Troubleshooting WirelessLANs with CentralizedControllersBRKEWN-3011Wesley Terry      BRKEWN-3011   © 2011 Cisco and/or its...
Troubleshooting Wireless LANs Supportability Software and Support Model Troubleshooting Basics The Client Debug WLC C...
Supportability BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   3
Supportability WLC Supportability        Methods of Management        Using the GUI        Important Show Commands (CLI) ...
WLC SupportabilityMethods of Management                                                                                   ...
WLC SupportabilityUsing the GUI Monitor        AP/Radio Statistics        WLC Statistics        Client Details        Tra...
WLC SupportabilityUsing the GUI Wireless > All APs        AP list shows AP Physical UP Time        APs are sorted by Cont...
WLC SupportabilityUsing the GUI Management        SNMP Config        Logs        Tech SupportBRKEWN-3011    © 2011 Cisco ...
WLC SupportabilityImportant Show Commands (CLI) Show run-config        Must have! No exceptions!        “show run-config ...
WLC SupportabilityImportant Debugs (CLI) Debug client <client mac address>        Client Involved? Must Have! No Exceptio...
WLC SupportabilityBest Practices Change default SNMP Parameters Configure Syslog for WLC and AP Enable Coredump for WLC...
AP Supportability Methods of Accessing the AP                                                                            ...
AP SupportabilityAP Remote Commands (WLC CLI) Debug AP enable <AP name>        Enables AP Remote Debug        AP Must be ...
AP SupportabilityShow Commands (AP CLI or WLC Remote Cmd) Show controller Do[0/1] (or Show Tech)        Must have! Before...
Software andSupport ModelBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   15
Software and Support Model Opening a TAC Service Request Cisco Support Model        TAC vs Business Unit        What to ...
Opening a TAC Service Request What should I have ready?        Clear problem description        Always: Show run-config  ...
Opening a TAC Service Request Potential reasons to slow a TAC SR‟s resolution        Information about the problem is mis...
Cisco Support Model – TAC vs. BU TAC        Customer advocate        Technology focused with cross technology collaborati...
Cisco Support Model – Expectations What not to expect from TAC        Design and deployment        Complete configuration...
Cisco Support Model - Escalation TAC Escalation Process        Multi-Tier support resources within a technology        TA...
WLC Software Trains CCO - Cisco.com release        6.0.202.0, 7.0.116.0, etc…        Full test cycle        Classified as...
WLC Software Trains - ES vs. Escalation Engineering Special        Development “special” image for fix validation or limi...
Troubleshooting BasicsBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   24
The 10-Point Capture                                                                           EAP                        ...
Troubleshooting Basics Troubleshooting 101                                                                     Problem   ...
Troubleshooting 101 Troubleshooting is an art with no right or wrong  procedure, but best with a logical methodology. St...
Troubleshooting 101 Step 2: Understand any possible triggers        If something previously worked but no longer works, t...
Troubleshooting 101 Step 4: Reproducibility        Any problem that has a known procedure to reproduce (or        frequen...
Recommended Tools Wireless Sniffer        Example: Linksys USB600N with Omnipeek              TAC can publish Omnipeek-RA...
The Client DebugBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   31
Steps to Building an 802.11 Connection    802.11                              1. Listen for Beacons    State 1:Unauthentic...
The Client Debugdebug client <mac address> A multi-debug macro        (Cisco Controller) >debug client 00:16:EA:B2:04:36 ...
Understanding the Client StateName                                                                                 Descrip...
The Client Debug - Walkthrough Association (Start) L2 Authentication (8021X_REQD) Client Address Learning (DHCP_REQD) ...
Client Debug - Association BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   36
Association(Cisco Controller) >debug client 00:16:EA:B2:04:36(Cisco Controller) >(Cisco Controller) >Association received ...
AssociationAssociation received from mobile on AP 00:26:cb:94:44:c00.0.0.0 START (0) Changing ACL none (ACL ID 0) ===> non...
AssociationSTA - rates (12): 130 132 139 150 12 18 24 36 48 72 96 108 0 0 0 0Processing RSN IE type 48, length 22 for mobi...
