This document presents two methods for solving the flight-to-gate assignment problem at airports with the goal of minimizing passenger walking distances. The first method is a heuristic algorithm called "Crowdest-Come-Best-Serve" which assigns the gate with the shortest average walking distance to the flight with the most passengers. The second method formulates the problem as a linear program to find an optimal solution. Both methods are tested on flight data from Toronto airport. The linear program achieves a 32% reduction in walking distance compared to the original assignment, while the heuristic achieves a 27% reduction but has much lower computational costs.
