Hadoop and VerticaThe Data Analytics Platform at Twitter               Bill Graham - @billgraham     Data Systems Engineer...
About that pony giveaway...                              2
Outline  • Architecture  • Data flow  • Job coordination  • Resource management  • Vertica integration  • Gotchas  • Future...
We count things  • 140 characters  • 140M active users  • 400M tweets per day  • 80-100 TB ingested daily (uncompressed)  ...
Heterogeneous stack  • Many job execution applications    • Crane - Java ETL    • Oink - Pig scheduler    • Rasvelg - SQL ...
Data flow: Analytics                                       Production Hosts                  Log                           ...
Data flow: Analytics                                       Production Hosts                  Log                           ...
Data flow: Analytics                                       Production Hosts                  Log                           ...
Data flow: Analytics                                       Production Hosts                  Log                           ...
Data flow: Analytics                                       Production Hosts                  Log                           ...
Data flow: Analytics                                       Production Hosts                  Log                           ...
Data flow: Analytics                                             Production Hosts                        Log               ...
Chaotic? Actually, no.                         7
System concepts  • Loose coupling  • Job coordination as a service  • Resource management as a service  • Idempotence     ...
Loose coupling  • Multiple job frameworks  • Right tool for the job  • Common dependency management                       ...
Job coordination  • Shared batch table for job state  • Access via client libraries  • Jobs & data are time-based  • 3 typ...
Job coordination  • Shared batch table for job state             batch table:                                             ...
Job coordination  • Shared batch table for job state             batch table:                                             ...
Job coordination  • Shared batch table for job state             batch table:                                             ...
Job coordination  • Shared batch table for job state             batch table:                                             ...
Resource management  • Analytics Resource Manager - ARM!  • Library above Zookeeper  • Throttles jobs and workers    • Onl...
Resource management  • Analytics Resource Manager - ARM!  • Library above Zookeeper  • Throttles jobs and workers    • Onl...
Resource management  • Analytics Resource Manager - ARM!  • Library above Zookeeper  • Throttles jobs and workers    • Onl...
Job DAG & state transition            “Local View”            • Is it time for me to run yet?            • Are my dependan...
Job DAG & state transition            “Local View”            • Is it time for me to run yet?            • Are my dependan...
Job DAG & state transition                 “Local View”                 • Is it time for me to run yet?                 • ...
Example: active users  Production Hosts                     Main Hadoop DW       MySQL/                                  A...
Example: active users                                                                       Job DAG                       ...
Example: active users                                                                       Job DAG                       ...
Example: active users                                                                       Job DAG                       ...
Example: active users                                                                       Job DAG                       ...
Example: active users                                                                            Job DAG                  ...
Example: active users                                                                             Job DAG                 ...
Vertica or Hadoop?  • Vertica    • Loads 100s of Ks rows/second    • Aggregate 100s of Ms rows in seconds    • Used for lo...
Vertica import options  • Direct import via Crane    • Load into dest table, single thread  • Atomic import via Crane/Rasv...
Vertica imports - pros/cons  • Crane & Rasvelg    • Good for smaller datasets, DB to DB transfers    • Single threaded    ...
VerticaStorer  • PigStorage implementation  • From Vertica’s Hadoop connector suite  • Out of the box    • Easy to get Hel...
Pig VerticaStorage  • Our enhancements    • Connection credential management    • Truncate before load option    • Throttl...
Pig VerticaStorage  • Our enhancements    • Connection credential management    • Truncate before load option    • Throttl...
Gotcha #1  • MR data load is not atomic    • Avoid partial reads    • Option 1: load to temp table, then insert direct    ...
Gotcha #2  • Speculative execution is not always your friend    • Launch more tasks than needed, just in case    • For non...
Gotcha #3  • isIdempotant() must be a first-class concept    • Loader jobs will fail    • Failure after first task success =...
Gotcha #4  • Vendor code only gets you so far    • Nice to haves == have to write    • Favor the decorator pattern    • Pi...
Future work  • More VerticaStorer features  • Multiple Vertica clusters  • Atomic DB loads with Pig/Oink  • Better DAG vis...
Acknowledgements                   24
Questions? Bill Graham - @billgraham                             25
