This document summarizes an industrial/commercial induction lighting high bay fixture called EasyLume. It is a maintenance-free system for 20-25 years that provides high performance lighting with low energy consumption. The fixture uses an induction lamp and electronic IC generator that produces over 75 CRI at efficiencies over 90% while saving 40-60% on energy costs compared to metal halide lights. It is suitable for ceilings from 18-40 feet high and has a rated life of 100,000 hours.

1. valuelight practical ideas
you need to
design specify
superior 1628187 Ontario Ltd. 612 Gordon Baker Rd. Toronto M2H 3B4 Canada
1-800-49-LAMPS fax 1-800-243-9494 int’l: ++1-416-352-5322 svc@valuelight.com
lighting systems
Project Reference:____________________________________________________________________________________________________________________
Fixture Type: __________ Cat. No:_________________________________ Voltage:___________ Options:_________________________________________
EASYLUME Industrial / commercial induction lighting high bay
high performance, low maintenance system
Induction Lamp + Electronic IC Generator CSA, UL or equivalent IP40
“Install & Forget”, maintenance-free for 20 - 25 years in typical commercial / industrial environments
ideal luminaire for factories, warehouses, supermarkets, schools, gyms, exhibition halls
narrow to medium distribution suitable for celings 18’ - 40’ high
high fixture efficiency, robust high performance specular reflector
40-60% energy savings from common existing Metal Halide lights
high C.R.I. (colour rendering) provides better vision, at lower light levels
IC generator is optimally cooled in cast aluminum housing CRI: >75
100,000 hours life rated induction lamp IC generator efficiency >90%
high performance specular aluminum reflector Input voltage 120V, 220V or 347V AC 50/60Hz
optimized for efficiency and long lasting performance Power factor >0.9
operating ambient temperature -100C to +55 0C THD <15%
wide “Low Bay” distribution with optional white reflector max. six years fixture warranty
Ordering Information Energy Savings
PRODUCT CODE SYSTEM WATTS HID REPLACEMENT DIMENSIONS MAX. WARRANTY REPLACES HID with ANNUAL SAVINGS: 1 Shift
SAVINGS: 2 Shifts 24/7
IHEL-IB-120-CW 73.3 150W 18”O.D. x 26” SIX YEARS 150W lamp (192W with ballast) $62.40 $93.60 $136.66
IHEL-IC-120-CW 111.0 250W 18”O.D. x 26” SIX YEARS 250W lamp (293W with ballast) $109.80 $163.80 $239.15
IHEL-IE-120-CW 207.6 400W 18”O.D. x 26” SIX YEARS 400W lamp (456W with ballast) $147.60 $221.40 $323.24
Colour Temperature Suffix: -CW: 4100K -WW: 3500K Calculations based on: energy cost $0.15/kWh
Input Voltage Suffix: -120 120 Volts/60Hz 1 shift: 4000 hrs/year
-347 347V/60Hz 2 shifts: 6000 hrs/year
-220 220-240V/ 50 Hz 24/7: 8760 hrs/year
Optional “Low Bay” Reflector: -WH white reflector
Accessories
PRODUCT CODE DESCRIPTION
IHEL-HBW WIREGUARD
IHEL-HBC -y
IHEL-HBC-y MONOP0INT MOUNT W. CANOPY, -y IS SUSPENSION LENGTH IN MM
IHEL-5 AIRCRAFT CABLE FAST HANGING SYSTEM 60” MAX. SUSPENSION
IHEL-10 AIRCRAFT CABLE FAST HANGING SYSTEM 120” MAX. SUSPENSION
Design c 2009 Valuelight, rev. Sept. 21/09
Specifications subject to change without notice.
Customer Service & Technical Support
1-800-49-LAMPS www.valuelight.com valuelight
