2. Overview:
• Parkinson’s Disease
• Background Tolcapone: COMT inhibitor drug
• COMT: target enzyme
• Mechanism in action
• Interactions between Tolcapone and COMT
• Detection
3. Parkinson’s Disease (PD):
• A neurological disorder: low dopamine level in
Central Nerve System (CNS).
• Dopamine is a neurotransmitter that helps nerve
cells communicate to controls balance and muscle
movement
4. Tolcapone:
• COMT inhibitor (IC50 = 36 nM)
• FDA approved in 1998, but issued a black box warning in 2009
due to the risk of liver failure that can lead to death.
• Combine with Levodopa/Decarboxylase inhibitor therapy.
• Withdrawn if :
No improvement in dopamine level in the brain within 3
weeks
SGPT/ALT or SGOT/AST levels exceed 2 times the
upper limit of normal
Clinical signs and symptoms suggest the onset of hepatic
dysfunction
5. Tolcapone: Lipinski’s Rule of 5
• Molecular mass:
273.244 g/mol < 500 g/mol ✔
• H bond donors: 2 < 5 ✔
• H bond acceptors: 5 <10 ✔
• LogP: 4 < 5 ✔
6. Catechol-O-methyltransferase (COMT):
• One single domain withα-
helices arranged around a
central mixed β-sheet
• Catalytic site: binds one
Mg2+ and the catechol
substrate
• SAM-binding site
DOI:10.2210/pdb3s68/pdb
7. Catechol-O-methyltransferase (COMT):
• Catalyzes the methylation of dopamine or COMT inhibitor
by using S-adenosyl-L-methionine (SAM) as a methyl donor
and yielding the O-methylated catechol and S-adenosyl-L-
homocysteine (SAH)
8. Mechanism in action:
• Tolcapone is used with Levodopa and Decarboxylase
inhibitor.
• Levodopa (L-DOPA): dopamine supplementation
• Levodopa is converted to Dopamine by the aromatic l-
amino acid decarboxylase (AADC)
9. Mechanism in action:
• Only approximately 1% of
an oral dose of levodopa
reaches the brain and
converted into Dopamine
• Levodopa is extensively
converted into dopamine by
Decarboxylase and into 3-
O-methyldopa (3-OMD) by
COMT enzyme in GI track,
liver and kidney; also in the
brain
10. Mechanism in action:
• Levodopa with an AADC
inhibitor to prevent its
conversion to dopamine in
peripheral tissues: only 5–
10% of an oral dose of
levodopa reaches the brain
• Tolcapone prevent the
degradation of Levodopa
and Dopamine
• Increases the relative
bioavailability of levodopa
by approximately twofold
12. Tolcapone: H bonds with COMT
• Asp 141 (2.5Å )
• Lys 144 (1.9Å and
2.6Å)
• Asn 170 (both 2.1Å )
• Glu 199 (1.8Å )
DOI:10.2210/pdb3s68/pb
13. Tolcapone: interact with Mg2+ in COMT
• Mg2+ ion is an anchor of Tolcapone in a
catalytic position
DOI:10.2210/pdb3s68/pbd
14. Tolcapone: interact with SAM in COMT
• 1 (-OH) of Tolcapone is positioned in proximity to
the activated methyl group of SAM
DOI:10.2210/pdb3s68/pbd
20. Metabolites of Tolcapone:
• Tolcapone is almost completely
metabolized prior to excretion
• 0.5% of dose found unchanged in
urine
• Tolcapone metabolites in urine
(60%) and in feces (40%)
• The primary metabolic pathways
is glucuronidation, also
methylation, oxidative
hydroxylation and reduction
reactions
24. Conclusion:
• Tolcapone combination with Levodopa/AADC
inhibitor: increase the amount of levodopa reaching the
brain, by protecting its O-methylation in the periphery
• High affinity and contribute to COMT conformational
changes
• Tolcapone is completely metabolized prior to excretion:
high risk of liver failure.
• Tolcapone and its metabolites can be detected by
different techniques.
25. References:
1. Bonifacio, M. J., Palma, P., Almeida, L., & Silva, P. S. (2007). Catechol-O-methyltransferase and Its Inhibitors in
Parkinson’s Disease. CNS Drugs Reviews,13(3), 352-379. Retrieved April 6, 2017.
2. Pajouhesh, H., & Lenz, G. R. (2005). Medicinal chemical properties of successful central nervous system
drugs. NeuroRX,2(4), 541-553. doi:10.1602/neurorx.2.4.541
3. Parkinson disease: Your Guide to Understanding Genetic Conditions. (2017, April 4). Retrieved April 6, 2017, from
https://ghr.nlm.nih.gov/condition/parkinson-disease#resources
4. Wishart DS, Tzur D, Knox C, et al., HMDB: the Human Metabolome Database. Nucleic Acids Res. 2007 Jan;35(Database
issue):D521-6. 17202168
5. Wishart DS, Knox C, Guo AC, et al., HMDB: a knowledgebase for the human metabolome. Nucleic Acids Res. 2009
37(Database issue):D603-610. 18953024
6. Wishart DS, Jewison T, Guo AC, Wilson M, Knox C, et al., HMDB 3.0 — The Human Metabolome Database in
2013. Nucleic Acids Res. 2013. Jan 1;41(D1):D801-7. 23161693
7. National Center for Biotechnology Information. PubChem Compound Database; CID=4659569,
https://pubchem.ncbi.nlm.nih.gov/compound/4659569 (accessed Apr. 6, 2017).
