UPSEE–PAST PAPERSPHYSICS - UNSOLVED PAPER - 2006
SECTION   Single Correct Answer Type         There are five parts in this question. Four choices are given for each part...
01   Problem     Which of the following is true for rays coming from infinity ?     a. Two images are formed     b. Contin...
02   Problem     What is dimensional formula of thermal conductivity ?     a. [MLT-1 - 1]     b. [MLT-3  -1]     c. [M2L...
03   Problem     A block C of mass m is moving with velocity v0 and collides elastically with block A     of mass m and co...
04   Problem     A bullet of mass 20 g and moving with 600 m/s collides with a block of mass 4     kg hanging with the str...
05   Problem     What is moment of inertia in terms of angular momentum(L) and kinetic     energy (K) ?     a.   L2       ...
06   Problem     A disc of mass 2 kg and radius 0.3 is rotating with angular velocity 30 rad/s. What     is angular veloci...
07   Problem     If a body is raised from the surface of the earth upto height R, what is the     change in potential ener...
08   Problem     A piston of cross-section area A is fitted in cylinder in which gas of volume     V at pressure P is encl...
09   Problem     Carbon, silicon and germanium atoms have four valence electrons each.     Their valence and conduction ba...
10   Problem     A piston fitted in cylindrical pipe is pulled as shown in the figure. A tuning fork is     sounded at ope...
11   Problem     A man is standing on the platform and one train is approaching and another     train is gong away with sp...
12   Problem     A capacitor having capacitance 1 µF with air is filled with two dielectrics as     shown. How many times ...
13   Problem     Permanent magnet his properties retentivity and coercivity respectively :     a. High-high     b. Low-low...
14   Problem     Hydrogen bomb is based upon     a. Fission     b. Fusion     c. Chemical reaction     d. Transmutation
15   Problem     Six moles of O2 gas is heated from 200C to 350C at constant volume. If specific     heat capacity at cons...
16   Problem     In Carnot engine efficiency is 40% at hot reservoir temperature T. For efficiency     50% what will be te...
17   Problem     A ball of mass 2 kg moving with velocity 3 m/s, collides with spring of natural     length 2 m and force ...
18   Problem     A proton moving horizontally downward enters in a magnetic field pointing     towards north. In which dir...
19   Problem     Induced emf in the coil depends upon :     a. Conductivity of coil     b. Amount of flux     c. Rate of c...
20   Problem     With in depletion regions of p-n junction diode :     a. p-side is positive and n-side is negative     b....
21   Problem     27 small drops each having charge q and radius r coalesce to from big drop, how     many times charge and...
22   Problem     X-rays are used in determining the molecular structure of crystalline because     its :     a. Energy is ...
23   Problem                                                                              In a radioactive material the a...
24   Problem     A steel ball of mass 5g is thrown downward with velocity 10 m/s from height     19.5 m. It penetrates san...
25   Problem     Two identical springs are connected in series and parallel as shown in the     figure. If fs and fp are f...
26   Problem     Light of frequency v falls on material of threshold frequency v0. Maximum     kinetic energy of emitted e...
27   Problem     A wave equation is given by                  1 x 1        where, x is in cam and t in                ...
28   Problem     A light moves from denser to rarer medium. Which of the following is correct ?     a. Energy increases   ...
29   Problem     A small disc of radius 2 cm is cut from a disc of radius 6 cm. If the distance     between their centers ...
30   Problem     Which one of the following statements is true ?     a. Both light and sound waves in air are transverse  ...
31   Problem     What is not true for equipotential surface for uniform electric field ?     Equipotential surface is flat...
32   Problem     Two copper wires of lengths l and 2l have radil r and 2r respectively. What is     raito of their specifi...
33   Problem     A metro trains strats from rest and in five seconds achieves 108 km/h. After     that it moves with const...
34   Problem     The radius of germanium (Ge) nuclide is measured to be twice the radius of     Be. The number of nucleons...
35   Problem                                                         a1t   a2t 2     The displacement of particle is given...
36   Problem                                                            If   | A x B |   3 A  B, then   the value ...
37   Problem                                                             Pressure of an ideal gas is increased by keeping...