Association0.0.0.0 START (0) Initializing policy0.0.0.0 START (0) Change state to AUTHCHECK (2) last state AUTHCHECK (2)0....
AssociationSending Assoc Response to station on BSSID 00:26:cb:94:44:c0 (status 0) ApVapId 1 Slot 0        Slot 0 = B/G(2...
Association - FSRProcessing WPA IE type 221, length 22 for mobile 00:16:ea:b2:04:36CCKM: Mobile is using CCKMCCKM: Process...
Association - Takeaway Association vs. Reassociation Debug shows        AP, Slot, AP-Group, WLAN ID, Interface, Data Rat...
Client Debug –L2 Authentication BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   44
802.1X AuthenticationSupplicant                                                                               Authenticato...
WPA2-AES-802.1XSending Assoc Response to station on BSSID 00:26:cb:94:44:c0 (status 0) ApVapId 1 Slot 0Station 00:16:ea:b2...
Common EAP Types 1 – Identity 2 – Notification 3 – NAK                  Sending EAP Request from AAA to mobile 00:16:ea...
802.1X (Cont.) (WPA2-AES-PSK)Sending Assoc Response to station on BSSID 00:26:cb:94:44:c0 (status 0) ApVapId 1 Slot 0Creat...
WPA2-AES-PSK - FailedStarting key exchange to mobile 00:1e:8c:0f:a4:57, data packets will be droppedSending EAPOL-Key Mess...
L2 Authentication - Takeaway  8021X_REQD means L2 Authentication pending          Authentication/Encryption has not be es...
Client Debug –IP Learning State BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   51
Client DHCP00:16:ea:b2:04:36 Received EAPOL-key in PTKINITNEGOTIATING state00:16:ea:b2:04:36 apfMs1xStateInc00:16:ea:b2:04...
Client DHCP                                                                                               Client State = ...
DHCP Proxy Enabled – DHCP Discover*pemReceiveTask: 00:16:ea:b2:04:36 0.0.0.0 Added NPU entry of type 9, dtlFlags 0x032.151...
DHCP Proxy Enabled – DHCP Offer34.166: 00:16:ea:b2:04:36 DHCP received op BOOTREPLY (2) (len 308,vlan 0, port 29, encap 0x...
DHCP Proxy Enabled – DHCP Request38.169: 00:16:ea:b2:04:36 DHCP received op BOOTREQUEST (1) (len 316,vlan 0, port 29, enca...
DHCP Proxy Enabled – DHCP Ack38.172: 00:16:ea:b2:04:36 DHCP received op BOOTREPLY (2) (len 308,vlan 0, port 29, encap 0xec...
DHCP Proxy Disabled – Discover/Offer*pemReceiveTask: 00:16:ea:b2:04:36 0.0.0.0 Added NPU entry of type 9, dtlFlags 0x0*00:...
DHCP Proxy Disabled – Request/Ack*00:16:ea:b2:04:36 DHCP received op BOOTREQUEST (1) (len 316,vlan 0, port 29, encap 0xec0...
Learning IP without DHCP*Orphan Packet from 10.99.76.147 on mobile*0.0.0.0 DHCP_REQD (7) Successfully plumbed mobile rule ...
Client DHCP - Takeway DHCP_REQD means Learning IP State        Only “Required” if enabled on WLC If Proxy is enabled    ...
Client Debug –L3 Authentication BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   62
Webauth*apfReceiveTask: 00:16:ea:b2:04:36 0.0.0.0 DHCP_REQD (7) Successfully plumbed mobile rule (ACL ID 255)*pemReceiveTa...
Webauth Redirect                                                                                  Webauth                 ...
ARP and DNS FunctionConfirm ARP and DNS FunctionBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   C...
3-Way Handshake                                                                                                           ...
Webauth - Takeaway If WEBAUTH_REQD, then not authenticated      Only traffic allowed is DHCP, ARP, DNS, Pre-Auth ACL, IPv...
