12. デプロイ処理の流れ(1) デプロイ準備
Tripleo Deep Dive: TripleOのアーキテクチャ
12
Undercloud
Overcloud
Controller
Server Server
Swift Heat Ironic
Nova
Neutron
openstack cli
template
Templateを用意して
$ openstack overcloud deploy …
13. デプロイ処理の流れ(2) planの作成
Tripleo Deep Dive: TripleOのアーキテクチャ
13
Undercloud
Overcloud
Controller
Server Server
Swift Heat Ironic
Nova
Neutron
openstack cli
template
plan
openstack cli内でtemplateからplanを
作成してswiftに格納
14. デプロイ処理の流れ(3) overcloudスタックの作成
Tripleo Deep Dive: TripleOのアーキテクチャ
14
Undercloud
Overcloud
Controller
Server Server
Swift Heat Ironic
Nova
Neutron
openstack cli
template
plan
openstack cliがHeatにスタックの作成
をリクエスト
overcloud
15. デプロイ処理の流れ(4) OSインストール
Tripleo Deep Dive: TripleOのアーキテクチャ
15
Undercloud
Overcloud
Controller
Server Server
Swift Heat Ironic
Nova
Neutron
openstack cli
template
plan
OS
overcloud
HeatがIronic/Nova/Neutronを使ってベ
アメタルインスタンスをデプロイ
16. デプロイ処理の流れ(5) ネットワーク設定
Tripleo Deep Dive: TripleOのアーキテクチャ
16
Undercloud
Overcloud
Controller
Server Server
Swift Heat Ironic
Nova
Neutron
openstack cli
template
plan
OS
nic設定os-net-config
os-collect-config
overcloud
SoftwareConfig/Deploymentリソースを
使ってnic設定スクリプトを実行
17. デプロイ処理の流れ(6) ホスト・サービス設定
Tripleo Deep Dive: TripleOのアーキテクチャ
17
Undercloud
Overcloud
Controller
Server Server
Swift Heat Ironic
Nova
Neutron
openstack cli
template
plan
OS
nic設定
ホスト設定
サービス設定
os-net-config
os-collect-config
puppet
ansible
overcloud
SoftwareConfig/Deploymentリソースを
使いansibleを実行。ansibleからpuppet
などを呼び出し設定適用
18. デプロイ処理の流れ(7) コンテナの設定(Pike以降)
Tripleo Deep Dive: TripleOのアーキテクチャ
18
Undercloud
Overcloud
Controller
Server Server
Swift Heat Ironic
Nova
Neutron
openstack cli
template
plan
OS
nic設定
ホスト設定
コンテナ設定
os-net-config
puppet
サービス設定
os-collect-config
ansible
paunch
puppet
overcloud
Pike以降ではansible内でコンテナの設
定も実行。
コンテナ設定はpaunchで管理
19. デプロイ処理のAnsible化 (Rocky以降)
Tripleo Deep Dive: TripleOのアーキテクチャ
19
Undercloud
Overcloud
Controller
Server Server
Swift Heat Mistral
openstack cli
template
plan
OS
nic設定
ホスト設定
コンテナ設定
os-net-config
puppet
サービス設定
ansible
paunch
puppet
overcloud ansible
ソフトウェア設定をHeatからAnsibleに
切り出し。
MistralがPlaybookの実行を管理
参考: https://docs.openstack.org/tripleo-docs/latest/install/advanced_deployment/ansible_config_download.html
22. Q. jinja2って何? A. こんな奴
Tripleo Deep Dive: THT詳解
22
{%- set primary_role = [roles[0]] -%}
{%- for role in roles -%}
{%- if 'primary' in role.tags and 'controller' in role.tags -%}
{%- set _ = primary_role.pop() -%}
{%- set _ = primary_role.append(role) -%}
{%- endif -%}
{%- endfor -%}
{%- set primary_role_name = primary_role[0].name -%}
...
resource_registry:
# networks as defined in network_data.yaml
{%- for network in networks if network.enabled|default(true) %}
OS::TripleO::Network::{{network.name}}: ../network/{{network.name_lower|default(network.name.lower())}}.yaml
{%- endfor %}
# Port assignments for the VIPs
{%- for network in networks if network.vip and network.enabled|default(true) %}
OS::TripleO::Network::Ports::{{network.name}}VipPort:
../network/ports/{{network.name_lower|default(network.name.lower())}}.yaml
{%- endfor %}
OS::TripleO::Network::Ports::RedisVipPort: ../network/ports/vip.yaml
...
参考: http://jinja.pocoo.org/
34. TripleOを使ったカスタマイズ
Tripleo Deep Dive: TripleOの使い方
● 構成・設定をカスタマイズするための機構
1. TripleOのtemplate生成用パラメタを使うもの
a. Role定義
b. Network定義
2. Heatのtemplateカスタマイズ機能を使うもの
a. リソース定義
b. パラメタ定義
3. カスタマイズ用の特殊なリソースを使うもの
a. ExtraConfig
● 1は説明済みなので2, 3を説明
34
