The return of the hierarchical model

  1. 1. The Return of the Hierarchical Model Jukka Zitting @ Day Software
  2. 2. /Agenda <ul><li>Part 1: Hierarchy </li></ul><ul><li>Concepts - </li></ul><ul><li>Benefits - </li></ul><ul><li>Drawbacks – </li></ul><ul><li>Examples - </li></ul>Part 2: Case Study - JCR - Jackrabbit - Sling - Lessons Learned questions and comments allowed
  3. 3. /Hierarchy/Concepts <ul><li>Every record has a parent record </li></ul><ul><ul><li>Except the root </li></ul></ul><ul><ul><li>No cyclical parent relations allowed </li></ul></ul><ul><ul><li>Referential integrity, but often no other reference types supported </li></ul></ul><ul><li>A name identifies a record within its parent </li></ul><ul><ul><li>The name is not necessarily unique (XML, DNS, etc.) </li></ul></ul><ul><ul><li>Path as an identifier: /path/to/record </li></ul></ul><ul><li>Record hierarchy is distinct from type hierarchy </li></ul><ul><ul><li>Structural flexibility, optionally limited by type constraints </li></ul></ul>A B C D E F
  4. 4. /Hierarchy/Benefits <ul><li>Natural </li></ul><ul><ul><li>Data in many domains is inherently hierarchical </li></ul></ul><ul><ul><li>Easy to understand </li></ul></ul><ul><li>Self-similar </li></ul><ul><ul><li>Recursive algorithms </li></ul></ul><ul><ul><li>Incremental map-reduce! </li></ul></ul><ul><li>Scalable </li></ul><ul><ul><li>Partitioning </li></ul></ul><ul><ul><li>Parallel processing </li></ul></ul><ul><li>Efficient </li></ul><ul><ul><li>Highly optimized path-based access and “joins” on the parent-child and subtree relationships </li></ul></ul>
  5. 5. /Hierarchy/Drawbacks <ul><li>Limited support for references </li></ul><ul><ul><li>Graph databases solve this problem, at a cost </li></ul></ul><ul><ul><li>DAG a partial solution </li></ul></ul><ul><li>Handling of flat structures </li></ul><ul><ul><li>Chronological: blogs, tweets, email, log entries, etc. </li></ul></ul><ul><ul><li>Sets: wiki pages, user accounts, etc. </li></ul></ul><ul><ul><li>Often requires an artificial hierarchy, e.g. /blog/2010/06/entry-for-today </li></ul></ul><ul><li>Standards are domain-specific or limited in scope </li></ul><ul><ul><li>POSIX, DNS, XPath/XQuery, JCR, etc. </li></ul></ul><ul><li>Difficulty of organizing things </li></ul><ul><ul><li>Coming up with good names for records is hard </li></ul></ul><ul><ul><li>Hierarchy requires maintenance </li></ul></ul>
  6. 6. /Hierarchy/Examples <ul><li>File system </li></ul><ul><li>DNS </li></ul><ul><li>LDAP </li></ul><ul><li>XML </li></ul><ul><li>WebDAV </li></ul><ul><li>RDBMS </li></ul>
  7. 7. /Hierarchy/Examples/File System <ul><li>Universally available </li></ul><ul><li>Two main types: files and folders </li></ul><ul><ul><li>Notable extensions: /dev/* and /proc/* </li></ul></ul><ul><ul><li>Unix philosophy: Everything is a file! </li></ul></ul><ul><li>Heavily optimized for specific use cases </li></ul><ul><li>Limited support for fine-grained data </li></ul><ul><ul><li>Some systems support things like extended attributes </li></ul></ul><ul><li>Built-in access controls, but usually no query support </li></ul><ul><li>Major limitations in distributed solutions </li></ul><ul><ul><li>SAN and NAS solutions reasonably efficient but limited in scope </li></ul></ul><ul><ul><li>Truly distributed systems like HDFS applicable only for limited use cases </li></ul></ul>
  8. 8. /Hierarchy/Examples/DNS <ul><li>Globally distributed, heterogenous, eventually consistent </li></ul><ul><ul><li>In production since 1983! </li></ul></ul><ul><li>Standardized query and update protocols </li></ul><ul><li>Domain-specific, highly optimized for scalability </li></ul><ul><li>Multiple records can have the same name </li></ul><ul><li>Fine-grained record types: A, NS, MX, TXT, AAAA, etc. </li></ul><ul><li>Security issues, both in design and implementations </li></ul><ul><ul><li>Not much impact in practice </li></ul></ul>
  9. 9. /Hierarchy/Examples/LDAP <ul><li>Protocol for accessing X.500-style directories </li></ul><ul><li>Record names are constructed from selected properties </li></ul><ul><ul><li>dn: cn=John Doe, dc=example, dc=com </li></ul></ul><ul><li>Record types defined by extensible schemas </li></ul><ul><li>Limited form of record references </li></ul><ul><li>Fairly powerful search </li></ul><ul><ul><li>Though no aggregate queries or arbitrary joins </li></ul></ul><ul><li>Optimized for fine-grained data that is mostly read </li></ul><ul><li>Replication and distributed use widely supported </li></ul>