Client Debug - RunBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   68
Run State10.10.3.82 DHCP_REQD (7) Change state to RUN (20) last state RUN (20)10.10.3.82 RUN (20) Reached PLUMBFASTPATH: f...
Client Debug –Deauth/DisassocBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   70
Deauthenticated Client Idle Timeout       Occurs after no traffic received from Client       Default Duration is 300 seco...
Deauthenticated Client WLAN Change       Modifying a WLAN in anyway Disables and Renables WLANapfSendDisAssocMsgDebug (ap...
Deauthenticated Client Authentication Timeout     Auth or Key Exchange max-retransmissions reachedRetransmit failure for ...
Deauthentication - Takeaway Client can be removed for numerous reasons        WLAN change, AP change, configured interval...
Client Debug – Tips and Tricks BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   75
Tips and Tricks Collect a client debug for an extended duration        Several roams, deauths, failures, etc… Use an enh...
Tips and TricksBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   77
Tips and TricksBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   78
Client Debug – SummaryBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   79
Client Connectivity Unified Wireless Network: Troubleshoot Client  Issues Document ID: 107585 Configuration Issues      ...
802.11n Speeds Troubleshoot 802.11n Speeds Document ID: 112055 Configuration Issues        11n Support Enabled        WM...
802.11n A-MPDU/A-MSDU Aggregation methods used could impact interop or  performance                                      ...
WLC Config Analyzer (WLCCA)BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   83
What Is the WLCCA? It is a Post Sales tool Main objective: Save time while analyzing configuration files  from WLCs Sec...
Where? Support Forums DOC-1373 BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   85
Input Needed Complete config output from WLC     Show run-config It does not work with old “show running-config” or with...
Functionality Overview - Checks Audit Checks     More than 100 config detail verifications     Based on TAC/Escalation ca...
Functionality Overview Audit Checks BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public...
Functionality Overview Config View BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public ...
WLCCA – High RF Index APsBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   90
Reducing CCI Turn off excess 2.4 radios. May want to do this  gradually, e.g. turn off 20% of radios per attempt After t...
2.4GHz – Target Coverage Most all 2.4GHz radios are at power 2 - 5 (dont want 7  or 8) In all locations, you have covera...
5 GHz – Target Coverage  Most all 5GHz radios are at power 1 – 3 (at   least 14dBm)      Consider the RRM min power setti...
Additional TroubleshootingBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   94
Additional Troubleshooting Wireshark Tutorial Clean Air SE-Connect / AP Sniffer Mode AP Join RRM Multicast/Broadcast...
Wireshark Tutorial BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   96
Wireshark Tutorial Default Wireshark view might look like this:BRKEWN-3011   © 2011 Cisco and/or its affiliates. All righ...
Wireshark Tutorial Newer versions of Wireshark have a feature for  “Apply as Column”      This will take any decodable pa...
Wireshark Tutorial Within seconds your wireshark can also have:BRKEWN-3011   © 2011 Cisco and/or its affiliates. All righ...
Wireshark Tutorial Filtering data is just as easyBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.  ...
Wireshark Tutorial - CAPWAP User data is encapsulated in CAPWAPBRKEWN-3011   © 2011 Cisco and/or its affiliates. All righ...
Wireshark Tutorial Wireshark can also de-encapsulate CAPWAP DATA       Edit > Preference > Protocols > CAPWAPBRKEWN-3011 ...
Wireshark Tutorial With CAPWAP de-encapsulated you can see all the  packets to/from client (between AP and WLC)BRKEWN-301...
SE-Connect – Clean AirAP Sniffer ModeBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public...
SE-Connect and Sniffer Mode Clean Air APs can be used in lieu of Spectrum Card  for Spectrum Analysis        AP can be pl...
Spectrum Expert with Clean Air Obtain Spectrum Key Connect to Remote Sensor  BRKEWN-3011   © 2011 Cisco and/or its affil...
Spectrum Expert with Clean AirBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   107
Sniffer Mode AP Select channel to Sniff Select destination for traffic    BRKEWN-3011   © 2011 Cisco and/or its affiliat...
