Axel Koehler from Nvidia presented this deck at the 2016 HPC Advisory Council Switzerland Conference. “Accelerated computing is transforming the data center that delivers unprecedented through- put, enabling new discoveries and services for end users. This talk will give an overview about the NVIDIA Tesla accelerated computing platform including the latest developments in hardware and software. In addition it will be shown how deep learning on GPUs is changing how we use computers to understand data.” In related news, the GPU Technology Conference takes place April 4-7 in Silicon Valley. Watch the video presentation: http://insidehpc.com/2016/03/tesla-accelerated-computing/ See more talks in the Swiss Conference Video Gallery: http://insidehpc.com/2016-swiss-hpc-conference/ Sign up for our insideHPC Newsletter: http://insidehpc.com/newsletter

1. HPC Advisory Council Meeting Lugano | 22 March 2016
The Tesla Accelerated Computing Platform
Axel Koehler , Principal Solution Architect

2. 2
Agenda
Introduction
TESLA Platform for HPC
TESLA Platform for HYPERSCALE
TESLA Platform for MACHINE LEARNING
TESLA System Software and Tools
Data Center GPU Manager, Docker

3. 3
ENTERPRISE AUTOGAMING DATA CENTERPRO VISUALIZATION

4. 4
TESLA PLATFORM PRODUCT STACK
Software
System Tools &
Services
Accelerators
Accelerated
Computing
Toolkit
Tesla K80
HPC
Enterprise Services · Data Center GPU Manager · Mesos · Docker
GRID 2.0
Tesla M60, M6
Enterprise
Virtualization DL Training
Hyperscale
Hyperscale Suite
Tesla M40 Tesla M4
Web Services

5. 5
TESLA PLATFORM FOR HPC

6. 6
CPU
Optimized for
Serial Tasks
GPU Accelerator
Optimized for
Parallel Tasks
HETEROGENEOUS COMPUTING MODEL!
Complementary Processors Work Together

7. 7
COMMON PROGRAMMING MODELS ACROSS
MULTIPLE CPUS
x86
Libraries
Programming
Languages
Compiler
Directives
AmgX
cuBLAS

8. 8
370 GPU-Accelerated
Applications
www.nvidia.com/appscatalog

9. 9
TESLA K80
World’s Fastest Accelerator
for HPC & Data Analytics
0 5 10 15 20 25 30
Tesla K80 Server
Dual CPU Server
# of Days
AMBER Benchmark: PME-JAC-NVE Simulation for 1 microsecond
CPU: E5-2698v3 @ 2.3GHz. 64GB System Memory, CentOS 6.2
CUDA Cores 2496
Peak DP 1.9 TFLOPS
Peak DP w/ Boost 2.9 TFLOPS
GDDR5 Memory 24 GB
Bandwidth 480 GB/s
Power 300 W
GPU Boost Dynamic
Simulation Time from
1 Month to 1 Week
5x Faster
AMBER Performance

10. 10
VISUALIZE DATA INSTANTLY FOR FASTER SCIENCE
Traditional
Slower Time to Discovery
CPU Supercomputer Viz Cluster
Simulation- 1 Week Viz- 1 Day
Multiple Iterations
Time to Discovery =
Months
Tesla Platform
Faster Time to Discovery
GPU-Accelerated Supercomputer
Visualize while you
simulate/without
data transfers
Restart Simulation Instantly
Multiple Iterations
Time to Discovery = Weeks
Flexible
Scalable
Interactive
Days
Data Transfer

11. 11
EGL CONTEXT MANAGEMENT
Top systems support OpenGL under X
EGL: Driver based context management
Support for full OpenGL*, not only GL ES
Available in e.g. VTK
New opportunities for CUDA/OpenGL** interop
*Full OpenGL in r355.11; **CUDA interop in r358.7
Leaving it to the driver
Tesla GPU
Tesla driver with EGL
ParaView/VMD
X-server

12. 12
SCALABLE RENDERING AND COMPOSITING
Large-scale (volume) data visualization
Interactive visualization of TB of data
Stand-alone or coupling into simulation
HW Accelerated remote rendering
Plugin for ParaView available
http://www.nvidia-arc.com/products/nvidia-index.html
NVIDIA INDEX
Dataset from NCSA Blue Waters

13. 13
NVLINK : A HIGH-SPEED GPU INTERCONNECT
Whitepaper: http://www.nvidia.com/object/nvlink.html
GPU to CPU via NVLink
NVLink
Pascal
CPU
(NVLINK
Enabled)
DDR
Memory
10s-100s GB
HBM
16-32GB
DDR4
50-75 GB/s
1Tbyte/s
PCIe
GPU to GPU via NVLink
PascalPascal
CPU
(x86)
PCIe Switch
NVlink

14. 14
U.S. TO BUILD TWO FLAGSHIP SUPERCOMPUTERS
Powered by the Tesla Platform
100-300 PFLOPS Peak
10x in Scientific App Performance
IBM POWER9 CPU + NVIDIA Volta GPU
NVLink High Speed Interconnect
40 TFLOPS per Node, >3,400 Nodes
2017
Major Step Forward on the Path to Exascale

