iOS design: a case study   CocoaHeads, Antwerp, March 26th 2012
I would like to give some context to this presentation. Theseslides are from a 30 minute presentation called iOS design: a...
If I make presentations, some slides only contain afew words or images so the slides won’t distractfrom what is being said...
iOS Design: a case study is about how we built ConcertWall.      Kristof, developer      Johan, interface designer      @a...
Let’s go through the process of designing ConcertWall,from initial brief to final result.
Introduction
My name is JohanWolf or @wolfr_ on the internet
I read all day
I like to play video games
I love to write
I have an interest in photography
So this is my company’s website, ( http://wolfslittlestore.be/ ). Notice how the graphics on thehomepage are @2x retina :)...
Design for mobile
Design for mobile                    These days I design a lot of interfaces for mobile:                    iPhone, iPad, ...
First iPhone owned:                         iPhone 3GNumber of iPhones owned so far:                       3Favorite appli...
First iPhone owned:                                                     iPhone 3GNumber of iPhones owned so far:          ...
Case study
Initial brief• Redesign of existing Last Concerts iPhone app• Design of extra functionality to be added• Website: add polish
Proposal• Complete redesign and rebranding of Last Concerts  iPhone app• New marketing strategy: new website & app icon• F...
This is the old Last Concerts website. [http://www.lastconcerts.com/]
This is the old app design. Noticehow it doesn’t look too bad (albeita bit standard) because thedefaults Apple provided ar...
Wireframing &interaction design
To kick off the project we sat down with a giantsheet of paper. I bought a big roll of paper in thepaper shop. Drawing tog...
Not going to bore you too much with this part,but of course before designing or wireframinganything you need to know: * Wh...
On the train home I thought a bit about themarketing... the initial app name idea was“Gigfind” (rejected later). We kept th...
The next process was putting everything Ilearned in the wireframes. This is my style ofwireframing where I put everything ...
This is a detailed view of part of the wireframe.Notice the notes that outline my thoughtssurrounding the screens I’m desi...
I generally use this template called TouchGesture reference guide to show if there is anyspecific movement required on a sc...
This is another template (by Teehan+Lax). I don’tuse it personally but I included it here show thedifference between the i...
interaction design   visual design
Another technique that helps to make the                     distinction is to make your UI elements gray and             ...
Sometimes it might make more sense towireframe with a good kit of default UI and builda working app first, based on the def...
Visual design & user interface        customization
Custom is hard.  People always forget things.
I often hit this iceberg when I stray from nativecontrols. For example, Ajax interactions require morepolish than basic we...
Very simple example:  a dark interface
Let’s say you were to make a “dark” iOSinterface. Maybe a developer would start with asimple grouped table view in Xcode.
You could set a new background color, but nowyour other UI elements don’t match thebackground.
You can now go look for ways to customize theother UI elements. In OS5 some interfaceelements can be given a “tint” color.
There are tutorials out there that show you howto change the default UI completely. The endresult of most of these tutoria...
Even famous apps like Instapaper don’timplement a version that is 100% “right”.There is no default list view for dark inte...
How to make a grouped table view thats fits rightin? Start by looking at the one that Apple made.The key to a great iOS des...
Work those details (not like this app).                                                                    Non retina grap...
In the end, if you want a custom design that isgreat, you’re going to need to implement yourown version of certain UI part...
List item 1List item 2List item 3              Here’s my version the grouped table view... you              could say: not...
list_view_top@2x.png list_view_middle@2x.pnglist_view_bottom@2x.png
List item 1List item 2List item 3              This “dark UI” design works on any background -              even disco sty...
If what you are building can’t be built with thedefault UI elements take a close look at what theleaders in a particular fi...
True business cost of customization: both UIelements took at least several hours & iterationsto get right
But if nobody took any UI risk there would not be anyinnovation out there, so it depends on what you’redoing. This screens...
The Tapbots guys are famous for their custominterfaces. Their business is practically based on thefact that their apps are...