  10. 10. /Hierarchy/Examples/XML <ul><li>Data storage based on the XML DOM </li></ul><ul><ul><li>Various levels of conformance </li></ul></ul><ul><li>Highly buzzword compliant in the early 2000’s </li></ul><ul><ul><li>Few of the XML database products are still in active use </li></ul></ul><ul><li>Inefficient handling of binary data (at all granularities) </li></ul><ul><li>Powerful query and transformation tooling </li></ul><ul><ul><li>XPath, XQuery, XSLT, etc. </li></ul></ul><ul><ul><li>Many implementations not optimized for performance </li></ul></ul><ul><li>Optional type constraints with XML Schema, etc. </li></ul><ul><li>The result? XML extensions in SQL </li></ul>
  11. 11. /Hierarchy/Examples/WebDAV <ul><li>Extends HTTP with concepts of collections and properties </li></ul><ul><ul><li>Also: locking, versioning, search, etc. </li></ul></ul><ul><li>Often used (only) for HTTP-based access to a file system </li></ul><ul><ul><li>Also leveraged by fs-like systems like Subversion </li></ul></ul><ul><li>Limited XML-based query with PROPFIND </li></ul><ul><ul><li>More query power with DASL </li></ul></ul><ul><li>Somewhat heavy-weight for fine-grained access </li></ul><ul><li>Fragmented and often incompatible implementations </li></ul><ul><ul><li>File system backend as the lowest common denominator </li></ul></ul><ul><ul><li>cf. AtomPub </li></ul></ul>
  12. 12. /Hierarchy/Examples/RDBMS <ul><li>Various ways of representing hierarchies in RDBM systems </li></ul><ul><ul><li>Adjacency model: Each row has a reference to the parent </li></ul></ul><ul><ul><li>Nested sets: Rows numbered in depth-first traversal order </li></ul></ul><ul><ul><li>etc. </li></ul></ul><ul><li>Little structural flexibility </li></ul><ul><li>Expensive parent-child or subtree joins </li></ul><ul><ul><li>Vendor-specific extensions to address this problem </li></ul></ul><ul><li>Two words: Impedance mismatch </li></ul>
  13. 13. /Hierarchy/Summary <ul><li>Data storage/management using an explicit tree hierarchy </li></ul><ul><li>Natural mapping, nice non-functional characteristics </li></ul><ul><li>Limited functionality, lack of generic standards </li></ul><ul><li>Widely used, but in domain-specific ways </li></ul><ul><ul><li>Extremely efficient/scalable for certain data models </li></ul></ul><ul><li>How about a generic, feature-rich hierarchical database? </li></ul>
  14. 14. /Case/JCR <ul><li>Content Repository for Java Technology API (JCR) </li></ul><ul><ul><li>JCR 1.0 out in 2005, specified in JSR 170 </li></ul></ul><ul><ul><li>JCR 2.0 out in 2009, specified in JSR 283 </li></ul></ul><ul><ul><li>Work on JCR 2.1 starting </li></ul></ul><ul><li>A content repository is a hierarchical content store </li></ul><ul><ul><li>with full text search, observation, versioning, transactions, etc. </li></ul></ul><ul><ul><li>JCR 2.0 adds retention, type management, join queries, etc. </li></ul></ul><ul><li>Designed for both structured and unstructured content </li></ul><ul><ul><li>handling of both finely and coarsely grained data </li></ul></ul><ul><li>Application platform more than an integration API </li></ul>
  15. 15. /Case/Jackrabbit <ul><li>Reference implementation of both JCR 1.0 and 2.0 </li></ul><ul><ul><li>Primary focus on feature-completeness </li></ul></ul><ul><li>Apache incubator since 2004, TLP since 2006 </li></ul><ul><li>Internal storage through an abstracted key-value API </li></ul><ul><ul><li>Tree model implemented on top of that </li></ul></ul><ul><ul><li>Lucene search index maintained separately </li></ul></ul><ul><ul><li>Separate journal for cluster deployments </li></ul></ul><ul><li>Advanced WebDAV support </li></ul><ul><li>Jackrabbit 3: Focus on scalability, modularity </li></ul>
  16. 16. /Case/Sling <ul><li>Web framework based on the JCR content model </li></ul><ul><li>Apache incubator since 2007, TLP since 2009 </li></ul><ul><li>Intuitive URL mapping </li></ul><ul><ul><li>Path selects the underlying content resource </li></ul></ul><ul><ul><li>Optional selectors and extensions determine representation </li></ul></ul><ul><li>JSON and POST servlets with Javascript support </li></ul><ul><li>OSGi for server-side modularity </li></ul><ul><li>Everything is content </li></ul>
  17. 17. /Case/Lessons Learned <ul><li>Content-driven development </li></ul><ul><ul><li>Data first, structure later </li></ul></ul><ul><li>Distribute for redundancy </li></ul><ul><ul><li>Modern hardware goes a long way for scalability/performance </li></ul></ul><ul><ul><li>For small/medium deployments, distribution is more important for fault-tolerance especially in cloud environments </li></ul></ul><ul><li>Relationships are important </li></ul><ul><ul><li>JCR 2.0 is a DAG, plus references for expressing full graphs </li></ul></ul><ul><ul><li>Referential integrity not so important </li></ul></ul><ul><li>Notable data sets are flat </li></ul><ul><li>Don’t forget tool support for ad-hoc tasks! </li></ul>
  18. 18. /Questions? <ul><li>http://jackrabbit.apache.org/ </li></ul><ul><li>http://sling.apache.org/ </li></ul><ul><li>http://www.day.com/jsr283 </li></ul>

×