15. 15
TESLA PLATFORM FOR HYPERSCALE

16. 16
EXABYTES OF CONTENT PRODUCED DAILY
User-Generated Content Dominates Web Services
10M Users
40 years of video/day
1.7M Broadcasters
Users watch 1.5 hours/day
6B Queries/day
10% use speech
270M Items sold/day
43% on mobile devices
8B Video views/day
400% growth in 6 months
300 hours of video/minute
50% on mobile devices
Challenge: Harnessing the Data Tsunami in Real-time

17. 17
TESLA FOR HYPERSCALE
10M Users
40 years of video/day
270M Items sold/day
43% on mobile devices
TESLA M4TESLA M40
HYPERSCALE SUITE
POWERFUL: Fastest Deep Learning Performance LOW POWER: Highest Hyperscale Throughput
GPU Accelerated
FFmpeg
Image Compute
Engine
! !
GPU REST Engine
!

18. 18
HTTP (~10ms)
GPU REST Engine (GRE) SDK
Accelerated Microservices
for Web and Mobile Applications
Supercomputer performance for hyper-scale
datacenters
Powerful nodes with low response time (~10ms)
Easy to develop new microservices
Open source, integrates with existing infrastructure
Easy to deploy & scale
Ready-to-run Docker file
GPU REST Engine
Classification
Speech
Recognition
…
Scaling
developer.nvidia.com/gre

19. 19
TESLA M4
Highest Throughput
Hyperscale Workload
Acceleration
CUDA Cores 1024
Peak SP 2.2 TFLOPS
GDDR5 Memory 4 GB
Bandwidth 88 GB/s
Form Factor PCIe Low Profile
Power 50 – 75 W
Video
Processing
Processing
Video
Transcode
Machine
Learning
Inference
H.264 & H.265, SD & HD
Stabilization and
Enhancements
Resize, Filter, Search,
Auto-Enhance

20. 20
JETSON TX1
Embedded
Deep Learning
• Unmatched performance under 10W
• Advanced tech for autonomous machines
• Smaller than a credit card
JETSON TX1
GPU 1 TFLOP/s 256-core Maxwell
CPU 64-bit ARM A57 CPUs
Memory 4 GB LPDDR4 | 25.6 GB/s
Storage 16 GB eMMC
Wifi/BT 802.11 2x2 ac/BT Ready
Networking 1 Gigabit Ethernet
Size 50mm x 87mm
Interface 400 pin board-to-board connector

21. 21
HYPERSCALE DATACENTER NOW ACCELERATED
Tesla Platform
SERVERS FOR TRAINING
Scales with Data
SERVERS FOR INFERENCE, WEB SERVICES
Scales with Users
!
Exabytes of Content / Day Trained Model Model Deployed on Every Server Billions of Devices

22. 22
TESLA PLATFORM FOR MACHINE LEARNING

23. 23
DEEP LEARNING EVERYWHERE
INTERNET & CLOUD
Image Classification
Speech Recognition
Language Translation
Language Processing
Sentiment Analysis
Recommendation
MEDIA & ENTERTAINMENT
Video Captioning
Video Search
Real Time Translation
AUTONOMOUS MACHINES
Pedestrian Detection
Lane Tracking
Recognize Traffic Sign
SECURITY & DEFENSE
Face Detection
Video Surveillance
Satellite Imagery
MEDICINE & BIOLOGY
Cancer Cell Detection
Diabetic Grading
Drug Discovery

24. 24
Why is Deep Learning Hot Now?
Big Data Availability GPU AccelerationNew ML Techniques
350 millions
images uploaded
per day
2.5 Petabytes of
customer data
hourly
300 hours of video
uploaded every
minute

25. 25
Image “Volvo XC90”
Image source: “Unsupervised Learning of Hierarchical Representations with Convolutional Deep Belief Networks” ICML 2009 & Comm. ACM 2011.
Honglak Lee, Roger Grosse, Rajesh Ranganath, and Andrew Ng.
WHAT IS DEEP LEARNING?

26. 26
DRIVE PX AUTO-PILOT
CAR COMPUTER
NVIDIA GPU DEEP LEARNING
SUPERCOMPUTER
Neural Net Model
Classified Object
!
Camera Inputs
Cars That See Better … And Learn

27. 27
Camera Inputs
Medical Compute Center
(Training)
Hospital/Doctor
(Inference)
Classified Object
Med. device inputs
Neural Net Model
!
!
Deep Learning Platform In Medical
Feedback

28. 28
GPUs deliver --
- same or better prediction accuracy
- faster results
- smaller footprint
- lower power
NEURAL
NETWORKS
GPUS
Inherently
Parallel ! !
Matrix
Operations ! !
FLOPS ! !
Bandwidth ! !
GPUS AND DEEP LEARNING

29. 29
NVIDIA CUDA
ACCELERATED COMPUTING PLATFORM
WATSON CHAINER THEANO MATCONVNET
TENSORFLOW CNTK TORCH CAFFE
NVIDIA GPU THE ENGINE OF DEEP LEARNING

