A presentation I gave at Internetofthingsday in Oslo november 6th. Here's the video: http://www.ndcvideos.com/#/app/videos/1941

1. Supercharge your IoT toolbox with
MQTT and Node-RED
Simen Sommerfeldt, Internet of Things Day 2014

2. Advisor and CTO, Bouvet Oslo
Dataforeningen, HIOA,
Lær Kidsa Koding!
Oslo IoT meetup
@sisomm

5. how to do reliable
messaging over
unreliable
networks? ”
“
Dr. Andy Stanford-Clark, IBM

6. Background
“MQTT was actually first designed for
Real Time, Mission Critical,
Command & Control, SCADA systems”
- Arlen Nipper, Cirrus Link Solutions

7. Background
http://4.bp.blogspot.com/-X9AAHRg_Jps/UL9jW9XV8DI/AAAAAAAABu8/nZhETlJ02K0/s1600/ISO+New+England+control+room.JPG

8. Pub/Sub with topic paths
/container/address/devicetype/unique/status <payload>
/minecraft/world/skull/250,72,211/status IS_ALONE
Wildcards: # entire subtree, + a single level
http://m.eet.com/media/1171446/0912embmqtt01.png

9. Broker
/container/address/devicetype/unique/status <payload>
/minecraft/world/skull/250,72,211/status IS_ALONE
/container/address/devicetype/unique/incoming <payload>
/arduino/1/incoming SERVOS_MOVE,54,69

10. Can combined with REST to
provide notifications

11. Multiple brokers
http://usuaris.tinet.cat/sag/mq_pubsub.htm

12. Standard since October 29th

13. IoT-friendly “Tricks”
• Last will & testament
• Binary payload
• 3 QoS levels
• Retained messages
• 2 byte overhead
• Small footprint
• Low bandwidth

14. Mobile: MQTT vs HTTPS
http://mobilebit.wordpress.com/2013/05/03/rest-is-for-sleeping-mqtt-is-for-mobile/
”
“

15. Do one thing
and do it well!
“I position MQTT as "the UNIX utility of
M2M" - deliberately simple, easy to plug
in to other tools, languages, and
techniques”
- Andy Piper, Twitter

16. MQTT is so simple that my
children instantly could follow
the message flow and suggest
changes

18. Usages...

19. MQTT might be in your pocket now

20. http://highscalability.com/blog/2014/1/13/nytimes-architecture-no-head-no-master-no-single-point-of-fa.html

21. “MQTT is used both inside as inter-process
communication and in the cloud
for diagnosis”
- Stefano Costa, Bluewind

23. Credo: “Use it as a protocol.
Provide scaling and security as
you need”

24. http://www.slideshare.net/kellogh/mqtt-kafka-33100776

25. Security
• Username/Password
• SSL connections
• ACL for topics in some brokers
• Client authentication (Certificates)
• Encrypt messages

26. MQTT servers
• RabbitMQ
• Apache ActiveMQ
• Apache Apollo
• Moquette
• HiveMQ
• Mosca
• IBM MQ
• Mosquttio

27. Cloud services
• Xively
• Nimbits
• Azure?
• Eurotech Everywhere Device Cloud
• Litmus Automation
• M2M.IO

28. ESB’s
• Mule
• Fuse ESB
• WSO2
• IBM Websphere ESB
• Talend

29. Node.red
26-Nov-14
9

30. DEMO ( )

32. “Wiring together hardware
devices, APIs and online
services in new and
interesting ways [...] focus
on the task at hand and not
worry about the plumbing”
- Nick O’Leary, IBM

33. "Just as a spreadsheet lets you
to play around with numbers,
Node-RED is a tool that's good
for playing around with events”
- Dave Convay-Jones, IBM

34. http://www.infoq.com/resource/news/2014/05/ibm-node-red-qconlondon/en/resources/Node-RED-WS-Tweet-Demo-QCon-London-2014.png

35. Inputs

36. Functions
& Social

37. Storage,
Analysis,
“Advanced”

38. Simple to install, with node.js and npm
Find other nodes on GitHub!

39. https://c1.staticflickr.com/3/2299/2217422218_dac8acaa63.jpg

40. Can use other node.js packages
& be embedded

41. Make your own

42. Users manual
In your browser:
1. Add or select a node
2. Configure it
3. Combine it with others to form a flow
4. Deploy
5. Test

43. My Original Python Broker:
~20 hrs
Node Red:
1 hr

45. Copy and paste with JSON

46. Usages
• Rapid mockup of REST Services
• Mockup of Integration scenarios
• Internet of things protyping
http://www.kongsbjergskolen.kolding.dk/Infoweb/Forsideavis/visnyhed.asp?AvisID=5&ID=12

47. Don’t run in production
- or know what you do!

48. My wants: Mutex and
aggregator pattern
My wants:
Mutex
&
Aggregator pattern
http://huisdierencentrumhaarlem.nl/wp-content/uploads/2013/01/animals-cat-kitten-cute-begging-kitten-wallpaper.jpg

49. Sommerfeldt surveilance system?

50. http://blogg.bouvet.no/2014/03/10/an-internet-of-things-demo-using-raspberry-pi-arduino-
minecraft-and-mqtt/

51. http://blogg.bouvet.no/2014/08/04/node-red-how-it-simplifed-my-iot-project-and-how-you-
can-rapidly-prototype-for-the-internet-of-things/

52. github.com/sisomm/iot-concepts
56-Nov-14
4

53. Thanks to...
• Andy Piper @ Twitter (Former IBM)
• Michael Laing @ NY Times
• Ian Skerret @ Eclipse Foundation
• Benjamin Cabé @ Eclipse working group
• Stefano Costa @ Bluewind
• Nils Perret @ Bouvet

54. Join us on
our demo day
November 18th
@ Bouvet

55. Questions?

56. Thanks

57. Answer to Clemens Vasters
https://www.ibm.com/developerworks/community/blogs/c565c720-
fe84-4f63-873f-607d87787327/entry/
mqtt_a_discussion_on_clemens_vasters_post?lang=en
