This document provides information on various automation projects completed by Square Automation including laser cutting systems, pick and place systems, testing benches, deposition systems, and more. It lists the system specifications for each including the controllers, motors, software, and applications. It also describes Square Automation's products, services, and upcoming project areas like NDT, welding machines, tensile testing, and engraving machines.

1. Square Automation Project Photo AlbumDistributors & Integrators of Motion Control Solution

2. Products Servo Motor / Servo Drive

3. Stepper Motor / Stepper Drive

4. PLC & Motion Controller

5. Data Acquisition Module

6. Linear Actuators System

7. AC / DC Motor

8. VFD’s

9. Higher capacity Gear boxesServicesMotion Controller & PLC Programming

10. SPM & Lab Testing Machine Builder

11. Software Development in Labview, VB6 & .NetElectrical Control Panel Development.

12. Mechanical DesignSystem Specification: Controller – Motion Controller from Galil Motion 3 Axis

13. Servo Motor – AC Servo Motor 1.3 & 2.3Nm Servo (TECO)

14. Software – DXF to G Code Interpreter Software

15. Application – Cutting ApplicationXY Laser Cutting System

16. System Specification: Controller – Motion Controller from Galil Motion 4 Axis

17. Motor – AC Servo Motor 1.3 & 2.3Nm with Gearbox (TECO)

18. Servo based linear actuator

19. Application – Ultra Sonic Welding 4 Axis Pick & Place control System

20. System Specification: Controller – Delta PLC

21. Motor – Stepper Motor (Spark Motors)

22. Application – Table used in Atomic research systemOscillating Table System for Atomic Research

23. System Specification: Controller – Delta PLC

24. Motor – AC Servo Motor (Xinstart)

25. Software – Labview Based Software for data measurement

26. Application – Torque Measurement Test Bench System for Torque Testing of Lock & Key.

27. Test Bench System for Testing Lock & Key Force Measurement.System Specification: Controller – Customised Controller

28. Motor – Stepper Motor (Spark Motors)

29. Software – Labview Based Software for data measurement

30. Application – Force Measurement Fully Automatic Thin Film Deposition System

31. Hot Wire CVD System