8. Peter W. Rose, Andreas Prlić, Ali Altunkaya, Chunxiao Bi, Anthony R. Bradley, Cole H. Christie, Luigi Di Costanzo,
Jose M. Duarte, Shuchismita Dutta, Zukang Feng, Rachel Kramer Green, David S. Goodsell, Brian Hudson, Tara
Kalro, Robert Lowe, Ezra Peisach, Christopher Randle, Alexander S. Rose, Chenghua Shao, Yi-Ping Tao, Yana
Valasatava, Maria Voigt, John D. Westbrook, Jesse Woo, Huangwang Yang, Jasmine Y. Young, Christine Zardecki,
Helen M. Berman, Stephen K. Burley.
(2017) The RCSB protein data bank: integrative view of protein, gene and 3D structural information Nucleic Acids
Research, 45: D271-D281
9. Ehler, A., Benz, J., Schlatter, D., & Rudolph, M. G. (2014). Mapping the conformational space accessible to catechol-O-
methyltransferase. Acta Crystallographica Section D Biological Crystallography,70(8), 2163-2174.
doi:10.1107/s1399004714012917
10. Jorga, K., Fotteler, B., Heizmann, P., & Gasser, R. (2001). Metabolism and excretion of tolcapone, a novel inhibitor of
catechol-O-methyltransferase. British Journal of Clinical Pharmacology,48(4), 513-520. doi:10.1046/j.1365-
2125.1999.00036.x
11. Gonçalves, D., Alves, G., Soares-Da-Silva, P., & Falcão, A. (2012). Bioanalytical chromatographic methods for the
determination of catechol-O-methyltransferase inhibitors in rodents and human samples: A review. Analytica Chimica
Acta,710, 17-32. doi:10.1016/j.aca.2011.10.026
12. &. (1998). Tolcapone (Tasmar). American Journal of Nursing,98(7). doi:10.1097/00000446-199807000-00016
Editor's Notes
the substantia nigra that produces dopamine.
When the cells in substantia nigra are die or damages, they stop making dopamine, the communication between the brain and muscles weakens; finally, the brain becomes unable to control muscle movement.
High affinity
serum glutamic-pyruvic transaminase (SGPT/ALT) and serum glutamic-oxaloacetic transaminase (SGOT/AST)
From Rat COMT model
dopamine does not cross the blood–brain barrier (BBB), and levodopa can
Pass BBB, Levodopa convert to Dopamine by AADC
5-10%
Combine all 3 in 1 treatment: Levodopa, AACD inhibitor and Tolcapone: THE BIOAVAILABILITY OF Levolopa increase 2 fold because
Tolcapone prevent Levodopa metabolism in peripheral tissues and in brain, also dopamine metabolism in the brain by inhibiting COMT enzyme.
Mg ion and SAM buried inside the enzyme
Part end of the drug stick out of space
6 Hbonds with 4 residues on COMT
The Mg2+ anchor of the drug in a catalytic position by the two catechol hydroxyl groups of the substrate
Also interact with 3 residues on COMT and 1 water molecule (not shown)
The Mg2+ has an octahedral coordination to Asp141 and Asp169, Asn170, and one crystallographic water molecule (not shown). The 2 free coordination sites are occupied by the two catechol hydroxyl groups of the substrate, so the Mg2+ ion is a anchor of the substrate (or inhibitor) molecules in a catalytic position.
To study conformational changes of COMT when it complex withMg2+, SAM or its analogue and Tolcapone in human: used Humanized rat COMT model.
No SAM: His185, Trp186 (Tryptophan) and Arg189 (arginine) stack on top of each other, with Trp186 occupying the usual position SAM or SAH. Glu133 hydrogenbonds to Trp186.
With SAM or SAH: Glu133 hydrogenbonds to –OH groups of SAM or its analogue.
His185, Trp186 and Arg189 swing out
Lys187, Trp 186 and Asp 188 interact with each other: Asp188 hydrogen-bonds to Trp186. Lys187 electrostatically interact with Asp188.
With both inhibitor and SAM: Asp188 releases both Lys187 and Trp186. Trp186 now packs perpendicularly on top of SAM and Lys187 point toward the Mg2+ site.
absence of inhibitor : Conformation change at beta loop 6/7, cause Glu242 in flips away from the Mg2+ site by 6A (and does not bind to the water molecules that replace the catechol).
tHEN, Mg2+ RELEASED, a conformational change in loop alpha 2/alpha3 removes Met83 from the Mg2+ site
Also, Lys187 is in the out Mg2+ and interact with Asp 188
Lastly, SAM removed, Glu133 reorients to Ala110 and Trp186. Pro217 SWING OUT
200mg tablet
Conjugated Catechol moiety: can not be active as COMT inhibitor.
Intact Catechol moiety: The metabolites resulting from oxidation or reduction can be active as inhibitors of COMT.
