4. What are HTML5 Ads?
An HTML5 ad is a display ad consisting of a self-
contained HTML, CSS, and Javascript package, which
can provide rich animation and interactivity
5. What do HTML5 Ads Look Like?
Google Web Designer Showcase
6. The Past
● Create HTML5 ads only via the AdWords UI
● Support only for predefined HTML5 ad
templates or Google Web Designer ads
Today
● Create HTML5 ads via the API
● Use any authoring tool
HTML5 Ads in AdWords
7. HTML5 vs Flash
Flash Ads HTML5 Ads
Maturity ● Mature ● Maturing
Availability ● Closed standard
proprietary to Adobe
● Open standard
Browser
support
● Consistent desktop
support, but no longer
played automatically in
Chrome
● Limited mobile support
● Supported by all major
browsers on desktop
and mobile
● Not all browsers are
consistent
9. Key AdWords HTML5 Ad Policies
● Ad is a single zip file <150 KB
● Format must be a standard
ad size
● Only relative references are
permitted
○ External references (outside the zip file)
allowed only for Google fonts, Google-hosted
jQuery, and exit handler
See the AdWords Help Center for the complete list
10. Several Ways to Create HTML5 Ads
❏ Google Web Designer
❏ Manual creation
❏ AdWords UI ad gallery
❏ Other authoring tools
✔ discussed today
✔
✔
11. Google Web Designer
● Simple but powerful WYSIWYG interface
● Many pre-made templates available
● Includes required meta tags automatically
● Low barrier to entry for your creative design team
14. New API Objects
Template Ad ID 419
A new template ad which takes a
MediaBundle object as a field
MediaBundle object
A new subclass of Media that
contains the ad’s zip file and specifies
the HTML entry point
15. Code Sample
● Create the TemplateAd object
TemplateAd html5Ad = new TemplateAd();
html5Ad.setName("Ad for HTML5");
html5Ad.setTemplateId(419L);
html5Ad.setFinalUrls(new String[] {"http://example.com/html5"});
html5Ad.setDisplayUrl("example.com/html5");
Dimensions dimensions = new Dimensions();
dimensions.setWidth(300);
dimensions.setHeight(250);
html5Ad.setDimensions(dimensions);
16. Code Sample (Contd.)
● Create the MediaBundle object
byte[] html5Zip = com.google.api.ads.common.lib.utils.Media
.getMediaDataFromUrl("https://goo.gl/9Y7qI2");
MediaBundle mediaBundle = new MediaBundle();
mediaBundle.setData(html5Zip); // takes base64 encoded bytes of the zip file
mediaBundle.setEntryPoint("carousel/index.html");
mediaBundle.setType(MediaMediaType.MEDIA_BUNDLE);
Note: You can also refer to a previously uploaded MediaBundle object
17. Code Sample (Contd.)
● Populate the TemplateAd
TemplateElementField media = new TemplateElementField();
media.setName("Custom_layout");
media.setFieldMedia(mediaBundle);
media.setType(TemplateElementFieldType.MEDIA_BUNDLE);
TemplateElementField layout = new TemplateElementField();
layout.setName("layout");
layout.setFieldText("Custom");
layout.setType(TemplateElementFieldType.ENUM);
TemplateElement adData = new TemplateElement();
adData.setUniqueName("adData");
adData.setFields(new TemplateElementField[] {media, layout});
html5Ad.setTemplateElements(new TemplateElement[] {adData});
18. Code Sample (Contd.)
● Create the AdGroupAd
AdGroupAd html5AdGroupAd = new AdGroupAd();
html5AdGroupAd.setAdGroupId(adGroupId);
html5AdGroupAd.setAd(html5Ad);
html5AdGroupAd.setStatus(AdGroupAdStatus.PAUSED); // optional
AdGroupAdOperation operation = new AdGroupAdOperation();
operation.setOperator(Operator.ADD);
operation.setOperand(html5AdGroupAd);
AdGroupAdReturnValue result =
adGroupAdService.mutate(new AdGroupAdOperation[] {operation});
19. Code Sample (Contd.)
● Uploading a MediaBundle separately
byte[] html5Zip = com.google.api.ads.common.lib.utils.Media
.getMediaDataFromUrl("https://goo.gl/9Y7qI2");
MediaBundle mediaBundle = new MediaBundle();
mediaBundle.setData(html5Zip);
// do not call setEntryPoint()
mediaBundle.setType(MediaMediaType.MEDIA_BUNDLE);
mediaBundle = (MediaBundle) mediaService.upload(new Media[] {mediaBundle})[0];
Map<MediaSize, Dimensions> dimensions = Maps.toMap(mediaBundle.getDimensions());
System.out.printf(
"HTML5 media with ID %d, dimensions '%dx%d', and MIME type '%s' "
+ "was uploaded.%n",
mediaBundle.getMediaId(), dimensions.get(MediaSize.FULL).getWidth(),
dimensions.get(MediaSize.FULL).getHeight(), mediaBundle.getMimeType());
20. ● Google Web Designer - https://goo.gl/2X7BpS
● HTML5 ad policies - https://goo.gl/LIoKJ7
● Swiffy - https://goo.gl/grjyIh
● Template ads - https://goo.gl/7kRFZv
● Example SOAP request - https://goo.gl/J0Fn16
Resources
