:
– tfa/repository/suptools/<node>/managelogs/usage_snapshot/
• Snapshot happens every 60 minutes, configurable with:
• Disk usage monitoring is ON by default, configurable with:
105
tfactl set diskUsageMonInterval=<minutes>
tfactl set diskUsageMon=<ON|OFF>

• Trim & collect all important log files updated in
the past 12 hours:
• Collect a problem specific Service Request Data
Collection (SRDC):
106
Collect
tfactl diagcollect
• Collections stored in the repository directory
• Change diagcollect timeframe with –since <n>h|d
• For list of types of srdc collections use tfactl diagcollect -srdc help
tfactl diagcollect -srdc ora600

TFA dbglevel profiles
• Example
– tfactl dbglevel -set node_eviction
– would be used for enhancing diagnostics when node evictions are the being
investigated and would perform the following operation internally
• crsctl set log css "CSSD=4"
• crsctl set log css "CSSDNMC=4"
• crsctl set log css "CLSF=4"
• crsctl set log css "CSSDGMCC=4"
• crsctl set log css "CSSDGMPC=4"
• To revert to the original or default logging levels the following command
– $ tfactl dbglevel -unset node_eviction
• would perform the following operations internally
• crsctl set log css "CSSD=2"
• crsctl set log css "CSSDNMC=2"
• crsctl set log css "CLSF=0"
• crsctl set log css "CSSDGMCC=2"
• crsctl set log css "CSSDGMPC=2" Oracle Confidential – Internal/Restricted/Highly Restricted 107

• Use srdc <incident type>:
• To specify sid use –sid <oracle sid>
• To specify database use –db <dbname>
• To specify incident date & time use
–inc_date <YYYY-MM-DD> -inc_time <HH:MM:SS>
• To upload directly to the SR use –sr<SR#>
• For dbperf use these parameters to
specify the good & bad performance
periods to compare:
108
Incident Based Collections with SRDC
tfactl srdc ora4030
Incident Type Description
ora4030 For ORA-04030 errors
dbperf For basic db performance problems
tfactl srdc ora4030 -sid orcl –db RDBMS121
-inc_date 2016-06-15 -inc_time 02:48:23
-sr 3-123456789
Parameter Description
perf_base_sd Start date for a good performance period
perf_base_st Start time for a good performance period
perf_base_ed End date for a good performance period
perf_base_et End time for a good performance period
perf_comp_sd Start date for a bad performance period
perf_comp_st Start time for a bad performance period
perf_comp_ed End date for a bad performance period
perf_comp_et End time for a bad performance period
tfactl srdc dbperf –db RDBMS121
–perf_base_sd 2016-06-15 –perf_base_st 01:30:00
–perf_base_ed 2016-06-15 –perf_base_et 02:00:00
–perf_comp_sd 2016-06-16 –perf_comp_st 09:30:00
–perf_comp_ed 2016-06-16 –perf_comp_et 10:00:00
Oracle Confidential – Internal

Generates Diagnostic
Metrics View of Cluster
and Databases
109Confidential – Oracle Internal/Restricted/Highly Restricted
Oracle 12c Cluster Health Monitor

Generates Diagnostic Metrics View of Cluster and Databases
Cluster Health Monitor (CHM)
GIMR
ologgerd
(master)
osysmond
osysmond
osysmond
osysmond
12c Grid Infrastructure
Management Repository
• Always on - Enabled by default
• Provides Detailed OS Resource Metrics
• Assists Node eviction analysis
• Locally logs all process data
• User can define pinned processes
• Listens to CSS and GIPC events
• Categorizes processes by type
• Supports plug-in collectors (ex.
traceroute, netstat, ping, etc.)
• New CSV output for ease of analysis
OS Data OS Data
OS Data
OS Data
Confidential – Oracle Internal/Restricted/Highly RestrictedConfidential – Oracle Restricted

Oclumon CLI or Full Integration with EM Cloud Control

Discovers Potential Cluster
& DB Problems - Notifies
with Corrective Actions
112
Oracle 12c Cluster Health Advisor

Generates Diagnostic Metrics View of Cluster and Databases
GIMR
ologgerd
(master)
osysmond
osysmond
osysmond
osysmond
12c Grid Infrastructure
Management Repository
• Provides Detailed OS Resource Metrics
• Assists Node eviction analysis
• Locally logs all process data
• User can define pinned processes
• Listens to CSS and GIPC events
• Categorizes processes by type
• Supports plug-in collectors (ex.
traceroute, netstat, ping, etc.)
• New CSV output for ease of analysis
OS Data OS Data
OS Data
OS Data