30. cuDNN
Deep Learning Primitives
IGNITING ARTIFICIAL
INTELLIGENCE
" GPU-accelerated Deep Learning
subroutines
" High performance neural network
training
" Accelerates Major Deep Learning
frameworks: Caffe, Theano, Torch
" Up to 3.5x faster AlexNet training
in Caffe than baseline GPU
Millions of Images Trained Per Day
Tiled FFT up to 2x faster than FFT
developer.nvidia.com/cudnn
0
20
40
60
80
100
cuDNN 1 cuDNN 2 cuDNN 3 cuDNN 4
0.0x
0.5x
1.0x
1.5x
2.0x
2.5x

31. 31
NVIDIA DIGITS
Interactive Deep Learning GPU Training System
Test Image
Monitor ProgressConfigure DNNProcess Data Visualize Layers
http://developer.nvidia.com/digits

32. 32
TESLA M40
World’s Fastest Accelerator
for Deep Learning Training
0 1 2 3 4 5 6 7 8 9 10 11 12 13
GPU Server with
4x TESLA M40
Dual CPU Server
13x Faster Training
Caffe
Number of Days
CUDA Cores 3072
Peak SP 7 TFLOPS
GDDR5 Memory 12 GB
Bandwidth 288 GB/s
Power 250W
Reduce Training Time from 13 Days to just 1 Day
Note: Caffe benchmark with AlexNet,
CPU server uses 2x E5-2680v3 12 Core 2.5GHz CPU, 128GB System Memory, Ubuntu 14.04

33. 33
Facebook’s deep learning machine
Purpose-Built for Deep Learning Training
2x Faster Training for Faster Deployment
2x Larger Networks for Higher Accuracy
Powered by Eight Tesla M40 GPUs
Open Rack Compliant
Serkan Piantino
Engineering Director of Facebook AI Research
“Most of the major advances in machine learning and AI in the
past few years have been contingent on tapping into powerful
GPUs and huge data sets to build and train advanced models”

34. 34
Designed for AI Computing at large scale
Built on the NVIDIA Tesla Platform
• 8 Tesla M40s deliver aggregate 96 GB GDDR5
memory and 56 teraflops of SP performance
• Leverages world’s leading deep learning
platform to tap into frameworks such as Torch
and libraries such as cuDNN
Operational Efficiency and Serviceability
• Free-air Cooled Design Optimizes Thermal and
Power Efficiency
• Components swappable without tools
• Configurable PCI-e for versatility

35. 35
NCCL
GOAL:
• Build a research library of accelerated collectives that is easily
integrated and topology-aware so as to improve the scalability of
multi-GPU applications
APPROACH:
• Pattern the library after MPI’s collectives
• Handle the intra-node communication in an optimal way
• Provide the necessary functionality for MPI to build on top to handle
inter-node
Accelerating Multi-GPU Communications for Deep Learning
github.com/NVIDIA/nccl

36. TESLA SYSTEM SOFTWARE AND TOOLS

37. DATA CENTER GPU MANAGEMENT
Device Management!
Board-level GPU
Configuration & Monitoring
• Device Identification
• Configuration & Monitoring
• Clock Management
All GPUs Supported Tesla GPUs Only Tesla GPUs Only
! Active Diagnostics ! Health &
Governance
• GPU Recovery & Isolation
• System Validation
• Comprehensive Diagnostics
• Real-time Monitoring &
Analysis
• Governance Policies
• Power & Clock Management
Diagnostics, Recovery &
System Validation
Proactive Health, Policy &
Power Mgmt.
Today Data Center GPU Manager (DCGM)

38. DATA CENTER GPU MANAGER (DCGM)
Compute Node
Management Node
DC GPU Manager
DC Cluster Management SW
Mgmt. SW Agent
APIs
Network
Tesla Enterprise Driver
Admin
GPU GPU GPU GPU
Admin
CLI
DCGM Available as library & CLI
Ready for integration into ISV Mgmt. Software
— eg. Bright Cluster Manager , IBM Platform Cluster Manager
Ready for integration with HPC Job Schedulers
— eg. Altair PBS Works, Moab & Maui, IBM Platform LSF,
SLURM, Univa GRID Engine
DCGM currently in Public Beta
http://www.nvidia.com/object/data-center-gpu-manager.html

39. GROWING CONTAINER ADOPTION IN DATA
CENTER
“Docker spreads like wildfire, especially in the enterprise”
Rightscale 2016 Cloud Survey Report
>2X growth in Docker
adoption in a year
Across Enterprise, Cloud and HPC

40. GPU CONTAINERIZATION USING NVIDIA-DOCKER
Single command-line interface to take care of all
deployment steps
• Discovery, Config/setup, Device allocation
Pre-built images on Docker HUB – CUDA, Caffe, Digits
• Reproducible builds across heterogeneous targets
Remote deployment using NVIDIA-Docker-Plugin and
REST interface
Key Highlights
# NVIDIA Docker on GitHUB (experimental) – Available Now
# Bundled with CUDA Product – Future Versions (In planning)

41. Axel Koehler
akoehler@nvidia.com
