The document provides specifications for 92mm multipoint door lock handle sets made of 304 stainless steel or 316 stainless steel. It includes the part numbers, descriptions, finishes, dimensions, and features of the 92mm multipoint handles. The handles are designed for use on doors up to 80mm thick, have full-length spindles for strength, spring-loaded cassettes to maintain horizontal position, and bolt-through fixings. The 316 stainless steel handles are suitable for corrosive marine environments.

1. 92mm Multipoint Handle
Code Description Finish
Part No Description Finish
JR090-SSS 92mm Multipoint Lock Handle Set - 304 Stainless Steel SsS
JR090-PB 92mm Multipoint Lock Handle Set - 304 Stainless Steel pb
JR090-CP 92mm Multipoint Lock Handle Set - 304 Stainless Steel cp
92mm Multipoint Handle
Code Description Finish
DRAWN BY:-________________
CHECKED BY:-______________
APPROVED BY :-____________
DATE:- , REV.NO.:-
18-03-2013 00
ALL DIMENSIONS ARE IN MM.
Leading Edge in Joinery Hardware
First choice
for corrosive
environments
Multipoint Door lOCK handleS
Part No Description Finish
KM070-316-SSS Multipoint Handle Set - 316 Stainless Steel SsS
range
216
216
10
10
92
245.8
30
92
245.8
• To suit up to 80mm doors
• Full length spindle to give full lever strength
• Sag resistant spring cassette to maintain
horizontal rest position
• 304 Stainless Steel Base material
• Bolt through fixings
• Grub screw free
• 1600 hours salt spray tested
• PB & CP Finish are PVD coated
• 245 x 30 x 12mm Backplate
Spring Cassette x2
• Includes Sprung
Cassette
• To suit up to 80mm doors
• Full length spindle to give full lever strength
• Bolt through fixings made of 316 Satin Stainless Steel
• Matching Lever on backplate and rose available, See Page 67.
• Fully 316 marine grade Stainless Steel
• 249 x 28 x 10mm Backplate
97
multipoint Door handles
ALL DIMENSIONS ARE APPROX.
PRODUCT :-
OUTER RECTANGLE PLATE
PROJECT :- COSTAL GROUP
28
CODE :- RC3N1MH1921S
249
129
- Corrosion Resistant High Grade AISI 316 Stainless Steel Architectural Products.
