3. Itanium® Update p • Committed Itanium Roadmap • Itanium® 9300 Processor delivered in 2010 • Poulson, the 10th Itanium processor, is on track for 2012 delivery • Kittson processor under development • Intel® Itanium® Processor Line delivers Mission Critical UNIX support, with mainframe-class reliability and scalability ih i f l li bili d l bili • Itanium-based Solutions are a $4B industry in Mission Critical computing (1) More than 80% top Global 100 companies running Itanium® (1) Source: Hewlett-Packard, 20103 All dates and plans are subject to change without notice.
4. Poulson: Advances Itanium® Architecture Key Highlights • New architecture, 2x the cores, 2x instructions throughput • Total 54MB on-die memory • 3.1 Billion Transistors on 32nm process Key Capab t es ey Capabilities New! • Intel® Instruction Replay Technology • Intel® Hyper-Threading Technology, enhanced with dual-domain multi-threading support • Intel® Itanium New Instructions Poulson: the most sophisticated Intel® processor to date4 All dates and plans are subject to change without notice.
5. Poulson: First Intel Processor to support Intel® Instruction Replay Technology p y gy Instruction Buffer Replay pipeline path Instruction replay capability improves system resiliency • Expanded error detection captures more errors in various stages • Errant instructions are then re executed from Instruction buffer to re-executed automatically recover from severe errors Intel® I t ti R l T h l I t l® Instruction Replay Technology helps to prevent h l t t system crashes and data corruption5 All dates and plans are subject to change without notice.
6. Greater Parallelism with Intel® Hyper-Threading Technology Improvements yp g gy p Front-End Back-End Instruction Instruction i Buffer Buffer Dual-Domain Multithreading support enhances performance • Minimizes thread switching costs of traditional Itanium MT implementation • Maximizes efficiency of concurrent threads to complement 12-issue instruction execution Unique EPIC architecture implementation to increase overall throughput6 All dates and plans are subject to change without notice.
7. Itanium® Processor New Instructions Mid- Branch Floating Point Mid- Expanded Data Level Predict Execution Inst. Level Integer Operations Access Hints Cache BR Integer Floatin Data • mpy4 • mov dahr CTL Register R i t g Pt RF Cache C h • mpyshl4 1st Integer • clz struction level Cache Execution Queues 1st Ins level 1st level Cache Cache Buffers Thread Control Pipe Line Interface Expanded Software Buffers • hint@priority Control Logic Prefetch • if t h ifetch.count t Individual Poulson Core • Poulson continues to optimize for legacy Itanium code without recompilation • New Instructions simplify common tasks and branch operations to help take future Itanium performance to the next level Poulson architecture and New Instructions are underpinnings i i i i for the future of Itanium computing7 All dates and plans are subject to change without notice.
8. Poulson RAS Advances Increase System and Application Resiliency Error Prevention and End to End Error Improved Firmware Correction Detection Error Handling • Intel® Instruction Replay • Enhanced Cache error • Expanded coverage of Technology coverage p potential error events for automatic recovery • Expanded use of soft • Residual error error resilient structures protection for floating- • Improved logging and point operations configurations for • HW/SW mechanisms higher hi h availability and il bilit d enable correctable parity serviceability errors Increases Process Improves Execution Minimizes Service Resiliency Integrity Interruption Enables mission critical RAS capability with enhanced error prevention, detection and correction8 All dates and plans are subject to change without notice.
9. Poulson Builds on Itanium’s Strengths • Intel® Itanium New Instructions New Itanium • Intel® Hyper Threading Technology improvements Intel Hyper-Threading Architecture • Doubles the high capacity cores and delivers maximum 12-issue execution EPIC architecture • Intel® Instruction Replay Technology Improved Power • Enables accurate Core power prediction and management Management and RAS features • Achieves mainframe reliability and resiliency with high levels of RAS feature integration • Intel’s most sophisticated general purpose processor to date Innovative with 3 1B transistors 3.1B engineering work • Supports advanced OEM system features for physical partitions, seamless failovers, and system reconfigurations Strong Foundation for the future of Itanium Computing9 All dates and plans are subject to change without notice.