38   Problem     Two spheres of same size, one of mass 2 kg and another of mass 4 kg, are     dropped simultaneously from ...
39   Problem     The moment of inertia of a rod about an axis through its centre and     perpendicular to it is    1   ML2...
40   Problem     A boat at anchor is rocked by waves whose crests are 100 m apart and     velocity is 25 m/s. the boat bou...
41   Problem     By sucking through a straw, a student can reduce the pressure in his lungs     to 750 mm of Hg (density =...
42   Problem     Two parallel large thin metal sheets have equal surface charge densities ( =     26.4 x 10-12 C/m2) of op...
43   Problem     A wire mesh consisting of every small squares is viewed at a distance of 8 cm     through a magnifying co...
44   Problem     Hard X-rays for the study of fractures in bones should have a minimum     wavelength of 10-11 m. the acce...
45   Problem     A lens is made of flint glass (refractive index = 1.5). When the lens is immersed     in a liquid of refr...
46   Problem     The voltage of clouds is 4 x 106 V with respect to ground. In a lightning strike     lasing 100 ms, a cha...
47   Problem     For inelastic collision between two spherical rigid bodies :     a. The total kinetic energy is conserved...
48   Problem     Which of the following diagrams represent the variation of electric field vector     with time for a circ...
49   Problem     The operation of a nuclear reactor is said to be critical, if the multiplication     factor (k) has a val...
50   Problem     The circuit given below represents which of the logic operations ?     a. AND     b. NOT     c. OR     d....
51   Problem     Three objects coloured black, gray and white can with stand hostile     conditions at 28000C. These objec...
52   Problem     Two balloons are filled, one with pure He gas and the other by     air, respectively. If the pressure and...
53   Problem     Flash light equipped with a new set of batteries, produces bright whit light.     As the batteries wear o...
54   Problem     The spatial distribution of the electric field due to charge (A, B) is shown in     figure. Which one of ...
55   Problem     If a street light of mass M is suspended from the end of a uniform rod of     length L in different possi...
56   Problem      238       92   U has 92 protons and 238 nucleons. It decays by emitting an alpha     particle and become...
57   Problem     The fossil bone has a 14C : 12C ratio, which is    1    of that in a living animal                     ...
58   Problem     Two tuning forks P and Q when set vibrating, give 4 beats per second. If a     prong of the fork P is fil...
59   Problem     If alpha, beta and gamma rays carry same momentum, which has the longest     wavelength     a. Alpha rays...
60   Problem     When you make ice cubes, the entropy of water :     a. Does not change     b. Increases     c. Decreases ...
61   Problem     A light emitting diode (LED) has a voltage drop of 2 V across it and passes     current of 10 mA. When it...
62   Problem     The minimum potential difference between the base and emitter required to     switch a sillcon transistor...
63   Problem                               2                Given that :   y  A sin      (ct  x )       where, ...
64   Problem     A projectile is thrown in the upward direction making an angle of 600 with the     horizontal direction w...
65   Problem     A wire 3m in length and 1 mm in diameter at 300C is kept in a low temperature     at –1700C and is stretc...
66   Problem     A tank is filled with water of density 1g per cm3 and oil of density 0.9 g per cm3.     The height of wat...
67   Problem     an engineer claims to have made an engine delivering 10 kW power with fuel     consumption of 1 g/s. The ...
68   Problem     Two concentric spheres of radii R and r have similar charges with equal surface     densities ( ) What i...
69   Problem     In the condenser shown in the circuit is charged to 5V and left in the circuit, in     12s the charge on ...
70   Problem     Two cells, having the same emf, are connected in series through an external     resistance R Cells have i...
71   Problem     Fleming’s left and right hand rules are used in :     a. DC motor and AC generator     b. DC generator an...
72   Problem     A long hollow copper tube carries a current I. Then which of the following will     be true ?     a. The ...
73   Problem     A battery has an emf of 15 V and internal resistance of 1 . Is the terminal to     terminal potential dif...
74   Problem     An inductance L and a resistance R are connected in series with a battery of emf     .The maximum rate at...
75   Problem     Cause of heat production in a current carrying conductor is :     a. Collisions of free electrons with on...
FOR SOLUTIONS VISIT WWW.VASISTA.NET
