1. MULTiPOINT dOOR LOCKs (ENTRANCE Solutions)
ML120 Auto Door Lock ML80 Heritage Door Lock
• Standard Key Height Position • 2/3 Key Height Position
Coming Soon
Back to back
stainless steel
cylinder pull
45
BS+18
45
BS
BS+18
BS+18
BS+18
45
BS+18
45
Product Code Product Code
Multipoint Lock ML120-LH
Multipoint Lock ML120-RH
• 45mm Backset
• 63mm Overall Lockcase
• 92mm euro profile centre
Leading Edge in Joinery Hardware
Product Code
Multipoint Lock ML80-LH-45
Multipoint Lock ML80-RH-45
Product Code
An external lever handle is not
required to operate the locking
points and the lock can be
deadlocked or opened externally
by turning the key a quarter of a
turn. From the inside the door can
be opened by an internal thumb
turn, again with a quarter turn.
The door is automatically locked
when closed
from the inside and the key is then
required to gain entry from the
outside.
The Heritage Locking system is
an ideal solution for not only
replacement period doors but for
prestige new build doors also.
See Page 95 for keep options.
