1. SRM SPACE PROBE
CHASING THE INCOMING SUNGRAZER...

2. INTRODUCTION
SRM SPACE PROBE is a research project under the
department of Aerospace (SRM University,
Kattankulathur).
We are sponsored by Maple Software. Our task is to
Launch an unmanned high altitude balloon till 28th
november
2013 and accomplish all the mission objectives

3. RESEARCH SUBJECT (ISON)
Comet ISON will make an appearance in Earth's
sky in 2013. While it's hard to predict just how
bright the comet will be when it arrives, some
astronomers are saying that it could be as bright
as the full moon or perhaps, even visible in daylight.
ISON is considered a "sungrazer," meaning that it
will pass very close to the sun when it gets into
the inner solar system in November 2013.
Our mission is to take photograph of this comet from an altitude of 30 km and use it for
Estimating the composition of ISON comet.

4. Two Major Segments of Project:
1) Ground Segment
2) Space Segment: High Altitude Balloon

5. Ground Segment
1) Launch Facility
2) Launch Pad
3) Integration of Balloon
4)Helium/Hydrogen Filling in the Balloon

6. Space Segment: High Altitude Balloon
Flight System
1) 3 rubber and 1 plastic Balloons (Hydrogen Filled)
2) Recovery mechanism (Optional)
3) Box for Payload
4) 3 Radio Sonde
5) Release Mechanism
6) Nylon Chords to connect payload and Balloon
7) Tracking Devices

7. Payload
It will be consisting of a chronograph, a telescope, RGB filters, a Camera for
ISON experiment and also a parachute for recovery, Radio-sonde for main
tracking system and android phone as a backup system. A data recorder
and a flight recording camera.

8. PAYLOAD-1

9. BLOCK DIAGRAM OF ENTIRE SYSTEM

10. PLAN OF THE PROJECT
1) Selection of students
2) Purchasing of required materials
3) Design and Build Flight System
4) Test Flight System
5) Develop Payload
6) Launch
7) Recover
8) Study of observed / Stored Data

11. DESIGN
We choose to have
capsule shaped module
to resist shear forces
and for stability factor
as drag is also low for
uniform bodies

13. Tracking Mount

14. PARACHUTE CALCULATION

16. Descend Velocity of payload
3kg payload
30km-Vd=47.234m/s
25km-Vd=32.039m/s
20km-Vd=21.490m/s
15km-Vd=14.538m/s
10km-Vd=9.964m/s
5km-Vd=7.467m/s
1km-Vd=6.075m/s
0km-Vd=5.788m/s

17. WIND PROFILE

18. SPECIFICATION OF
COMPONENTS

19. MICROCONTROLLER
ARDUINO BOARD
PROCESSOR: ATMega328
CLOCK SPEED: 16MHz
OPERATING VOLTAGE: 5V
INPUT VOLTAGE: 7-12V
WEIGHT: 30grams.

20. TELESCOPE
Model: Travel Scope 70 Portable
Key Features: 70 mm Aperture,
100x Light Gathering Power,
400 mm Focal Length,
Fully Optical Coated
Maximum
Magnification: 165 x
Minimum
Magnification: 10 x
Brand: Celestron
Display
Magnification:10 - 165 x
Weight: 1500 g

21. CAMERA Brand: Sony
Series: Cyber-shot
Type: Point & Shoot
Weight: 122 g (with Battery and Meomry
Card), 106 g (Body Only)
Dimensions: 93.1 (W) x 52.3 (H) x 22.5 (D)
mm
Optical Sensor Resolution (in MegaPixel):
16.1 Megapixels
Image Sizing: 4608 X 3456 (16 M)
Video Format: H.264
Image Format: JPEG, DCF, DPOF

22. MEMORY CARD
• CAPACITY: 32GB
• TEMPERATURE RANGE: -30degC-85degC
• SHOCK AND VIBRATION PROOF: CAN
WITHSTAND UPTO 500Gs OF SHOCK
• Type: Micro SD.

23. BATTERY
1. Nickel-Metal Hydrated(NiMH)
2.Voltage Output: 1.2volts/cell
3.Quantity used: 12
4.Weight of Each cell: 22g
5.Operating Temperature: -20C to 50C
6.Charging Range: 0C to 45C

24. ELECTROMECHANICAL SYSTEM
• SERVO MOTORS
Quantity:1 for FULL ROTATION
Quantity:2 for 180 DEGREES ROTATION
WEIGHT OF EACH SERVO: 45grams
PULSE CONTROLLED WITH COMMAND FROM
MICROCONTROLLER BOARD.
TORQUE:3kgcm

25. COST ANALYSIS
DESCRIPTION NOS Cost of one item Total cost
Weather balloon 2 7500 15000
Telescopes 2 6000 12000
Spectrometer 1 6000 6000
Camera (HD) 2 5000 10000
Camera 2 3000 6000
RGB Filter 1 1000 1000
Android phones 2 5000 10000
Other electronics - - 20000
Material - - 20000

26. Sponsors
Maple Software is a software
development company that has been
providing software services and other IT
enabled services for over eight years to
independent software vendors and
companies reliant upon technology.
They have sponsored us a sum of 70,000/-

27. THANK YOU