Confidential – Oracle Restricted 115
CHA has detected a service degradation due to higher than expected I/O latencies.
Cluster Health Advisor
CHA/DB Health: I/O problem
CHA detected a for service degradation due to higher than expected I/O latencies.
CHA/DB Health
The degradation is caused by a higher than expected utilization of shared storage devices for this
database. No evidence of significant increase in I/O demand on the local node.
Problem
Confidence
Action
95.17%
Validate whether there is increase in I/O demand on other nodes than the local and find I/O intensive SQL .
Add more disks to disk group or move database to faster disks.
proddb_1
proddb_2

Copyright © 2017, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted 116
Cluster Health Advisor Daemon
Dependencies to the Grid Infrastructure
Management Repository (GIMR)

Command Line Tool - chactl

Will only monitor cluster
initially
Tell it to monitor the
database
chactl monitor database –db <db_name>

Cluster Health Advisor - diagnosis
Query the cluster diagnosis for
incidents and recommendations chactl query diagnosis –db <db_name>chactl query diagnosis
Query a specific database for
diagnosis
Query the repository footprint
chactl query repository

Autonomously Preserves
Database Availability and
Performance
120
Oracle 12c Database Hang Manager

Debugging Live Systems: Hangs
• Parsing the system state dump can be very time consuming.
To debug a hang more quickly you could query v$session.
blocking_session:
select sess.sid sid,substr(proc.program,0,25)
prog,substr(sw.event,0,15) event,sw.wait_time wt,
sess.blocking_session bsid from v$process proc, v$session sess,
v$session_wait sw where proc.addr=sess.paddr and
sess.status='ACTIVE‘ and sw.sid=sess.sid order by prog;
SID Program Event WT BSID
----- ------------------------- --------------- --- -----
2836 oracle@fstsun002 (S000) enq: TM - conte 0 2979
2979 oracle@fstsun002 (TNS V1- enq: TM - conte 0 2853

Debugging Live Systems: Hangs
• sqlplus –prelim “/ as sysdba” is useful because it avoids a
process state object creation which requires various
resources such as latches.
• Trying to acquire those resources may cause your debugger
session to hang.
• Some dumps/commands may require a PSO therefore you
can execute those dumps/commands in an existing process
that already has a PSO
$ sqlplus -prelim "/ as sysdba"
SQL> oradebug setorapid 9
SQL> oradebug dump systemstate 3

Oracle 12c Hang Manager
• Reliably detects database hangs and
deadlocks
• Autonomously resolves them
• Supports QoS Performance Classes, Ranks
and Policies to maintain SLAs
• Logs all detections and resolutions
• New SQL interface to configure sensitivity
(Normal/High) and trace file sizes
Autonomously Preserves Database Availability and Performance Session
DIA0
EVALUATE
DETECT
ANALYZE
Hung?
VERIFY
Victim
QoS
Policy

Full Resolution Dump Trace File and DB Alert Log Audit Reports
Oracle 12c Hang Manager
Dump file …/diag/rdbms/hm6/hm62/incident/incdir_5753/hm62_dia0_12656_i5753.trc
Oracle Database 12c Enterprise Edition Release 12.2.0.0.0 - 64bit Beta
With the Partitioning, Real Application Clusters, OLAP, Advanced Analytics
and Real Application Testing options
Build label: RDBMS_MAIN_LINUX.X64_151013
ORACLE_HOME: …/3775268204/oracle
System name: Linux
Node name: slc05kyr
Release: 2.6.39-400.211.1.el6uek.x86_64
Version: #1 SMP Fri Nov 15 13:39:16 PST 2013
Machine: x86_64
VM name: Xen Version: 3.4 (PVM)
Instance name: hm62
Redo thread mounted by this instance: 2
Oracle process number: 19
Unix process pid: 12656, image: oracle@slc05kyr (DIA0)
*** 2015-10-13T16:47:59.541509+17:00
*** SESSION ID:(96.41299) 2015-10-13T16:47:59.541519+17:00
*** CLIENT ID:() 2015-10-13T16:47:59.541529+17:00
*** SERVICE NAME:(SYS$BACKGROUND) 2015-10-13T16:47:59.541538+17:00
*** MODULE NAME:() 2015-10-13T16:47:59.541547+17:00
*** ACTION NAME:() 2015-10-13T16:47:59.541556+17:00
*** CLIENT DRIVER:() 2015-10-13T16:47:59.541565+17:00
2015-10-13T16:47:59.435039+17:00
Errors in file /oracle/log/diag/rdbms/hm6/hm6/trace/hm6_dia0_12433.trc (incident=7353):
ORA-32701: Possible hangs up to hang ID=1 detected
Incident details in: …/diag/rdbms/hm6/hm6/incident/incdir_7353/hm6_dia0_12433_i7353.trc
2015-10-13T16:47:59.506775+17:00
DIA0 requesting termination of session sid:40 with serial # 43179 (ospid:13031) on instance 2
due to a GLOBAL, HIGH confidence hang with ID=1.
Hang Resolution Reason: Automatic hang resolution was performed to free a
significant number of affected sessions.
DIA0: Examine the alert log on instance 2 for session termination status of hang with ID=1.
In the alert log on the instance local to the session (instance 2 in this case),
we see the following:
2015-10-13T16:47:59.538673+17:00
Errors in file …/diag/rdbms/hm6/hm62/trace/hm62_dia0_12656.trc (incident=5753):
ORA-32701: Possible hangs up to hang ID=1 detected
Incident details in: …/diag/rdbms/hm6/hm62/incident/incdir_5753/hm62_dia0_12656_i5753.trc
2015-10-13T16:48:04.222661+17:00
DIA0 terminating blocker (ospid: 13031 sid: 40 ser#: 43179) of hang with ID = 1
requested by master DIA0 process on instance 1
Hang Resolution Reason: Automatic hang resolution was performed to free a
significant number of affected sessions.
by terminating session sid:40 with serial # 43179 (ospid:13031)

