![class BoundedBuffer {
synchronized void put(Object x) throws InterruptedException {
while( occupied == buffer.length )
wait();
notify();
++occupied;
putAt %= buffer.length;
buffer[putAt++] = x;
}
synchronized Object take() throws InterruptedException {
while( occupied == 0 )
wait();
notify();
--occupied;
takeAt %= buffer.length;
return buffer[takeAt++];
}
private Object[] buffer = new Object[4];
private int putAt, takeAt, occupied;
}
-- Tom Cargill
wiki.c2.com XP Challenge 14](https://image.slidesharecdn.com/agentthreadingmodel-180817094935/85/Agent-threading-model-3-320.jpg)
Agent threading model
- 1. Threading Models and theAgent Abstraction Judd Gaddie @juddgaddie
- 2. Shared Memory ConcurrencyModel x? x=x*2 x=x*3 x=x*4 x=x*5 x=x*6 x=x*7 x=x*8 x=x*9 x=x*10 What are all the possible values of X ? private int x = 1
- 3. class BoundedBuffer { synchronizedvoid put(Object x) throws InterruptedException { while( occupied == buffer.length ) wait(); notify(); ++occupied; putAt %= buffer.length; buffer[putAt++] = x; } synchronized Object take() throws InterruptedException { while( occupied == 0 ) wait(); notify(); --occupied; takeAt %= buffer.length; return buffer[takeAt++]; } private Object[] buffer = new Object[4]; private int putAt, takeAt, occupied; } -- Tom Cargill wiki.c2.com XP Challenge 14
- 4.
- 5. “..developing, testing anddebugging multithreaded programs can be extremely difficult because concurrency bugs do not manifest themselves predictably. And when they do surface, it is often at the worst possible time in production, under heavy load.” Brian Goetz - Java Concurrency in Practice
- 6.
- 7.
- 10. 3 Agents -Single Core Core 1 Time Agent1 1 Agent2 1 Agent3 1 Agent1 2 Agrona Basic Agent Framework https://github.com/real-logic/agrona
- 11. Pay by thecore
- 13. Pipelining - Agentper Core Time Core 2 Core 3 Core 1 Agent1 1 Agent1 2 Agent1 3 Agent1 4 Agent2 1 Agent2 2 Agent2 3 Agent3 1 Agent3 2
- 14. ● No blockingcalls in an Agent ● Agents must not hold on to execution cycle for too long ● Requires consistent small tasks (streaming) or a way to slice up large tasks Limitations
- 15. Agent Agent Agent Agent SlowAux Service High Level Architecture
- 16. ● Deterministic execution ●Easy reasoning ● Improved Testability ● 1 thread per core ● No kernel thread context switching ● Improved cache locality Benefits
- 17. Thank you! Questions? We’re Hiring!transficc.com/careers