A common interaction   design mistake
Web style form   iOS style form (better!)
It took me a while to learn how to handle forms             on iOS. Take a close look at Calendar (add new             eve...
Test your design (!)             Use Skala preview http://bjango.com/mac/             skalapreview/ by Bjango to view your...
Design resources
For the Illustrator guys like me check out theiPhone Vector UI elements template http://www.mercuryintermedia.com/blog/ind...
The Teehan+Lax PSD template is your best friendwhen designing for iOS. It’s an almost perfectrepresentation of Apple’s UI ...
Design: lessons learned
• Custom vs. native is a tough balance - stick to the  standards where possible• “Coloring” UIKit makes more sense than re...
• Give your app personality through: • Splash screen • App icon • App content
• Dont try to give your app personality through: • Custom interaction design • Ignoring standards and good defaults (e.g. ...
Final designs
App icon
Iterations
Iterations       Since illustration is not my forte we hired an       illustrator, Mattias Lundin from Sweden: http://    ...
It’s easy to go overboard with app icon designs.The guys from Spice Invaders made 50 variants...a bit too much.
You should read their “making of” blog post onhttp://on-5.com/2012/01/the-making-of-spice-invaders/
Speaking of “behind the scenes”, here’s anothercool one: http://www.repeattimerapp.com/how/
In the end we ran with this icon, showing 2posters, a Woodstock reference, bold colors & areference to music through the n...
Michael Flarup’s template is the best templateout there for designing your app icon. Recently anew version came out “suppo...
Keep in mind that this is the size most people aregoing to see your icon at, I can only advise touse a simple glyph/form i...
These icons are super clear and to me still lookattractive:
Assets & specification
You can’t just deliver a PSD to a developer,there’s no way that’s going to work. This part ofthe presentation is about pre...
Some tools to work faster when making assets:Prepo is a Mac app to easily convert @2x imagesto regular sized images (“@1x”...
Here’s the assets for ConcertWall. Takes somework to export them all, especially crisp assets inboth retina and non-retina...
I use some automator actions to make my lifeeasier e.g. this does about the same thing as thePrepo app (convert @2x to @1x)
This action just adds text to multiple files, if youforget to add @2x to the names (like I alwaysdo :))
I write a spec for the developer in which I explainwhich images to use where, which fonts to usewhere etc. You can’t possi...
## Lists: thumbnailsUse glow.png for the glow on last.fm images.* The thumbnails are 54x55 pixels* Use a black 54x55 thumb...
A design has to be  communicatedMerely sending the mockups is not enough.
The app I use to make these is called Mou(http://mouapp.com/), on the left side you writein Markdown, on the right side yo...
Marketing: website
Here’s a simple way to make a good lookingiPhone asset for your marketing website:
Download Mikael Eidenberg’s iPhone template,open it in Photoshop, and edit the smart objectinside of it (http://www.mikael...
This is what it should look like.
Now put your own design in there...
Bam! A nice graphic for the website.
Here’s an early version of the website design. Igot tired of the “feature list” type design talkingabout how great the app...
The new approach is simpler: since the app isfree anyway we want to lead people to downloadright away. Why not let the app...
This is the current version which we are stilllooking to improve, we would like a “happy”version with a festival background.
This shows some of the steps involved increating this design: photography, logo and iconcreation forego the design process...
Thank you!Follow me: @wolfr_ on TwitterE-mail me: mail@wolfslittlestore.beRead the blog: wolfslittlestore.be/journalSubscr...
ResourcesWeb content mentioned in this talkLastConcerts http://www.lastconcerts.com/Touch gesture reference guide: http://...
If you liked this presentationCheck out my previous presentations:Designing better user interfaceshttp://www.slideshare.ne...
Hire me.If you like what you’re seeing, I can apply my knowledge to yourapplication too. Get in touch: mail@wolfslittlesto...
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
iOS design: a case study