Deploys with Minimum
Footprint and Maximum
Manageability
125Confidential – Oracle Restricted
Oracle Domain Services Cluster (DSC)

Oracle 12c Domain Services Cluster (DSC)
126
• Hosts Framework as Services
• Reduces local resource footprint
• Centralizes management
• Speeds deployment and patching
• Optional Shared Storage
• Supports multiple versions and
platforms going forward
Deploys with Minimum Footprint and Maximum Manageability
Application
Member
Cluster
Database
Member
Cluster
Database
Member
Cluster
Oracle Domain Services Cluster
Database
Member
Cluster
Application
Member
Cluster
Database
Member
Cluster
ORACLE CLUSTER DOMAIN
Management Repository Service
Trace File Analyzer Receiver
ORAchk Collection Service
Grid Names Service
Storage Services
Rapid Home Provisioning Service

Oracle Cluster Domain
IO Service
ACFS
Services
ASM
Service
Database
Member Cluster
Uses ASM
Service
Database
Member Cluster
Uses IO & ASM
Service of DSC
Trace File
Analyzer
(TFA)
Service
Mgmt
Repository
(GIMR)
Service
Application
Member Cluster
GI only
Database
Member Cluster
Uses local ASM
Shared ASM
Additional
Optional
Services
Rapid Home
Provisioning
(RHP)
Service
Private
Network
SAN
NAS

Oracle 12c Domain Services Cluster (DSC)
128
• Hosts Framework as Services
• Reduces local resource footprint
• Centralizes management
• Speeds deployment and patching
• Optional Shared Storage
• Supports multiple versions and
platforms going forward
Deploys with Minimum Footprint and Maximum Manageability
Application
Member
Cluster
Database
Member
Cluster
Database
Member
Cluster
Database
Member
Cluster
Application
Member
Cluster
Database
Member
Cluster
ORACLE CLUSTER DOMAIN
Management Repository Service
Trace File Analyzer Receiver
ORAchk Collection Service
Grid Names Service
Storage Services
Rapid Home Provisioning Service

Compare Database Status Before & After Upgrade
• Download dbupgdiag.sql from doc 556610.1
• Run both before and after the upgrade:
Confidential – Oracle Internal/Restricted/Highly Restricted 129
cd <location of the script>
$ sqlplus / as sysdba
sql> alter session set
nls_language='American';
sql> @dbupgdiag.sql
sql> exit

AIOUG : OTNYathra - Troubleshooting and Diagnosing Oracle Database 12.2 and Oracle RAC

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Similar to AIOUG : OTNYathra - Troubleshooting and Diagnosing Oracle Database 12.2 and Oracle RAC

Similar to AIOUG : OTNYathra - Troubleshooting and Diagnosing Oracle Database 12.2 and Oracle RAC (20)

More from Sandesh Rao

More from Sandesh Rao (20)

Recently uploaded

Recently uploaded (20)

AIOUG : OTNYathra - Troubleshooting and Diagnosing Oracle Database 12.2 and Oracle RAC
