The document describes research assessing the strength of reinforced concrete structures using ultrasonic pulse velocity (UPV) and Schmidt rebound hammer (SRH) non-destructive tests. The tests were used to determine relationships between compressive strength test results and NDT values. Regression analysis was used to develop models correlating compressive strength with UPV and SRH readings. The results show significant correlations for both methods, with SRH prediction found to be more efficient under certain conditions. Combining the two NDT methods improved strength estimation and produced more reliable results closer to true values.