Sniffer Mode AP Omnipeek has a Remote Adapter to capture this data Wireshark, just capture network adapter   NOTE: Wires...
Sniffer Mode AP With wireshark, filter !icmp.type == 3 Data (UDP 5000) still not intelligible yet   Decode as Airopeek  ...
Sniffer Mode APBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   111
AP Discover/JoinBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   112
AP Discover/Join                                                                                         AP Runs Hunting  ...
AP - Discover Process AP Discovery Req to known and learned WLCs Broadcast       Reaches WLCs with MGMT Interface in loc...
AP - Discover Process                       broadcast                                                                     ...
AP – WLC Selection/Join WLCs send Discovery Response back to AP    Name, Capacity, AP Count, Master?, AP-MGR, Load per AP...
Troubleshooting AP Discovery/Join “Lightweight AP (LAP) Registration to a Wireless LAN  Controller (WLC)”, Document ID 70...
RRMBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   118
RRM There are usually only two common scenarios or  issues involving RRM APs not changing channel        Check if other ...
RRM Debugs WLC – debug airewave-director <?> AP       debug capwap rm mesurements       debug capwap rm rogueBRKEWN-3011...
RRM Show AP Auto-RF (In Run-Config) show ap auto-rf [802.11a/b] <AP Name> Load Information        Receive Utilization.. ...
Broadcast/MulticastBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   122
Broadcast/MulticastBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   123
Broadcast/Multicast AP Multicast Mode – Multicast     Address must be unique among WLCs Broadcast Traffic is delivered v...
Broadcast/Multicast AP Show Commands     Show capwap mcast     Show capwap mcast mgid all BRKEWN-3011   © 2011 Cisco and/...
Client Mobility BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   126
Mobility—Intra-Controller Client roams between two APs on the same controller BRKEWN-3011   © 2011 Cisco and/or its affil...
Mobility—Inter-Controller (Layer 2)BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public  ...
Mobility—Layer 3 Layer 3 roaming (a.k.a. anchor/foreign)        New WLC does not have an interface on the subnet the clie...
Mobility—Messaging Flow When a client connects to a WLC for the first time,  the following happens:        New WLC sends ...
Debug Client <Mac Address>Mobility— L2 Inter WLC                                                                  Debug Mo...
Debug Client <Mac Address>Mobility— L3 Inter WLC                                                                  Debug Mo...
Debug Client <Mac Address>Mobility— L3 Inter WLC                                                                  Debug Mo...
Mobility— L3 Handoff Ignored*mmListen: Mobility packet received from:*mmListen: 10.4.22.55, port 16666*mmListen: type: 3(M...
Mobility Group vs. Mobility Domain Mobility Group - WLCs with the same group name      L2/L3 Handoff      Auto Anchoring ...
Mobility Data/Control Path Sent between all WLCs, by member with lowest MAC      Control Path = UDP 16666 (30 Seconds)   ...
Voice over WiFi BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   137
VoWiFi Wireless IP Phone Deployment Guide        http://www.cisco.com/en/US/docs/voice_ip_comm/cuipph/79        25g/7_0/e...
VoWiFi - Troubleshooting Must know if problem occurs during roaming events  or when no association change takes place If...
VoWiFi - Troubleshooting Define a reproducible area where you believe you  have perfect voice coverage but have problems...
VoWiFi - Debugs Phone can Trace (debug) to file or syslog       Recommend USB Connection and SYSLOG       Configured via ...
SummaryBRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   142
SummaryClient       WLC - show run-config, debug client <mac>, debug dhcp message enable,             debug dot1x <?> enab...
Summary Links:        Understanding Debug Client on Wireless LAN Controllers        (WLCs) Document ID: 100260        Uni...
Complete Your OnlineSession Evaluation Receive 25 Cisco Preferred Access points for each session  evaluation you complete...
Visit the Cisco Store for               Related Titles        http://theciscostores.comBRKEWN-3011   © 2011 Cisco and/or i...
BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   147
Thank you.BRKEWN-3011   © 2011 Cisco and/or its affiliates. All rights reserved.   Cisco Public   148
